128. Working principle of constant current and current jump faults
In this video, we mainly explain the working principle of constant current and current jump.
Detail
Comments

1

00:00:00,466 --> 00:00:04,533

The maintenance of iPhone startup constant current and current jump faults

2

00:00:05,266 --> 00:00:10,733

In this video, we mainly explain the working principle of constant current and current jump

3

00:00:11,400 --> 00:00:13,433

Let's look at the main power supply first

4

00:00:14,466 --> 00:00:19,300

In the first step, when we buckle the battery or connect the adjustable power supply,

5

00:00:19,466 --> 00:00:21,600

the main power supply will be generated

6

00:00:21,966 --> 00:00:25,700

The second step, after the main power supply has the main power supply,

7

00:00:26,300 --> 00:00:32,066

it will provide the working voltage for the 32.768M crystal oscillator

8

00:00:33,000 --> 00:00:35,366

After the crystal oscillator has power supply,

9

00:00:35,533 --> 00:00:41,666

it will generate a 32.768M clock signal and return to the main power supply

10

00:00:42,633 --> 00:00:47,833

This clock signal is a necessary condition for the main power supply to output other signals

11

00:00:52,100 --> 00:00:56,433

If the 32.768M crystal oscillator is damaged,

12

00:00:56,700 --> 00:01:01,033

it will cause the working conditions of the main power supply to be unsatisfied

13

00:01:01,533 --> 00:01:07,266

Therefore, if the crystal oscillator is damaged, it will also cause a constant current

14

00:01:07,666 --> 00:01:11,800

In the third step, after the main power supply receives the main power supply,

15

00:01:12,566 --> 00:01:16,400

it will generate PP1V8_ALWAYS standby power supply

16

00:01:19,133 --> 00:01:25,266

This power supply will provide a pull-up voltage for the switch pin internally through the power supply IC

17

00:01:25,733 --> 00:01:28,666

Step 4, when we trigger the switch,

18

00:01:31,000 --> 00:01:35,333

the voltage of the switch pin will change from 1.8V to 0V

19

00:01:36,100 --> 00:01:40,233

This is the power on signal, it will be sent to the main power supply

20

00:01:41,466 --> 00:01:44,400

After the main power supply receives the power-on signal,

21

00:01:44,766 --> 00:01:47,433

it will wake up the CPU and start working

22

00:01:49,166 --> 00:01:50,533

At the same time,

23

00:01:51,500 --> 00:01:57,033

the power supply module inside the power supply will generate about 30 channels of power supplies

24

00:01:57,433 --> 00:02:01,000

to provide working voltage for other chips in the mainboard

25

00:02:03,400 --> 00:02:06,933

With so many chips, the CPU will work first

26

00:02:07,800 --> 00:02:11,300

In order for the CPU to work, in addition to power supply,

27

00:02:11,466 --> 00:02:14,433

it also needs a clock signal and a reset signal

28

00:02:14,900 --> 00:02:17,000

After the CPU has power supply,

29

00:02:17,066 --> 00:02:19,500

the internal clock module starts to work,

30

00:02:19,800 --> 00:02:25,800

and it will generate a power supply to provide working voltage for the 24M crystal oscillator

31

00:02:26,333 --> 00:02:30,033

After the 24M crystal oscillator has power supply,

32

00:02:30,100 --> 00:02:32,666

it generates 24M frequency,

33

00:02:33,066 --> 00:02:39,400

and then returns to the inside of the CPU to send clock signals for other chips managed by the CPU

34

00:02:40,133 --> 00:02:42,466

After the clock module works normally,

35

00:02:43,700 --> 00:02:48,866

it will output a test clock signal to the main power supply to notify the main power supply

36

00:02:49,566 --> 00:02:55,333

After the main power supply receives the test clock signal, it will send a reset signal to the CPU

37

00:02:55,666 --> 00:03:00,066

After the CPU has power supply, clock signal and reset signal,

38

00:03:00,733 --> 00:03:03,300

the internal self-test module will work

39

00:03:03,700 --> 00:03:05,633

Ok, that's it for this lesson
