1

00:00:00,433 --> 00:00:04,566

The maintenance of iPhone startup constant current and current jump faults

2

00:00:04,933 --> 00:00:09,566

In this lesson, we mainly explain how to connect an iPhone to a computer

3

00:00:10,166 --> 00:00:13,033

There are two ways to connect your phone to your computer

4

00:00:13,500 --> 00:00:18,100

The first method is to plug in the data cable after the mobile phone is turned on,

5

00:00:18,400 --> 00:00:20,100

click trust on the screen,

6

00:00:20,233 --> 00:00:22,966

and enter the password to connect to the computer

7

00:00:23,266 --> 00:00:26,033

The second method is to enter the flash mode

8

00:00:26,700 --> 00:00:31,433

There are two Apple flashing modes, recovery mode and DFU mode

9

00:00:33,233 --> 00:00:37,533

Only after entering the flashing mode, we plug in the data cable,

10

00:00:37,800 --> 00:00:40,366

can the computer recognize the mobile phone

11

00:00:40,733 --> 00:00:44,266

If the mobile phone has a constant current when it is turned on,

12

00:00:44,600 --> 00:00:49,700

current jumps, stuck white apple or white apple restart, etc.,

13

00:00:50,100 --> 00:00:52,133

after plugging in the data cable,

14

00:00:52,300 --> 00:00:54,966

the computer cannot recognize the mobile phone

15

00:00:55,333 --> 00:01:00,133

So at this time, if we want to see the error report of the flash machine,

16

00:01:00,266 --> 00:01:03,500

we need to enter the recovery mode or DFU mode

17

00:01:03,833 --> 00:01:09,100

Enter the flash mode Method 1, enter the flash mode according to the key combination

18

00:01:09,566 --> 00:01:14,866

This method is suitable for mainboard whose current is above 200mA after booting

19

00:01:15,266 --> 00:01:20,700

The following is the operation method for different Apple models to enter the recovery mode,

20

00:01:20,900 --> 00:01:22,533

we can follow the steps

21

00:01:24,833 --> 00:01:27,200

Let's take the iPhone7 model as an example

22

00:01:27,200 --> 00:01:31,333

to demonstrate how to enter the flashing mode through a combination of keys

23

00:01:32,866 --> 00:01:36,366

First, open the flashing software in the computer,

24

00:01:37,333 --> 00:01:39,800

and connect the data cable to the computer

25

00:01:40,433 --> 00:01:44,966

When the mobile phone is turned off, turn on the adjustable power supply

26

00:01:45,766 --> 00:01:49,066

We press and hold the volume down button on the phone,

27

00:01:50,600 --> 00:01:52,600

then plug in the data cable

28

00:01:53,100 --> 00:01:54,800

Wait for about 10 seconds,

29

00:01:55,100 --> 00:01:58,300

the data cable icon will be displayed on the screen,

30

00:02:01,133 --> 00:02:04,533

at this time we release the volume down button

31

00:02:05,600 --> 00:02:09,100

The computer will show that it has entered the flashing mode,

32

00:02:09,966 --> 00:02:11,700

and we can flash the machine

33

00:02:13,300 --> 00:02:15,400

This method is suitable for models

34

00:02:15,400 --> 00:02:19,200

whose current can jump to more than 200mA after booting

35

00:02:21,766 --> 00:02:23,966

Enter the flash mode Method 2

36

00:02:24,433 --> 00:02:27,266

If we can't enter the flash mode through the first way,

37

00:02:28,600 --> 00:02:33,666

we can connect the computer through the professional data line into the flash mode

38

00:02:34,766 --> 00:02:37,300

This method is also suitable for models

39

00:02:37,300 --> 00:02:40,700

whose current jumps to more than 200mA after booting

40

00:02:41,733 --> 00:02:44,433

Next, I will demonstrate this method

41

00:02:46,966 --> 00:02:50,266

First, connect the flashing cable to the computer,

42

00:02:50,366 --> 00:02:53,166

and open the flash software on the computer

43

00:02:54,033 --> 00:02:57,633

When the mobile phone is turned off, connect the power cord,

44

00:02:57,866 --> 00:03:01,866

plug in the data cable, and wait for about 10 seconds

45

00:03:10,600 --> 00:03:15,566

At this time, the computer will display that it has entered the flash mode,

46

00:03:15,933 --> 00:03:17,566

and we can go to flash

47

00:03:22,333 --> 00:03:28,166

This method is also suitable for models with a current of more than 200mA after booting

48

00:03:31,000 --> 00:03:35,666

There are many professional data cables for entering the flash mode on Taobao,

49

00:03:36,700 --> 00:03:38,833

and the price is not expensive

50

00:03:42,933 --> 00:03:45,033

Ok, that's all for this video
