1

00:00:00,433 --> 00:00:04,533

The maintenance of iPhone startup constant current and current jump faults

2

00:00:04,966 --> 00:00:09,533

In this lesson, we mainly explain how to connect an iPhone to a computer

3

00:00:10,033 --> 00:00:12,766

There are two ways to connect your phone to your computer

4

00:00:13,366 --> 00:00:17,333

The first method is to plug in the data cable after the mobile phone is turned on,

5

00:00:17,733 --> 00:00:21,933

click trust on the screen, and enter the password to connect to the computer

6

00:00:22,333 --> 00:00:24,933

The second method is to enter the flash mode

7

00:00:25,333 --> 00:00:27,166

There are two Apple flashing modes,

8

00:00:27,766 --> 00:00:29,600

recovery mode and DFU mode

9

00:00:31,866 --> 00:00:35,600

Only after entering the flashing mode, we plug in the data cable,

10

00:00:35,666 --> 00:00:37,800

can the computer recognize the mobile phone

11

00:00:38,133 --> 00:00:41,266

If the mobile phone has a constant current when it is turned on,

12

00:00:41,433 --> 00:00:46,000

current jumps, stuck white apple or white apple restart, etc.,

13

00:00:47,266 --> 00:00:49,100

after plugging in the data cable,

14

00:00:49,366 --> 00:00:51,866

the computer cannot recognize the mobile phone.

15

00:00:52,066 --> 00:00:56,466

So at this time, if we want to see the error report of the flash machine,

16

00:00:56,600 --> 00:00:59,566

we need to enter the recovery mode or DFU mode

17

00:01:00,666 --> 00:01:04,366

If the current of the mainboard is within 200mA after booting,

18

00:01:04,533 --> 00:01:08,733

we may not be able to enter the flashing mode through method 1 and method 2

19

00:01:09,166 --> 00:01:11,833

We need to use method 3 and method 4

20

00:01:13,100 --> 00:01:16,066

If none of the above three methods can enter,

21

00:01:16,633 --> 00:01:19,433

then we need to remove the hard disk on the mainboard

22

00:01:20,600 --> 00:01:25,300

After removing it, plug in the data cable to see if it can be connected

23

00:01:25,833 --> 00:01:31,200

Apple's full range of models will automatically enter DFU mode after removing the hard disk

24

00:01:31,600 --> 00:01:34,533

And the boot current is set at about 50mA

25

00:01:35,600 --> 00:01:38,633

Let's take the iPhone 7 as an example to illustrate

26

00:01:38,833 --> 00:01:41,366

If you can't get in through the above methods,

27

00:01:41,766 --> 00:01:43,366

you need to remove the hard disk

28

00:01:45,133 --> 00:01:48,766

After removing the hard drive, let's connect to the computer again

29

00:01:53,533 --> 00:01:56,500

The mainboard is connected to an adjustable power supply,

30

00:02:00,700 --> 00:02:04,466

and we plug in the data cable, and the current does not jump,

31

00:02:04,700 --> 00:02:06,466

which is an individual case

32

00:02:08,066 --> 00:02:10,333

Because in 90% of cases,

33

00:02:10,433 --> 00:02:13,666

the iPhone will be turned on after plugging in the data cable

34

00:02:14,466 --> 00:02:17,300

There is no current after we plug in the data cable,

35

00:02:17,566 --> 00:02:19,533

we need to press the switch first

36

00:02:22,866 --> 00:02:25,700

The current will be set at about 50mA,

37

00:02:27,533 --> 00:02:30,066

we will plug in the data cable at this time

38

00:02:31,933 --> 00:02:35,500

The computer will show that it has entered the DFU mode,

39

00:02:36,466 --> 00:02:38,433

and we can go to flash the machine

40

00:02:38,933 --> 00:02:41,500

After removing the hard disk from the mainboard,

41

00:02:41,733 --> 00:02:44,966

the progress can be refreshed to about 20%.

42

00:02:45,600 --> 00:02:50,933

If we only brush to 11% or 19% in the process of flashing

43

00:02:51,600 --> 00:02:55,233

At this time, we can also repair according to the error code

44

00:02:55,700 --> 00:02:59,700

If after we remove the hard disk, the computer is still not connected,

45

00:03:00,066 --> 00:03:03,900

it may be that there is a problem with the connection circuit of the mainboard

46

00:03:04,366 --> 00:03:06,866

and we need to repair the connection circuit

47

00:03:12,300 --> 00:03:17,133

If the iPhone cannot be connected to the computer after the connection circuit is repaired,

48

00:03:17,333 --> 00:03:19,366

there may be a problem with the CPU

49

00:03:20,800 --> 00:03:22,733

Ok, that's all for this video
