1

00:00:00,600 --> 00:00:04,833

The maintenance of iPhone startup constant current and current jump faults

2

00:00:05,100 --> 00:00:09,400

In this lesson, we mainly learn how to flash the phone with Aisi Assistant,

3

00:00:09,566 --> 00:00:12,500

and how to check the error codes when flashing the phone

4

00:00:12,966 --> 00:00:15,566

Aisi flashing error viewing method

5

00:00:16,200 --> 00:00:20,566

When iTunes flashes, it will report a numerical error

6

00:00:21,100 --> 00:00:24,366

For Aisi, we usually look at the flashing progress

7

00:00:25,133 --> 00:00:29,633

Different progress errors, maintenance methods are also different

8

00:00:31,766 --> 00:00:36,200

Next, let's take a look at the process of flashing the phone with Aisi Assistant

9

00:00:37,333 --> 00:00:39,600

When the mobile phone enters the flash mode,

10

00:00:40,466 --> 00:00:45,133

the computer can recognize that it has entered the recovery mode or DFU mode

11

00:00:47,666 --> 00:00:52,400

Whether it is recovery mode or DFU mode, we can all flash the phone

12

00:00:52,700 --> 00:00:54,666

Let's flash the machine next

13

00:00:57,266 --> 00:00:59,333

After the computer can recognize it,

14

00:00:59,600 --> 00:01:02,333

we download the system of the corresponding model

15

00:01:03,300 --> 00:01:06,900

I have already downloaded this, we can directly flash it

16

00:01:07,566 --> 00:01:11,700

When flashing, there is one-key flashing, iTunes flashing,

17

00:01:12,066 --> 00:01:15,100

professional flashing, and batch flashing

18

00:01:15,233 --> 00:01:17,466

We can choose different flashing modes

19

00:01:19,566 --> 00:01:24,600

In actual maintenance, some Apple machines cannot be flashed with Aisi Assistant,

20

00:01:24,733 --> 00:01:26,666

but can be flashed with iTunes

21

00:01:27,400 --> 00:01:32,100

Some cannot be flashed with iTunes, but they can be flashed with Aisi

22

00:01:32,633 --> 00:01:34,966

Like this kind of flashing software,

23

00:01:35,166 --> 00:01:39,533

we can't flash it out of date, so we can exchange software to try it out

24

00:01:40,633 --> 00:01:44,466

Under normal circumstances, we choose one-click flashing

25

00:01:44,700 --> 00:01:46,400

When we choose one-key flashing,

26

00:01:46,500 --> 00:01:48,466

there will be several options below,

27

00:01:48,866 --> 00:01:52,766

including retain user data, regular fast flashing,

28

00:01:53,066 --> 00:01:56,466

anti-data recovery flashing, and repair flashing

29

00:01:57,033 --> 00:01:58,266

Keep user data,

30

00:01:58,466 --> 00:02:01,666

that is, the data in the hard disk will not be erased

31

00:02:02,466 --> 00:02:06,433

In this case, if you flash the machine with a normal machine,

32

00:02:06,566 --> 00:02:08,533

there is generally no problem

33

00:02:09,566 --> 00:02:14,166

If it is a faulty machine, if you want to keep the user data and flash the machine,

34

00:02:14,433 --> 00:02:17,066

most of them will fail to flash the machine

35

00:02:17,400 --> 00:02:20,700

If the machine fails, the data cannot be saved

36

00:02:21,100 --> 00:02:25,933

Repair flashing means that when the mobile phone data is full and there is no space,

37

00:02:27,000 --> 00:02:31,400

it may cause the boot stuck to white apple, or the white apple to restart

38

00:02:32,066 --> 00:02:34,800

But if we want to keep the data of the mobile phone,

39

00:02:35,300 --> 00:02:37,433

we can try to use the repair flashing

40

00:02:38,400 --> 00:02:42,400

This kind of flash mode can't guarantee 100% no problem

41

00:02:42,800 --> 00:02:47,766

To prevent data recovery, it is to erase all the data in the hard disk

42

00:02:48,533 --> 00:02:52,933

Under normal circumstances, we will choose the conventional quick flash

43

00:02:53,100 --> 00:02:55,633

When flashing, there is a prompt message

44

00:02:56,233 --> 00:02:58,800

If the mobile phone is bound with an Apple ID,

45

00:02:59,100 --> 00:03:02,566

we need to prepare the account and password of the Apple ID

46

00:03:03,000 --> 00:03:05,933

If the account number and password are forgotten,

47

00:03:06,133 --> 00:03:09,466

even if the machine is flashed, it cannot be used

48

00:03:10,566 --> 00:03:12,100

Okay, let me demonstrate

49

00:03:13,133 --> 00:03:15,400

We click to refresh immediately,

50

00:03:16,966 --> 00:03:21,033

there will be a reminder message asking if you want to keep the data

51

00:03:21,033 --> 00:03:23,933

and if you want to fix the battery health problem

52

00:03:28,166 --> 00:03:31,033

We can choose yes or no, it doesn't matter

53

00:03:35,400 --> 00:03:39,166

If the data is important to the customer, we can back it up first

54

00:03:41,266 --> 00:03:45,800

But like this kind of machine, it cannot be backed up without turning on

55

00:03:46,000 --> 00:03:48,100

So we choose to flash directly

56

00:03:50,400 --> 00:03:53,633

We can see the progress bar when we're flashing with Aisi assistant

57

00:03:54,000 --> 00:03:58,066

On the side, we can also see Toggle Diagnostic Mode

58

00:03:58,166 --> 00:04:00,500

After switching between different modes,

59

00:04:00,933 --> 00:04:03,000

we will see the steps of flashing

60

00:04:12,866 --> 00:04:17,366

When it is flashing to 20%, there will be a progress bar on the screen

61

00:04:18,100 --> 00:04:20,933

If the progress bar is black and has passed through,

62

00:04:21,033 --> 00:04:23,133

there will be no data in the phone

63

00:04:31,733 --> 00:04:37,566

21% to 60%, it is usually writing system files to the hard disk

64

00:04:38,733 --> 00:04:43,233

If there is a problem with this process, it is generally a hard disk failure

65

00:04:44,333 --> 00:04:47,166

If it is still not normal after replacing the hard disk,

66

00:04:47,466 --> 00:04:49,533

there may be a problem with the CPU

67

00:04:51,133 --> 00:04:55,766

During the flashing process, we also need to observe the text under the progress

68

00:04:56,600 --> 00:05:01,566

The file system is being written, and data is still written to the hard disk at this time

69

00:05:07,266 --> 00:05:08,666

flashing firmware

70

00:05:09,033 --> 00:05:11,900

Flashing the firmware is flashing the baseband part

71

00:05:15,633 --> 00:05:18,433

Now the progress has reached 80%

72

00:05:19,466 --> 00:05:21,000

Sending baseband

73

00:05:22,433 --> 00:05:27,300

After it reaches to 80%, the system key bag is being established,

74

00:05:27,666 --> 00:05:30,233

basically the machine can be used normally

75

00:05:30,466 --> 00:05:35,266

During the flashing process, as long as the flashing is not 100%,

76

00:05:35,866 --> 00:05:40,066

after the machine is powered off, the next time it is turned on,

77

00:05:40,933 --> 00:05:45,400

it will be in a constant current state, and the machine will not be turned on

78

00:05:47,933 --> 00:05:49,800

Ok, flashing is complete

79

00:05:50,300 --> 00:05:52,233

After the flashing is completed,

80

00:05:52,433 --> 00:05:57,266

the phone will enter the progress bar again, which takes about 5 minutes

81

00:06:00,500 --> 00:06:06,033

After the progress bar is finished, the computer can recognize the information of the mobile phone,

82

00:06:06,600 --> 00:06:09,533

which belongs to the flashing state of a normal machine

83

00:06:10,300 --> 00:06:12,433

Ok, that's all for this video
