Usage of multimeter

2

00:00:02,733 --> 00:00:06,600

In this lesson we mainly learn how to measure circuit board voltage

3

00:00:09,366 --> 00:00:12,900

Measuring voltage is an essential maintenance step in maintenance,

4

00:00:14,933 --> 00:00:18,533

we can judge whether the line is normal according to the voltage value

5

00:00:20,366 --> 00:00:25,400

When repairing the mainboard of the mobile phone, the voltage of the mainboard is DC

6

00:00:25,933 --> 00:00:27,866

Method of Measuring DC Voltage

7

00:00:28,666 --> 00:00:33,566

In the first step, the black marker of the multimeter is inserted into the public port,

8

00:00:34,166 --> 00:00:38,900

and the red marker is inserted into the red socket marked by the voltage resistance

9

00:00:41,266 --> 00:00:45,133

The second step is to adjust the multimeter to the DC voltage range

10

00:00:46,100 --> 00:00:51,100

If it is a manual range multimeter, we need to choose the 20V DC voltage range,

11

00:00:52,700 --> 00:00:55,833

because the power supply of the mobile phone is 4.2V

12

00:00:56,100 --> 00:01:00,466

If it is in the 2V position, the voltage value cannot be measured

13

00:01:01,266 --> 00:01:04,300

The mainboard needs to be powered on when measuring the voltage,

14

00:01:06,100 --> 00:01:10,166

and some power supplies need to be triggered to start up when measuring the voltage

15

00:01:12,666 --> 00:01:16,900

After measurement, the value displayed on the screen is the voltage value

16

00:01:18,100 --> 00:01:19,766

Precautions when measuring

17

00:01:20,066 --> 00:01:23,533

When measuring the voltage, the mainboard must be powered on

18

00:01:24,333 --> 00:01:28,066

If it is a manual range multimeter, select the appropriate range,

19

00:01:28,233 --> 00:01:31,900

and the range should be greater than the voltage of the point to be measured

20

00:01:32,366 --> 00:01:35,266

When measuring, the markers cannot be reversed.

21

00:01:35,466 --> 00:01:40,166

After the reverse connection, there will be a minus sign in front of the measured voltage,

22

00:01:40,266 --> 00:01:42,600

which is generally called negative voltage

23

00:01:43,033 --> 00:01:45,100

There is a negative voltage in the mobile phone,

24

00:01:46,533 --> 00:01:50,566

and the measurement after reverse connection may lead to misjudgment

25

00:01:52,500 --> 00:01:55,066

Let's measure it in the physical mainboard

26

00:01:57,166 --> 00:02:00,333

First, we insert the black marker into the COM port,

27

00:02:00,766 --> 00:02:03,200

and the red marker into the V red port

28

00:02:07,433 --> 00:02:10,500

The multimeter is adjusted to the DC voltage range,

29

00:02:11,800 --> 00:02:16,233

and the mainboard needs to be powered on when measuring, or trigger the power on

30

00:02:19,566 --> 00:02:22,933

After we trigger the switch, the black marker is grounded,

31

00:02:24,000 --> 00:02:26,566

such as a metal shell or a screw post,

32

00:02:27,333 --> 00:02:29,433

and then the red marker is used to measure

33

00:02:30,166 --> 00:02:34,100

At this time we can see that the voltage value is about 1.2V

34

00:02:35,500 --> 00:02:40,633

After changing the measurement point, we can see that the voltage is about 0.8V

35

00:02:41,100 --> 00:02:44,800

If the red marker is grounded, the black marker is used to measure

36

00:02:46,600 --> 00:02:50,933

We can see that the display will show about -4.2V

37

00:02:53,166 --> 00:02:57,666

The 1.2V power supply measured just now supplies power to the hard disk

38

00:02:58,266 --> 00:03:03,033

If the voltage is lower than 1.2V or higher than 1.2V,

39

00:03:03,200 --> 00:03:05,766

it means that there is a problem with the power supply

40

00:03:06,133 --> 00:03:08,133

That's all for this video
