150. Viewing method of location diagram
In this lesson, we mainly learn how to view the location diagram.
Detail
Comments

1

00:00:00,500 --> 00:00:02,500

Usage of location diagram

2

00:00:03,100 --> 00:00:07,100

In this lesson, we mainly learn how to view the location diagram

3

00:00:08,400 --> 00:00:11,766

The location diagram is consistent with the physical diagram,

4

00:00:11,933 --> 00:00:15,100

and each component in the location diagram has a number

5

00:00:16,866 --> 00:00:20,966

In the location diagram, the components correspond to the real object,

6

00:00:21,566 --> 00:00:25,166

and in the location diagram, the component numbers are unique

7

00:00:27,233 --> 00:00:29,400

For example, CPU chip,

8

00:00:30,000 --> 00:00:33,366

the number in the location diagram is U1000

9

00:00:34,766 --> 00:00:38,866

The location diagram is also called the component distribution diagram,

10

00:00:39,000 --> 00:00:41,533

component diagram, bit number diagram,

11

00:00:41,833 --> 00:00:43,966

board location diagram, etc.,

12

00:00:44,700 --> 00:00:46,066

they are all the same

13

00:00:48,866 --> 00:00:50,900

How to view the location diagram

14

00:00:51,966 --> 00:00:53,266

Component numbers

15

00:00:53,533 --> 00:00:58,133

The numbers of the different components in the location diagram are also different

16

00:00:58,733 --> 00:01:03,133

In the location diagram, letter U represents the integrated chip,

17

00:01:04,033 --> 00:01:09,766

for example, U2700 and U1000 both represent the integrated chip

18

00:01:10,533 --> 00:01:12,833

J stands for the connection socket

19

00:01:13,000 --> 00:01:18,533

In Android models, some connection sockets are identified by P or CN

20

00:01:19,866 --> 00:01:23,633

R stands for resistor, C stands for capacitor

21

00:01:27,000 --> 00:01:32,400

L/ FL stands for inductor, D/ DZ stands for diode

22

00:01:35,400 --> 00:01:41,266

Q stands for MOS tube, and in some circuit diagrams, Q also stands for triode

23

00:01:43,266 --> 00:01:47,266

Because in the mobile phone, the transistors are all integrated,

24

00:01:47,466 --> 00:01:50,000

so Q only represents the MOS tube

25

00:01:51,100 --> 00:01:54,466

In addition to numbering each component in the location diagram,

26

00:01:54,733 --> 00:01:56,933

there are some other identifications

27

00:01:58,500 --> 00:02:02,133

In Apple models, red dots, red squares,

28

00:02:02,233 --> 00:02:05,433

or stars represent the orientation of components

29

00:02:08,100 --> 00:02:12,566

In the physical picture, we can see that each component will have a small dot,

30

00:02:13,066 --> 00:02:15,466

which represents the direction of the chip

31

00:02:18,533 --> 00:02:21,266

When welding, if we forget the direction,

32

00:02:21,666 --> 00:02:26,533

we can open the location diagram, check the corresponding red mark or dot,

33

00:02:26,933 --> 00:02:29,433

find the direction, and start welding

34

00:02:32,733 --> 00:02:37,000

In Huawei mobile phones, slashes are used on components,

35

00:02:37,933 --> 00:02:40,733

and dots represent the direction of components

36

00:02:41,333 --> 00:02:44,900

In OPPO mobile phones, there are some component marks

37

00:02:46,200 --> 00:02:49,933

Some models use black right angles, black dots,

38

00:02:50,000 --> 00:02:54,700

slashes, dots, or black triangles in the location diagram

39

00:02:56,666 --> 00:02:59,433

These marks represent the chip directions

40

00:03:01,500 --> 00:03:02,566

Summarize

41

00:03:02,833 --> 00:03:06,900

Regardless of whether it is an Apple model or an Android model,

42

00:03:07,100 --> 00:03:11,333

the markings in the chip location diagram represent the direction of the chip

43

00:03:13,133 --> 00:03:15,766

When welding, if we forget the direction,

44

00:03:16,133 --> 00:03:19,900

we can weld according to the component direction of the location diagram

45

00:03:20,366 --> 00:03:22,300

Ok, that's all for this video
