1
00:00:00,300 --> 00:00:01,666
How to use bitmap
2
00:00:02,466 --> 00:00:07,366
In this lesson we're going to learn about the meanings of the bitmap marks of different models
3
00:00:09,033 --> 00:00:12,266
Let's take the iPhone 12 ProMax as an example to explain
4
00:00:14,900 --> 00:00:16,433
After opening the bitmap,
5
00:00:16,733 --> 00:00:21,400
we can see that the appearance shape of the bitmap is the same as that of the physical map
6
00:00:23,733 --> 00:00:27,433
The advantage of this is that when we look for chips or components,
7
00:00:27,533 --> 00:00:29,833
they can correspond to physical components
8
00:00:30,966 --> 00:00:35,300
In the bitmap, the red solder points represent useful signals,
9
00:00:35,700 --> 00:00:38,200
which may be power supply or signal lines
10
00:00:39,566 --> 00:00:43,833
If the red solder point falls off during welding, we need to refill it
11
00:00:45,433 --> 00:00:48,000
The gray solder point represents the ground wire,
12
00:00:48,500 --> 00:00:51,266
we can see that there are many gray dots in the bitmap
13
00:00:53,033 --> 00:00:56,366
The gray dot inside the chip also represents the ground wire
14
00:00:56,866 --> 00:01:00,333
In the physical board, the ground wires are all connected
15
00:01:01,133 --> 00:01:04,966
The blue solder points in the bitmap represent idle pins
16
00:01:06,666 --> 00:01:08,666
After zooming in on the bitmap,
17
00:01:10,066 --> 00:01:13,266
we can see that there are many blue dots inside the CPU
18
00:01:14,133 --> 00:01:18,400
If the blue dot falls off when we solder, we don't need to deal with it
19
00:01:20,166 --> 00:01:24,466
The bitmap also integrates the characteristic of the location diagram
20
00:01:24,933 --> 00:01:31,533
After we zoom in, we can see that each small component, connector or chip will have a number
21
00:01:32,333 --> 00:01:35,166
The meaning of the component number in the bitmap is the same
22
00:01:35,166 --> 00:01:39,433
as the meaning of the identification in the location diagram and circuit diagram
23
00:01:41,033 --> 00:01:44,066
U stands for chip, J stands for connector
24
00:01:45,133 --> 00:01:46,933
After we zoom in on the bitmap,
25
00:01:47,500 --> 00:01:50,766
we can see that there will be an English logo under the solder points
26
00:01:51,466 --> 00:01:55,066
The English logo represents the signal meaning of the solder point,
27
00:02:00,633 --> 00:02:05,333
There will also be a combination of letters and numbers on the top of the English logo,
28
00:02:06,300 --> 00:02:08,700
which is the coordinates of the solder points,
29
00:02:10,533 --> 00:02:13,500
corresponding to the coordinates of the line logo in the drawing
30
00:02:15,666 --> 00:02:17,500
After zooming out of the bitmap,
31
00:02:18,066 --> 00:02:21,666
we can see that there will be right-angled lines at the edge of the chip
32
00:02:23,366 --> 00:02:26,400
The right-angled line represents the direction of the chip,
33
00:02:26,700 --> 00:02:30,133
which corresponds to the direction of the chip on the physical mainboard
34
00:02:32,100 --> 00:02:35,600
Some chips will have numbers marked above the red solder points,
35
00:02:36,533 --> 00:02:39,266
indicating the reference value of the diode value
36
00:02:45,900 --> 00:02:50,933
Let's take a look at the meaning of the bitmap logo of Huawei P40 pro+ mobile phone
37
00:02:53,800 --> 00:02:55,266
After opening the bitmap,
38
00:02:55,633 --> 00:03:00,600
we can see that the shape and structure of the bitmap are the same as the shape of the physical mainboard,
39
00:03:01,100 --> 00:03:04,466
which is convenient for us to find the corresponding components
40
00:03:05,900 --> 00:03:07,600
After the bitmap is enlarged,
41
00:03:08,366 --> 00:03:13,066
we can see that the color logo of this model has the same meaning as the logo in Apple's
42
00:03:16,600 --> 00:03:21,133
Red dots represent useful signals, gray dots represent ground wires,
43
00:03:21,300 --> 00:03:23,666
and blue dots represent idle pins
44
00:03:24,633 --> 00:03:28,433
After zooming in on the bitmap, we can see many English signs,
45
00:03:29,500 --> 00:03:32,433
which correspond to those in the schematic diagram
46
00:03:35,133 --> 00:03:39,300
The identification of numbers and letters also represents coordinates
47
00:03:40,000 --> 00:03:41,866
After zooming out the bitmap,
48
00:03:42,833 --> 00:03:46,100
we can see that there is a right-angle mark on the edge,
49
00:03:46,666 --> 00:03:49,066
which represents the direction of the chip
50
00:03:50,500 --> 00:03:53,133
Through the comparison of the above two models,
51
00:03:53,333 --> 00:03:56,233
it is found that the meaning of the logo is the same
52
00:03:56,600 --> 00:03:59,200
Therefore, when repairing mobile phones,
53
00:03:59,433 --> 00:04:03,266
the viewing method of bitmaps of different mobile phones is the same
54
00:04:04,900 --> 00:04:06,866
Ok, that's all for this video
