1

00:00:00,766 --> 00:00:02,066

How to use bitmap

2

00:00:02,933 --> 00:00:07,366

In this video, we mainly learn the meaning of colors and marks in the bitmap

3

00:00:09,666 --> 00:00:12,900

The mobile phone bitmap is made by combining the physical map,

4

00:00:13,066 --> 00:00:15,366

circuit diagram and location diagram

5

00:00:16,866 --> 00:00:20,333

The bitmap has the outline structure of the physical diagram,

6

00:00:20,833 --> 00:00:23,233

the component number of the location diagram,

7

00:00:23,633 --> 00:00:28,700

the signal names and pin coordinates in the circuit diagram and other informations

8

00:00:30,866 --> 00:00:34,200

The bitmap has the characteristic of simple search signal,

9

00:00:34,333 --> 00:00:36,633

convenient and easy to understand,

10

00:00:37,033 --> 00:00:41,466

and is an indispensable auxiliary maintenance software for maintenance personnel

11

00:00:42,500 --> 00:00:47,166

Different default colors or marks in the bitmap represent different meanings

12

00:00:49,500 --> 00:00:51,866

Red represents a useful signal,

13

00:00:52,866 --> 00:00:56,400

indicating that the solder point may be a power supply or a signal

14

00:00:57,766 --> 00:01:02,233

If the red solder point falls off during soldering, we need to refill it

15

00:01:03,566 --> 00:01:06,666

The gray dot in the bitmap represents the ground wire,

16

00:01:08,266 --> 00:01:10,766

and the ground wires are connected in the bitmap

17

00:01:12,066 --> 00:01:15,266

The blue solder points in the bitmap represent idle spots,

18

00:01:15,400 --> 00:01:17,966

indicating that this line is not used

19

00:01:18,400 --> 00:01:21,966

If the solder points fall off, we do not need to deal with them

20

00:01:22,600 --> 00:01:25,033

Let's understand the different marks in the bitmap

21

00:01:26,266 --> 00:01:30,833

In the bitmap, the number above the red solder point represents the diode value,

22

00:01:31,166 --> 00:01:34,200

which can be used as a reference value during measurement

23

00:01:34,733 --> 00:01:37,400

The red solder point will be marked in English,

24

00:01:38,600 --> 00:01:41,266

which is the same as the English mark in the drawing,

25

00:01:42,433 --> 00:01:45,233

representing the signal meaning of the solder point

26

00:01:53,566 --> 00:01:57,400

Letters and numbers will be marked above the solder points in the bitmap,

27

00:01:59,700 --> 00:02:02,533

and the letters and numbers are relatively large,

28

00:02:03,100 --> 00:02:06,566

and the identification is the coordinates of the solder points

29

00:02:12,200 --> 00:02:15,766

Most of the BGA chip pins are identified by coordinates,

30

00:02:16,033 --> 00:02:20,400

and the combination of numbers and letters represents the pin of the BGA chip

31

00:02:21,000 --> 00:02:24,866

In the bitmap, there will be a double-line mark at the edge of the chip,

32

00:02:25,000 --> 00:02:26,933

it represents the direction of the chip

33

00:02:27,400 --> 00:02:31,900

Same meaning as an asterisk or a small red dot in the location diagram

34

00:02:37,233 --> 00:02:40,766

The mark starting with U in the middle of the chip is the position number,

35

00:02:41,233 --> 00:02:46,133

which is the same as the position number marked in the circuit diagram and location diagram

36

00:02:47,800 --> 00:02:49,733

Ok, that's all for this video
