1

00:00:00,566 --> 00:00:02,900

Small current when iPhone is turned on

2

00:00:03,300 --> 00:00:07,300

In this lesson, we mainly talk about the maintenance process of small current

3

00:00:08,133 --> 00:00:10,100

Maintenance process step 2

4

00:00:10,766 --> 00:00:12,833

If the CPU power supply is normal,

5

00:00:13,200 --> 00:00:15,500

we need to measure the CPU clock signal

6

00:00:16,433 --> 00:00:20,366

The clock signal is provided by the 24M crystal oscillator,

7

00:00:20,633 --> 00:00:23,966

we need to measure the voltage of the two pins of the crystal oscillator

8

00:00:24,266 --> 00:00:26,933

The voltage value is around 0.8V,

9

00:00:27,800 --> 00:00:30,566

and there will be a voltage difference between the two pins

10

00:00:30,933 --> 00:00:32,966

If there is no voltage when we measure,

11

00:00:33,400 --> 00:00:36,233

it is possible that the crystal oscillator is damaged

12

00:00:36,333 --> 00:00:38,700

and we need to replace the crystal oscillator

13

00:00:39,133 --> 00:00:42,666

If it is still not normal after replacing the crystal oscillator,

14

00:00:43,200 --> 00:00:48,466

we need to measure whether there is any disconnection between the crystal oscillator pin and the CPU

15

00:00:49,066 --> 00:00:50,333

Let me demonstrate

16

00:00:51,133 --> 00:00:53,700

Let's take the iPhone 12 model as an example

17

00:00:54,466 --> 00:00:58,133

We first find the 24M crystal oscillator in the drawings,

18

00:01:04,566 --> 00:01:08,033

and the crystal oscillator position number is Y1000

19

00:01:09,566 --> 00:01:12,266

We go to the bitmap to find the crystal oscillator,

20

00:01:13,100 --> 00:01:16,733

and then measure the voltage of the two pins of the crystal oscillator

21

00:01:18,300 --> 00:01:21,800

We measure C1021 and C1020

22

00:01:25,166 --> 00:01:28,966

The mainboard is powered on, we will measure after the switch is triggered,

23

00:01:29,566 --> 00:01:32,300

and the measured voltage is 0.57V

24

00:01:32,966 --> 00:01:34,666

Let's measure another pin,

25

00:01:37,733 --> 00:01:41,300

and the measured voltage value is 0.59V

26

00:01:41,900 --> 00:01:45,366

The voltage of the two pins of the crystal oscillator is different,

27

00:01:45,533 --> 00:01:47,266

which means it is normal

28

00:01:47,600 --> 00:01:50,166

To make a completely accurate judgment,

29

00:01:50,500 --> 00:01:54,766

we need to measure the frequency of the crystal oscillator with an oscilloscope

30

00:01:55,200 --> 00:01:59,433

If it can reach 24M, it means the crystal oscillator is normal

31

00:01:59,766 --> 00:02:03,366

Next, let's measure the diode value of the crystal oscillator

32

00:02:03,833 --> 00:02:07,633

The red marker is grounded, and the black marker is measured,

33

00:02:08,133 --> 00:02:10,566

and the measured value is more than 700

34

00:02:10,866 --> 00:02:12,333

Let's measure another pin,

35

00:02:14,633 --> 00:02:17,166

and the measured value is more than 700,

36

00:02:17,900 --> 00:02:21,766

indicating that the crystal oscillator is not disconnected from the CPU

37

00:02:22,233 --> 00:02:24,233

Ok, that's all for this video
