1

00:00:00,433 --> 00:00:04,333

The maintenance of iPhone startup constant current and current jump faults

2

00:00:04,633 --> 00:00:08,700

In this lesson, we mainly explain how to connect an iPhone to a computer

3

00:00:10,100 --> 00:00:12,833

There are two ways to connect your phone to your computer

4

00:00:13,433 --> 00:00:17,733

The first method is to plug in the data cable after the mobile phone is turned on,

5

00:00:17,933 --> 00:00:19,700

click trust on the screen,

6

00:00:19,766 --> 00:00:22,533

and enter the password to connect to the computer

7

00:00:23,033 --> 00:00:25,700

The second method is to enter the flash mode

8

00:00:26,033 --> 00:00:28,033

There are two Apple flashing modes,

9

00:00:28,466 --> 00:00:30,533

recovery mode and DFU mode

10

00:00:32,566 --> 00:00:36,300

Only after entering the flashing mode, we plug in the data cable,

11

00:00:36,466 --> 00:00:38,600

can the computer recognize the mobile phone

12

00:00:39,100 --> 00:00:42,266

If the mobile phone has a constant current when it is turned on,

13

00:00:42,500 --> 00:00:47,666

current jumps, stuck white apple or white apple restart, etc.,

14

00:00:48,233 --> 00:00:50,133

after plugging in the data cable,

15

00:00:50,333 --> 00:00:52,900

the computer cannot recognize the mobile phone.

16

00:00:53,133 --> 00:00:57,466

So at this time, if we want to see the error report of the flash machine,

17

00:00:57,600 --> 00:01:00,733

we need to enter the recovery mode or DFU mode

18

00:01:01,533 --> 00:01:05,733

If the current of the mainboard is within 200mA after booting,

19

00:01:06,100 --> 00:01:10,533

we may not be able to enter the flashing mode through method 1 and method 2

20

00:01:11,433 --> 00:01:14,166

We need to use method 3 and method 4

21

00:01:16,300 --> 00:01:18,566

Method 3 is to force DFU

22

00:01:18,766 --> 00:01:24,566

At the point where the DFU is forced, connect a 1.8V or 3V thin wire,

23

00:01:24,800 --> 00:01:28,900

and then insert the data cable, you can connect to the computer

24

00:01:29,233 --> 00:01:34,833

Because the location of the forced DFU point of each model of iPhone is different

25

00:01:35,366 --> 00:01:41,566

We can find maintenance materials in Xinzhizao self-study tutorials and mobile phone tutorials,

26

00:01:42,633 --> 00:01:46,366

including iPhone's forced DFU signal and test points

27

00:01:52,866 --> 00:01:56,300

Let me take the iPhone7 model as an example to demonstrate

28

00:01:57,433 --> 00:02:01,266

We first find the forced DFU test point of iPhone 7

29

00:02:04,833 --> 00:02:08,300

This is the forced DFU signal point name of iPhone 7,

30

00:02:08,766 --> 00:02:11,200

we can also query it through the drawing

31

00:02:12,033 --> 00:02:15,933

This is the forced DFU test point name for Apple models

32

00:02:24,033 --> 00:02:27,600

The test point for the iPhone 7 has a small dot on the mainboard

33

00:02:29,333 --> 00:02:33,433

We need to connect it to a 1.8V or 3V power supply

34

00:02:34,033 --> 00:02:36,566

We need to use bitmap to find the voltage

35

00:02:39,700 --> 00:02:44,933

Open the bitmap of the iPhone 7 and find the corresponding forced DFU test point

36

00:02:45,466 --> 00:02:49,533

Let's see if there is a 3V or 1.8V power supply near it

37

00:02:50,200 --> 00:02:53,466

There is a 3V photosensitive power supply here

38

00:02:55,900 --> 00:03:00,100

At this time, we can short the test point and this end of the capacitor

39

00:03:00,733 --> 00:03:05,633

After shorting, then plug in the data cable, we can enter the DFU mode

40

00:03:06,400 --> 00:03:07,700

Let me demonstrate

41

00:03:09,066 --> 00:03:14,400

We short-circuit the test point of the forced DFU and the photosensitive capacitor next to it

42

00:03:17,000 --> 00:03:18,000

we have shorted

43

00:03:22,233 --> 00:03:23,600

Let's test it next

44

00:03:24,900 --> 00:03:27,033

First open the flashing software,

45

00:03:27,933 --> 00:03:30,066

plug the data cable into the computer

46

00:03:31,400 --> 00:03:33,133

When the mobile phone is turned off,

47

00:03:33,500 --> 00:03:36,933

connect the adjustable power supply and insert the data cable

48

00:03:38,600 --> 00:03:43,000

The computer can quickly recognize that the phone has entered DFU mode

49

00:03:45,100 --> 00:03:46,966

After entering the DFU mode,

50

00:03:47,100 --> 00:03:49,466

the screen will not display the picture

51

00:03:50,433 --> 00:03:55,300

If we go to flash the machine at this time, there may be an error reporting problem,

52

00:03:55,900 --> 00:03:59,866

we need to disconnect the connection cable before flashing the machine

53

00:04:00,366 --> 00:04:04,333

Because it is more troublesome to disconnect the flying wires later,

54

00:04:05,133 --> 00:04:07,833

I am used to using tweezers to short-circuit them

55

00:04:08,466 --> 00:04:12,900

After entering the mode, release the tweezers and you can flash the phone

56

00:04:13,433 --> 00:04:16,000

Why disconnect the line of forced DFU?

57

00:04:16,866 --> 00:04:21,833

Because a good machine will also report an error when forcing DFU to flash the machine

58

00:04:22,300 --> 00:04:26,266

After we disconnect, if the error is reported again after flashing,

59

00:04:26,433 --> 00:04:29,333

we can repair according to the error code of flashing

60

00:04:29,766 --> 00:04:31,666

So, that's all for this video
