1

00:00:00,300 --> 00:00:01,466

How to use bitmap

2

00:00:02,333 --> 00:00:06,533

In this lesson, we mainly learn the meanings of the toolbar logo in the bitmap

3

00:00:08,100 --> 00:00:12,266

After the bitmap is opened, there will be a row of toolbars on the top

4

00:00:13,333 --> 00:00:16,733

Different icons have different meanings and different functions

5

00:00:21,966 --> 00:00:26,166

The A logo icon in the bitmap represents the dual-open function

6

00:00:27,500 --> 00:00:32,133

When we turn on the dual-open function, half of the screen can display bitmaps,

7

00:00:32,333 --> 00:00:34,533

and the other half can display drawings

8

00:00:35,266 --> 00:00:39,033

The two mark icons marked by B and C are zoom in and zoom out

9

00:00:46,600 --> 00:00:50,400

When we click the plus sign with the mouse, the bitmap can be enlarged,

10

00:00:50,700 --> 00:00:53,700

and the bitmap can be zoomed out when we click the minus sign

11

00:00:54,366 --> 00:00:57,466

There are shortcuts for zooming in and out in the bitmap

12

00:00:58,066 --> 00:01:01,666

Slide the mouse wheel up, the bitmap will zoom in,

13

00:01:02,800 --> 00:01:05,833

and slide down, the bitmap will zoom out

14

00:01:07,200 --> 00:01:10,600

The toolbar icon marked with D represents centering

15

00:01:12,400 --> 00:01:18,166

If we zoom in on the bitmap, click the icon to display the entire bitmap in the middle of the screen

16

00:01:20,866 --> 00:01:23,700

The icon marked by E is the refresh function

17

00:01:24,000 --> 00:01:28,133

When the bitmap usage is stuck, we can click the refresh button

18

00:01:29,800 --> 00:01:35,266

The icons marked with F and G represent the left and right rotation functions of the bitmap

19

00:01:39,033 --> 00:01:43,066

The toolbar icon corresponding to H represents the cancel function

20

00:01:43,766 --> 00:01:48,266

For example, when using a bitmap, click the red solder point with the mouse,

21

00:01:48,566 --> 00:01:51,866

and some solder points will turn into the same yellow color

22

00:01:52,400 --> 00:01:56,333

When we click the cancel button, the yellow markers disappear

23

00:01:58,700 --> 00:02:02,300

The icon corresponding to the letter I is configured in color,

24

00:02:03,366 --> 00:02:07,000

and the color of the bitmap can be set according to your own preferences

25

00:02:07,633 --> 00:02:11,533

We can turn the solder points red, yellow, blue, etc.

26

00:02:12,900 --> 00:02:16,633

The icon corresponding to the letter J represents the mirror function

27

00:02:17,533 --> 00:02:19,533

After the mirror image is turned on,

28

00:02:19,833 --> 00:02:24,066

the solder points of the BGA chip will correspond to the points in the bitmap,

29

00:02:24,333 --> 00:02:26,666

which is convenient for us to judge and measure

30

00:02:27,933 --> 00:02:31,066

The icon corresponding to the K letter is highlighted

31

00:02:31,566 --> 00:02:36,533

After turning on the highlighting, click on any red solder point in the bitmap,

32

00:02:37,000 --> 00:02:40,466

and all the components connected to it will be displayed,

33

00:02:40,633 --> 00:02:44,033

which is convenient for us to find the connected components

34

00:02:44,666 --> 00:02:47,866

The icon corresponding to the L letter is the diode value

35

00:02:49,700 --> 00:02:51,333

After opening the icon,

36

00:02:51,766 --> 00:02:56,266

we can see that the value is displayed above the connector pin or solder point

37

00:02:57,166 --> 00:03:00,466

The icon corresponding to the M letter is the layer routing

38

00:03:01,066 --> 00:03:05,633

When we open the board layer wiring diagram, we can view the board layer circuits

39

00:03:06,266 --> 00:03:09,566

The icon corresponding to the N letter is mouse adjustment,

40

00:03:10,166 --> 00:03:13,700

which can adjust the size of the pointer when the mouse is selected

41

00:03:14,233 --> 00:03:16,533

The O letter corresponds to the find box,

42

00:03:16,866 --> 00:03:19,733

we can choose to find the signal or find the component

43

00:03:21,800 --> 00:03:24,266

The P letter corresponds to the search box

44

00:03:24,700 --> 00:03:27,366

When we want to search for signals or components,

45

00:03:28,533 --> 00:03:31,666

enter the corresponding English information in the search box

46

00:03:32,566 --> 00:03:34,066

Q is the search button

47

00:03:34,533 --> 00:03:38,266

When we enter English or letters when searching, click Search,

48

00:03:38,933 --> 00:03:43,633

and the components or lines with the same name as the search will be displayed in the bitmap

49

00:03:46,066 --> 00:03:48,133

Ok, that's all for this lesson
