1

00:00:00,733 --> 00:00:04,966

The maintenance of iPhone startup constant current and current jump faults

2

00:00:05,700 --> 00:00:11,533

In this video, we mainly explain the fault phenomenon of constant current and current jump

3

00:00:12,533 --> 00:00:16,633

Faults of constant current or current jump at startup are common,

4

00:00:17,366 --> 00:00:19,900

but such faults are very difficult to repair

5

00:00:21,533 --> 00:00:24,766

Let's first look at the take-off current of a normal machine

6

00:00:25,500 --> 00:00:28,933

Like the 6S series, after we trigger the switch,

7

00:00:29,866 --> 00:00:33,033

the current will start to jump from about 70mA

8

00:00:33,600 --> 00:00:37,666

6S to XS max models, after it is turned on,

9

00:00:38,266 --> 00:00:42,000

the trigger current will start to jump from about 50mA

10

00:00:42,766 --> 00:00:46,233

The iPhone 11, 12 series, after starting up,

11

00:00:46,466 --> 00:00:49,600

the current will start to jump from about 80mA

12

00:00:50,300 --> 00:00:54,400

Constant current fault means that after the mainboard is turned on,

13

00:00:55,833 --> 00:01:01,433

we trigger the switch, and the current is directly set between 50- 200mA,

14

00:01:01,700 --> 00:01:05,033

or between 50- 200mA after a jump

15

00:01:05,700 --> 00:01:08,700

This kind of current is a constant current fault

16

00:01:09,500 --> 00:01:12,266

Start-up current jump fault introduction

17

00:01:12,900 --> 00:01:16,366

After the mainboard is powered on, we trigger the switch,

18

00:01:16,766 --> 00:01:20,800

and the current jumps cyclically between 0 and 300mA

19

00:01:21,366 --> 00:01:25,966

For example, when the current jumps from 50mA after power on,

20

00:01:26,466 --> 00:01:32,800

it will jump to 100mA, then jump to 120 or 180mA,

21

00:01:34,033 --> 00:01:38,433

then return to 0, and then it starts to jump from 50mA,

22

00:01:39,633 --> 00:01:41,200

jumping back and forth

23

00:01:43,266 --> 00:01:47,500

But some current jump faults, the current will not return to 0,

24

00:01:47,800 --> 00:01:52,400

it jumps from 50mA to 100 or 120mA,

25

00:01:52,666 --> 00:01:56,166

and then back to 50mA, jumping back and forth

26

00:01:56,666 --> 00:01:59,933

Phenomena like these are current jump faults

27

00:02:02,233 --> 00:02:07,066

Next, let's observe these two failure phenomena in the physical mainboard

28

00:02:07,533 --> 00:02:10,433

Let's take a look at the current jump of a good mainboard

29

00:02:15,166 --> 00:02:19,933

After triggering the switch, the current starts to jump from 50mA,

30

00:02:31,066 --> 00:02:34,766

and in some machines it can jump to more than 1A

31

00:02:35,433 --> 00:02:39,400

After jumping to the highest current, the current will fall back

32

00:02:40,233 --> 00:02:44,633

At this time, the mobile phone is in the state of turning off the screen

33

00:02:45,733 --> 00:02:49,066

Let's take a look at the fault phenomenon of constant current

34

00:02:52,133 --> 00:02:57,133

After the switch is triggered, the current is directly set at about 60mA

35

00:02:57,966 --> 00:03:00,733

Let's take a look at the mainboard of the iPhone XR

36

00:03:03,000 --> 00:03:08,433

After triggering the switch, the current is directly set at about 70mA

37

00:03:08,866 --> 00:03:11,533

Let's take a look at the mainboard of the iPhone 12

38

00:03:16,966 --> 00:03:23,100

After triggering the switch, the current is directly set at around 116mA

39

00:03:23,700 --> 00:03:27,133

These fault phenomena are all constant current faults

40

00:03:28,066 --> 00:03:31,666

Let's take a look at the fault phenomenon of current cycle jump

41

00:03:33,266 --> 00:03:37,200

After the switch is triggered, the current jumps back and forth,

42

00:03:41,866 --> 00:03:46,033

sometimes returning to 0, sometimes not returning to 0

43

00:03:46,766 --> 00:03:49,533

Let's take a look at the mainboard of the iPhone 8P

44

00:03:57,866 --> 00:04:02,466

After triggering the switch, the current starts to jump from 60mA,

45

00:04:04,100 --> 00:04:09,566

then to 200mA and returns to 0, and then repeats the cycle

46

00:04:13,200 --> 00:04:15,800

Let's take a look at the mainboard of the iPhone 12,

47

00:04:22,033 --> 00:04:25,033

the current of this mainboard will also jump in a loop

48

00:04:25,700 --> 00:04:29,966

The fault phenomena we have seen are all current cycle jump faults

49

00:04:31,000 --> 00:04:33,066

Ok, that's all for this video
