1

00:00:00,666 --> 00:00:02,566

How to use the location diagram

2

00:00:03,333 --> 00:00:07,766

In this lesson we learn how to view the location diagram in different models

3

00:00:09,666 --> 00:00:12,533

Let's first look at the location diagram of the iPhone

4

00:00:13,166 --> 00:00:17,700

First open the location diagram of iPhone 11, and the physical scan map

5

00:00:19,600 --> 00:00:24,166

The mainboard of the iPhone 11 is a double-layer mainboard with components on three sides

6

00:00:26,400 --> 00:00:29,666

The location diagram will mark the information of each side,

7

00:00:30,066 --> 00:00:32,566

even the side without components will be marked

8

00:00:36,833 --> 00:00:39,033

After zooming in on the location diagram,

9

00:00:39,500 --> 00:00:42,166

we can see that there are numbers on each component,

10

00:00:42,866 --> 00:00:45,733

and different numbers represent different components

11

00:00:48,300 --> 00:00:51,900

C stands for capacitor and L stands for inductor

12

00:00:53,600 --> 00:00:56,766

R stands for resistor, and U stands for chip

13

00:00:58,566 --> 00:01:02,766

The number of each component will correspond to the component in the physical drawing

14

00:01:05,533 --> 00:01:10,166

In the iPhone 11 location diagram, some chips will have an asterisk mark,

15

00:01:10,800 --> 00:01:13,166

representing the direction of welding

16

00:01:18,100 --> 00:01:21,766

In the physical picture, there will also be a dot mark on the chip

17

00:01:24,533 --> 00:01:28,433

In maintenance, if we forget the direction of the components,

18

00:01:28,833 --> 00:01:32,433

we can weld according to the direction marked on the location diagram

19

00:01:33,566 --> 00:01:35,766

Let's check Huawei's location diagram

20

00:01:36,833 --> 00:01:41,933

Open the location diagram of P40 pro+ and zoom in on the location diagram

21

00:01:42,600 --> 00:01:46,266

We can see the number of small components and the number of the chip,

22

00:01:47,000 --> 00:01:50,100

which is the same as the location diagram of the iPhone

23

00:01:52,033 --> 00:01:56,633

But the direction of the chip, it's marked with a bevel, not an asterisk

24

00:01:59,066 --> 00:02:01,966

Some components are marked with small white circles,

25

00:02:02,800 --> 00:02:05,466

which all represent the direction of the components

26

00:02:08,633 --> 00:02:12,033

Let's open the location diagram of OPPO R15S

27

00:02:14,133 --> 00:02:18,233

After zooming in, we can also see the numbers of small components

28

00:02:20,433 --> 00:02:23,700

In this location diagram, the direction of the chip,

29

00:02:23,900 --> 00:02:26,366

it will be marked with bevels and circles

30

00:02:33,300 --> 00:02:35,933

In the location diagram below the R15S,

31

00:02:37,300 --> 00:02:42,300

you can also see its direction mark, with black circles and triangle symbols

32

00:02:48,433 --> 00:02:51,200

Let's take a look at the location diagram of Vivo

33

00:02:51,866 --> 00:02:55,133

Let's open the location diagram of Y91S

34

00:02:56,300 --> 00:03:00,133

After zooming in, we can see that the component numbers are the same,

35

00:03:00,633 --> 00:03:02,766

and the chip numbers are also the same

36

00:03:05,300 --> 00:03:09,266

The direction of Vivo's chip will be marked with a bevel and a small circle

37

00:03:11,533 --> 00:03:14,700

Now let's open the location diagram of Xiaomi 10 PRO

38

00:03:20,533 --> 00:03:24,733

We can see that the serial numbers of small components and chips are the same

39

00:03:28,200 --> 00:03:32,833

In this location diagram, the direction of the component is marked with a triangle,

40

00:03:33,533 --> 00:03:36,233

and a vertical line is drawn inside the triangle,

41

00:03:37,100 --> 00:03:39,966

which is a little different from the previous models

42

00:03:42,433 --> 00:03:45,266

The location diagrams of the above models,

43

00:03:45,700 --> 00:03:48,000

the direction marks of the chips are similar

44

00:03:50,166 --> 00:03:52,100

Ok, that's all for this video
