1

00:00:00,600 --> 00:00:04,400

The maintenance of iPhone startup constant current and current jump faults

2

00:00:04,866 --> 00:00:09,200

In this lesson, we mainly learn how to flash the phone with Aisi Assistant,

3

00:00:09,366 --> 00:00:12,300

and how to check the error codes when flashing the phone

4

00:00:12,766 --> 00:00:15,166

Aisi flashing error viewing method

5

00:00:16,000 --> 00:00:19,700

When iTunes flashes, it will report a numerical error

6

00:00:20,900 --> 00:00:24,566

For Aisi, we usually look at the flashing progress

7

00:00:25,233 --> 00:00:29,533

Different progress errors, maintenance methods are also different

8

00:00:31,733 --> 00:00:36,866

Below we take this faulty iPhone 7 as an example, refresh the machine to check

9

00:00:37,200 --> 00:00:41,433

After the mobile phone enters the flashing mode, we first connect to the computer,

10

00:00:41,700 --> 00:00:47,000

and the Aisi software will automatically recognize that the mobile phone has entered the DFU mode

11

00:00:48,066 --> 00:00:52,566

We click on the flashing page, you can choose to download the system of this model

12

00:00:57,066 --> 00:00:58,966

Now the system has been downloaded

13

00:01:01,466 --> 00:01:03,266

We choose one-click flashing,

14

00:01:04,433 --> 00:01:06,233

choose to flash immediately,

15

00:01:06,366 --> 00:01:08,233

and choose to confirm flashing

16

00:01:09,300 --> 00:01:12,233

At this point it will go into the progress bar

17

00:01:13,033 --> 00:01:15,900

According to the different positions of the progress bar,

18

00:01:16,433 --> 00:01:20,833

the error is reported, and we can repair it according to the error code

19

00:01:22,933 --> 00:01:25,600

The progress has been flashed to 16%

20

00:01:25,966 --> 00:01:30,200

At this time, the Apple logo will be displayed on the screen

21

00:01:38,033 --> 00:01:42,933

After flashing to 18%, normally it should enter normal mode

22

00:01:43,266 --> 00:01:47,433

But at this time, it shows that it has entered DFU mode,

23

00:01:47,933 --> 00:01:50,233

which belongs to the unlimited DFU

24

00:01:52,033 --> 00:01:57,100

In the case of unlimited DFU, we also repair according to the error code of flashing

25

00:01:59,200 --> 00:02:02,466

19%, it reports an error

26

00:02:02,833 --> 00:02:06,800

At this time, we can check the problem according to the error codes

27

00:02:07,066 --> 00:02:12,133

We open the error code table, when Aisi reports an error at 19%,

28

00:02:12,700 --> 00:02:18,666

it is caused by the I2C bus, hard disk, CPU, and power supply inductor

29

00:02:20,500 --> 00:02:23,833

It is the same as the iTunes error 4014

30

00:02:28,133 --> 00:02:32,333

We learned in previous lessons how to find and measure the I2C bus

31

00:02:33,633 --> 00:02:38,966

CPU working conditions are CPU power supply, clock signal and reset signal

32

00:02:39,733 --> 00:02:42,533

If the working conditions of the CPU are normal

33

00:02:44,200 --> 00:02:49,966

At this time, we only need to replace the power supply inductor of the CPU and the hard disk

34

00:02:50,400 --> 00:02:52,800

If it is still not normal after replacement,

35

00:02:52,966 --> 00:02:56,600

it may be a CPU problem or a board layer problem

36

00:02:56,933 --> 00:03:00,033

We need to replace the CPU with a new bottom of the board

37

00:03:02,000 --> 00:03:06,033

If the error is still reported, it means that the CPU is damaged

38

00:03:08,033 --> 00:03:09,966

Ok, that's it for this lesson
