1

00:00:00,566 --> 00:00:02,800

Small current when iPhone is turned on

2

00:00:03,100 --> 00:00:07,033

In this lesson, we mainly talk about the maintenance process of small current

3

00:00:07,933 --> 00:00:09,933

Maintenance process step 3

4

00:00:10,533 --> 00:00:13,766

If the power supply and clock signal of the CPU are normal,

5

00:00:14,066 --> 00:00:16,700

we need to measure the reset signal of the CPU

6

00:00:19,333 --> 00:00:22,233

We first cut off the power, measure the resistance,

7

00:00:22,233 --> 00:00:25,500

and rule out short circuit and disconnection problems

8

00:00:25,766 --> 00:00:27,933

If the measured value is relatively high,

9

00:00:28,066 --> 00:00:30,766

it may be that the fuse of the circuit is damaged,

10

00:00:31,066 --> 00:00:32,866

or the board layer is broken

11

00:00:33,666 --> 00:00:35,866

If the measured value is relatively low,

12

00:00:37,566 --> 00:00:41,266

it means that the capacitor or chip connected to the line is damaged,

13

00:00:45,433 --> 00:00:47,300

If the measured voltage is low,

14

00:00:47,900 --> 00:00:52,033

it is also caused by the capacitor connected to the line or the chip damage

15

00:00:52,366 --> 00:00:56,366

Next, let me demonstrate how to measure the reset of the CPU

16

00:00:56,800 --> 00:01:02,400

Let's take the iPhone12 model as an example, we first find the reset measurement point

17

00:01:03,066 --> 00:01:07,233

In the bitmap, we can see that there is a measuring point under the mainboard

18

00:01:16,100 --> 00:01:21,266

We can also see that the reset signal of the CPU will also be connected to a resistor,

19

00:01:22,100 --> 00:01:25,066

which belongs to the reset pull-up resistor

20

00:01:26,433 --> 00:01:33,433

Its other terminal voltage is 1.2V, and the reset voltage of the iPhone 12 model is 1.2V

21

00:01:33,966 --> 00:01:35,366

Now let's measure it

22

00:01:36,533 --> 00:01:39,333

After the power is turned on and the switch is triggered,

23

00:01:39,800 --> 00:01:41,700

let's measure the reset power supply

24

00:01:42,233 --> 00:01:47,033

The voltage value is about 1.2V, indicating that it is normal

25

00:01:48,633 --> 00:01:51,633

Next, let's measure the reset diode value

26

00:01:52,000 --> 00:01:53,833

After the mainboard is powered off,

27

00:01:54,666 --> 00:01:57,333

the multimeter is adjusted to the diode level,

28

00:01:57,666 --> 00:02:01,766

the red marker is grounded, and the black marker is used to measure

29

00:02:02,366 --> 00:02:06,233

The measured value is 296, indicating normal

30

00:02:06,966 --> 00:02:08,866

The mainboard of the iPhone 12,

31

00:02:08,966 --> 00:02:12,766

its reset signal is sent directly to the CPU by the power supply,

32

00:02:13,066 --> 00:02:15,000

without connecting other chips

33

00:02:15,400 --> 00:02:19,700

If we detect a short circuit, we can only replace the power supply

34

00:02:20,133 --> 00:02:23,666

After replacing the power supply, if it is still not normal,

35

00:02:23,833 --> 00:02:25,700

it means that the CPU is damaged

36

00:02:26,666 --> 00:02:32,100

But in some models, the reset of the CPU will be connected with the reset of other chips

37

00:02:33,100 --> 00:02:36,266

At this time, we can't replace the power supply first,

38

00:02:36,500 --> 00:02:39,133

we can remove other chips and then measure it

39

00:02:40,466 --> 00:02:43,200

If not normal, go to replace the power supply

40

00:02:44,666 --> 00:02:47,700

If it is not normal after the power supply is replaced,

41

00:02:47,933 --> 00:02:49,933

it means that the CPU is damaged

42

00:02:50,400 --> 00:02:52,300

Maintenance process step 4

43

00:02:53,000 --> 00:02:56,066

If all the working conditions of the CPU are normal,

44

00:02:56,300 --> 00:02:58,666

but the current is still small when starting up,

45

00:02:59,866 --> 00:03:04,900

it may be because the 32.768M crystal oscillator is damaged

46

00:03:05,200 --> 00:03:06,433

we can replace it

47

00:03:07,100 --> 00:03:09,233

If it is abnormal after the replacement,

48

00:03:09,400 --> 00:03:13,600

it may be that the CPU is damaged or there is a problem with the bottom of the board

49

00:03:14,400 --> 00:03:19,300

At this time, we need to move the board and move the CPU to the bottom of the good board

50

00:03:19,900 --> 00:03:24,533

If it is still a small current, we can judge that it is caused by CPU damage

51

00:03:25,000 --> 00:03:28,300

So, this is the end of the maintenance process of small current
