Usage of multimeter

2

00:00:02,433 --> 00:00:06,400

In this video, we mainly explain the functions of the multimeters

3

00:00:07,066 --> 00:00:12,900

Let's take the commonly used manual range multimeter VC890D as an example to explain

4

00:00:13,533 --> 00:00:16,566

The top position is the sound alarm indicator light

5

00:00:18,033 --> 00:00:21,166

For example, when measuring the connection of the line,

6

00:00:21,566 --> 00:00:25,533

there will be a sound of wind, and the sound is emitted from this position

7

00:00:28,733 --> 00:00:31,333

Below the indicator light is a display screen,

8

00:00:31,766 --> 00:00:35,400

which will display the measured voltage, value, etc.

9

00:00:38,966 --> 00:00:41,366

Below the display screen is the triode jack,

10

00:00:42,700 --> 00:00:45,566

the main function is to judge the polarity of the triode

11

00:00:47,533 --> 00:00:51,800

Data hold backlit function key, which is a 3-in-1 button

12

00:00:53,600 --> 00:00:56,666

When measuring, the measured value can be locked,

13

00:00:57,933 --> 00:00:59,533

the screen can be lit,

14

00:00:59,833 --> 00:01:03,166

and it can also be used to switch between different ranges

15

00:01:04,466 --> 00:01:06,400

The mark F is the capacitor range,

16

00:01:08,200 --> 00:01:11,900

which is specially used to measure the capacitance value of the capacitor,

17

00:01:12,733 --> 00:01:15,433

and can judge whether the capacitor is good or bad

18

00:01:15,733 --> 00:01:18,566

The resistance range is marked with the symbol of ohm,

19

00:01:19,200 --> 00:01:22,366

which is specially used to measure the quality of the resistor

20

00:01:24,866 --> 00:01:28,400

Diode/ buzzer range, this is a two-in-one range

21

00:01:29,433 --> 00:01:33,533

But in some multimeters, these two ranges are separated

22

00:01:33,933 --> 00:01:37,733

When measuring the connection of the line, use the buzzer range;

23

00:01:38,633 --> 00:01:42,800

when measuring the quality of the component or measuring the value of the diode,

24

00:01:43,033 --> 00:01:44,333

use the diode range

25

00:01:45,166 --> 00:01:46,566

AC current range,

26

00:01:47,000 --> 00:01:49,766

which is specially used to measure AC current,

27

00:01:52,433 --> 00:01:55,966

the range ranges from 20mA to 20A

28

00:01:58,366 --> 00:01:59,733

DC current range,

29

00:02:00,233 --> 00:02:02,766

which is specially used to measure DC current,

30

00:02:04,833 --> 00:02:08,900

the measurement range is from 200uA to 20A

31

00:02:14,066 --> 00:02:15,733

The switch mark is OFF

32

00:02:17,000 --> 00:02:21,200

When the button is rotated to OFF, the multimeter is turned off

33

00:02:27,000 --> 00:02:28,866

Flashlight switch button,

34

00:02:29,200 --> 00:02:32,566

VC890D integrates the flashlight function

35

00:02:33,033 --> 00:02:36,633

When we turn it on, the flashlight on the back turns on

36

00:02:37,366 --> 00:02:39,866

The triode mark HFE,

37

00:02:40,800 --> 00:02:44,966

this range should be used in conjunction with the upper triode socket,

38

00:02:45,766 --> 00:02:48,833

it is specially used to judge the polarity of the triode

39

00:02:49,233 --> 00:02:52,666

The DC voltage range is used to measure DC voltage,

40

00:02:54,133 --> 00:02:58,733

and the measurement range is from 200mV to 1,000V

41

00:02:59,800 --> 00:03:01,500

The range selection knob,

42

00:03:02,600 --> 00:03:04,833

which range the arrow is pointing at,

43

00:03:05,533 --> 00:03:08,133

indicating which range is currently adjusted

44

00:03:08,800 --> 00:03:10,333

AC voltage range,

45

00:03:10,566 --> 00:03:13,033

specially used to measure AC voltage,

46

00:03:14,400 --> 00:03:18,833

its measurement range is from 2V to 750V

47

00:03:19,833 --> 00:03:23,366

For example, when we measure domestic sockets,

48

00:03:23,800 --> 00:03:27,166

we need to adjust to the range of 750V

49

00:03:28,566 --> 00:03:31,533

Voltage sensing range NCV

50

00:03:32,166 --> 00:03:36,933

Turn the multimeter to the NCV position, and the top is close to the power line

51

00:03:37,800 --> 00:03:39,800

If the power line has power supply,

52

00:03:40,866 --> 00:03:44,100

the multimeter will emit a beep alarm sound

53

00:03:45,133 --> 00:03:46,566

Here are the test jacks

54

00:03:49,033 --> 00:03:52,666

When we use different functions, we need to choose different jacks

55

00:03:55,433 --> 00:03:57,500

The black jack is the public port,

56

00:03:58,633 --> 00:04:02,633

after the black marker is inserted, there is no need to move it

57

00:04:03,800 --> 00:04:08,533

When measuring voltage, insert the red marker into the ohm identification jack

58

00:04:11,266 --> 00:04:13,600

The two jacks on the left are current jacks,

59

00:04:15,100 --> 00:04:19,366

and the red markers need to be inserted into the jacks when measuring the current

60

00:04:21,366 --> 00:04:23,400

Ok, that's it for this lesson
