1

00:00:00,833 --> 00:00:05,033

The maintenance of iPhone startup constant current and current jump faults

2

00:00:05,433 --> 00:00:10,466

In this lesson, we mainly explain the maintenance methods of these two faults

3

00:00:11,433 --> 00:00:14,933

Although the symptoms of these two failures are different,

4

00:00:16,200 --> 00:00:18,866

their maintenance procedures are the same

5

00:00:19,800 --> 00:00:24,533

Step 1 of the maintenance process, replace the external components,

6

00:00:25,033 --> 00:00:28,166

and eliminate the external components problem

7

00:00:29,133 --> 00:00:34,333

Because in mobile phones, many external components are detected through the I2C bus

8

00:00:34,766 --> 00:00:39,766

The external cables detected through the I2C bus include tail plugs cables,

9

00:00:39,933 --> 00:00:42,633

earpieces cables, boot cables,

10

00:00:42,700 --> 00:00:44,833

and wireless charging cables

11

00:00:45,600 --> 00:00:50,300

Most of the components on these cables are detected through the I2C bus

12

00:00:50,800 --> 00:00:54,500

If these cables are corroded by water or have problems,

13

00:00:55,000 --> 00:00:58,533

it will cause constant current or current cycle jump

14

00:00:59,233 --> 00:01:02,666

Generally, when we exclude external components,

15

00:01:02,800 --> 00:01:05,466

we can remove the mainboard and test the bare board

16

00:01:06,000 --> 00:01:08,333

If the current is normal after starting up,

17

00:01:08,533 --> 00:01:11,733

we can install these external components in sequence

18

00:01:12,800 --> 00:01:16,133

If it doesn't turn on after buckling which accessory,

19

00:01:16,233 --> 00:01:18,700

it means that the external cable is damaged

20

00:01:19,000 --> 00:01:20,700

Let me show you how to do it

21

00:01:22,166 --> 00:01:26,833

After disassembling, directly buckle the adjustable power supply

22

00:01:27,900 --> 00:01:31,100

If you find that the current cycle jumps after starting up,

23

00:01:31,400 --> 00:01:34,866

and it does not start up, or the white apple restarts

24

00:01:35,100 --> 00:01:38,800

We need to remove the external components to test the bare board

25

00:01:39,933 --> 00:01:42,600

For example, we remove all the cables,

26

00:01:42,833 --> 00:01:47,200

boot cable, screen cable, tail plug cable, etc.,

27

00:01:49,900 --> 00:01:51,900

and then turn on the power

28

00:02:00,166 --> 00:02:06,100

If short-circuiting the switch with tweezers is not easy to operate, the switch cable can be left

29

00:02:07,500 --> 00:02:09,700

If the current jump is normal at this time,

30

00:02:09,966 --> 00:02:12,933

it means that it is caused by external components

31

00:02:13,466 --> 00:02:16,500

We put the external components back one by one,

32

00:02:16,900 --> 00:02:20,600

if the current is not normal, it means the mainboard problem

33

00:02:20,900 --> 00:02:23,533

At this time we need to overhaul the mainboard

34

00:02:23,833 --> 00:02:25,800

Ok, that's all for this video
