1

00:00:00,566 --> 00:00:02,833

Small current when iPhone is turned on

2

00:00:03,433 --> 00:00:07,433

In this lesson, we will learn the maintenance process of small current

3

00:00:08,233 --> 00:00:10,200

When repairing small current faults,

4

00:00:10,400 --> 00:00:12,433

we must first check the appearance to see

5

00:00:12,433 --> 00:00:16,500

if the mainboard has obvious water corrosion or damaged components

6

00:00:19,433 --> 00:00:22,766

After the elimination, if there is still a small current,

7

00:00:23,033 --> 00:00:26,666

we will follow the maintenance process to check and repair step by step

8

00:00:27,700 --> 00:00:30,600

Step 1 of the small current maintenance process,

9

00:00:31,166 --> 00:00:34,633

measure whether the power supply voltage of the CPU is normal

10

00:00:35,500 --> 00:00:40,166

There are about 15 power supplies for the CPU, we all need to measure them

11

00:00:40,533 --> 00:00:42,733

If there is no voltage when we measure,

12

00:00:42,933 --> 00:00:46,466

it is generally the damage of the inductor or the power IC

13

00:00:47,266 --> 00:00:49,466

Let's replace the inductor first

14

00:00:49,766 --> 00:00:54,200

If it is abnormal after replacement, we need to replace the power IC

15

00:00:54,833 --> 00:00:57,900

Matters needing attention when measuring power supply

16

00:00:59,400 --> 00:01:05,966

The CPU's GPU power supply and GPU_SDRM power supply cannot be measured when measuring the voltage

17

00:01:06,433 --> 00:01:10,900

These two power supplies will have voltages when we're playing games on the phone

18

00:01:11,700 --> 00:01:15,433

Why not measure the CPU power supply resistance value?

19

00:01:16,000 --> 00:01:18,533

If the power supply of the CPU is short-circuited,

20

00:01:18,700 --> 00:01:20,433

it will cause a large current,

21

00:01:20,566 --> 00:01:24,066

and we will not be able to repair the fault of the small current

22

00:01:24,500 --> 00:01:28,600

Next, let me demonstrate how to measure the power supply of the CPU

23

00:01:29,500 --> 00:01:32,200

Let's take the iPhone 12 model as an example

24

00:01:32,466 --> 00:01:36,100

After finding the power supply of the power output, jump to the bitmap

25

00:01:37,066 --> 00:01:40,066

Let's measure the power supply voltage of this road first,

26

00:01:42,066 --> 00:01:47,466

the voltage value of this power supply is between 0.5-1.06V

27

00:01:48,366 --> 00:01:50,266

After the mainboard is powered on,

28

00:01:51,166 --> 00:01:53,100

the black marker is grounded,

29

00:01:53,333 --> 00:01:55,433

and the red marker is used to measure

30

00:01:56,233 --> 00:02:00,133

At this time, the voltage we measured is about 0.7V,

31

00:02:00,366 --> 00:02:02,866

which is the same as that marked in the drawing,

32

00:02:03,133 --> 00:02:04,900

indicating that it is normal

33

00:02:05,566 --> 00:02:09,433

Let's measure the next power supply, PP_GPU power supply

34

00:02:10,233 --> 00:02:13,466

The voltage cannot be measured after turning on the computer,

35

00:02:14,266 --> 00:02:17,633

and the voltage will only be available when playing games

36

00:02:18,100 --> 00:02:19,533

Now let's measure it

37

00:02:21,633 --> 00:02:24,000

We measure the position of the yellow point,

38

00:02:27,200 --> 00:02:29,200

the measured voltage is 0V,

39

00:02:30,433 --> 00:02:33,033

and there is no voltage at the other end

40

00:02:33,600 --> 00:02:37,700

Just measured the power supply, we can see that it still has voltage

41

00:02:38,300 --> 00:02:42,700

Next, let's measure the PP_SOC_S1 power supply

42

00:02:43,500 --> 00:02:46,366

This power supply will also go to the CPU

43

00:02:47,033 --> 00:02:49,333

Let's measure it on this capacitor,

44

00:02:51,566 --> 00:02:54,066

and the measured value is 0.7V,

45

00:02:54,433 --> 00:02:57,933

which means that the power supply of this circuit is also normal

46

00:02:58,666 --> 00:03:00,233

Let's continue to measure

47

00:03:04,066 --> 00:03:09,500

PP1V8_S4 does not supply power to the CPU, we do not need to measure

48

00:03:13,633 --> 00:03:18,033

This power supply does not go to the CPU, and we don't need to measure it

49

00:03:18,733 --> 00:03:21,933

PP_DISP_S1 supplies power to the CPU,

50

00:03:26,566 --> 00:03:31,400

and the voltage is 0.75V, indicating that it is also normal

51

00:03:32,033 --> 00:03:37,466

Let's measure the power supply of PP_SRAM_S1, which is supplied to the CPU

52

00:03:40,300 --> 00:03:43,033

We measure on the capacitor C1874,

53

00:03:45,533 --> 00:03:49,666

the voltage is 0.78V, which is also normal

54

00:03:50,800 --> 00:03:52,633

Next we continue to measure

55

00:03:53,500 --> 00:03:59,766

PP1V2_S4, this power supply is not supplied to the CPU, we do not need to measure

56

00:04:00,900 --> 00:04:06,100

PP_AVE_S1, this power supply is for the CPU, let's measure it

57

00:04:08,333 --> 00:04:11,100

The voltage value is about 0.7V

58

00:04:11,900 --> 00:04:14,566

Let's measure the power supply of AVE_S1,

59

00:04:17,233 --> 00:04:20,466

the voltage is 0.7V, which is normal

60

00:04:21,066 --> 00:04:24,666

For CPU power supplies, we all need to measure one by one

61

00:04:25,033 --> 00:04:29,933

If the voltage value we measured is different from the voltage value marked in the drawing,

62

00:04:30,200 --> 00:04:32,866

it means that there is something wrong with the power supply

63

00:04:33,600 --> 00:04:36,600

Either the voltage is low or the voltage is high

64

00:04:36,800 --> 00:04:40,900

Generally, there is a problem with the inductor that generates the power supply

65

00:04:41,100 --> 00:04:44,633

If it is soldered or damaged, we need to replace it

66

00:04:45,566 --> 00:04:49,000

If the voltage is still abnormal after replacing the inductor,

67

00:04:49,266 --> 00:04:51,233

we need to replace the power IC

68

00:04:51,766 --> 00:04:53,833

Ok, that's it for this lesson
