161. Signals identification in differnt models
This video mainly demonstrates how to identify the power supply, ground wire
Detail
Comments

1

00:00:00,533 --> 00:00:02,033

Terms explanation

2

00:00:02,300 --> 00:00:06,200

This video mainly demonstrates how to identify the power supply, ground wire

3

00:00:06,200 --> 00:00:09,466

and signal in the schematic diagram of different models

4

00:00:11,233 --> 00:00:17,433

First check the power supply, ground wire and signal identification in the schematic diagram of the Apple model

5

00:00:18,000 --> 00:00:20,233

For example, on the current page,

6

00:00:20,600 --> 00:00:24,333

the logo PP_VDD_MAIN represents power supply

7

00:00:24,600 --> 00:00:28,300

Some power supply lines will directly mark the supply voltage

8

00:00:28,766 --> 00:00:33,333

For example, PP3V0 means that the power supply is 3V,

9

00:00:34,033 --> 00:00:37,700

and PP1V8 means that the power supply is 1.8V

10

00:00:38,000 --> 00:00:41,700

Some power supplies will use VDD to identify inside the chip

11

00:00:43,400 --> 00:00:44,733

Let's check the ground

12

00:00:44,966 --> 00:00:47,333

For example, under the chip,

13

00:00:47,666 --> 00:00:52,833

the internal pin identification GND and PGND both represent the ground wire

14

00:00:53,666 --> 00:00:56,100

In addition to the power supply and ground wire,

15

00:00:56,466 --> 00:01:02,900

there are some English marks on the bottom left of the chip, such as these English marks refer to the signal line

16

00:01:03,933 --> 00:01:07,833

In Apple's drawings, the signal line is generally drawn thinner,

17

00:01:08,466 --> 00:01:11,033

and the power supply is generally drawn thicker

18

00:01:13,366 --> 00:01:16,200

Next, let's look at the power supply, ground wire

19

00:01:16,200 --> 00:01:19,266

and signal identification in Huawei's schematic diagram

20

00:01:23,566 --> 00:01:28,100

In the current page, the line name identifies VDD_CPU_B,

21

00:01:28,133 --> 00:01:31,700

VDD_CPU_M, and VDD_CPU_L

22

00:01:33,466 --> 00:01:38,333

These three logos belong to the power supply, and they all start with VDD

23

00:01:39,133 --> 00:01:43,200

The power supply mark of this road is VBUCK5_0V8,

24

00:01:43,733 --> 00:01:47,000

which means that the power supply voltage is 0.8V

25

00:01:47,166 --> 00:01:50,833

VOUT7_1V8 also represents the power supply,

26

00:01:51,066 --> 00:01:53,666

indicating that the power supply is 1.8V

27

00:01:53,900 --> 00:01:57,200

AVSS is marked inside the box on the current page,

28

00:01:58,900 --> 00:02:03,566

VSS represents the ground wire, and the entire page represents ground

29

00:02:04,800 --> 00:02:08,766

In the schematic diagram, except for the power supply and ground wires,

30

00:02:09,166 --> 00:02:10,833

they belong to the signal wires

31

00:02:11,433 --> 00:02:16,933

For example, in the current page, like CSI3_DATA0 belongs to the signal line,

32

00:02:18,866 --> 00:02:21,866

ISP_SDA2 belongs to the signal line

33

00:02:22,533 --> 00:02:25,100

The VDD mark represents the power supply

34

00:02:25,466 --> 00:02:27,600

Let's look at the power supply, ground wire

35

00:02:27,600 --> 00:02:31,466

and signal identification in the Xiaomi series schematic diagram

36

00:02:31,900 --> 00:02:33,933

For example, in the current page,

37

00:02:34,233 --> 00:02:39,500

if the power supply logo has VREG_L6E_RCM_1P8,

38

00:02:40,033 --> 00:02:43,433

it means that the power supply is a 1.8V power supply

39

00:02:43,900 --> 00:02:49,166

QET6100_VDD2, VDD also represents power supply

40

00:02:49,933 --> 00:02:51,633

In the lower corner of the chip,

41

00:02:51,733 --> 00:02:55,233

we can see that the internal identification of the pin is GND,

42

00:02:55,966 --> 00:02:58,033

and GND represents the ground wire

43

00:02:58,666 --> 00:03:02,966

In addition to the red power supply, this chip also has a ground wire

44

00:03:04,333 --> 00:03:06,833

Lines marked in gray represent signals

45

00:03:07,766 --> 00:03:13,600

Like SDR_PRX16, RF_N77_TRX_CH0,

46

00:03:14,100 --> 00:03:15,933

these are all signal lines

47

00:03:17,200 --> 00:03:19,033

Ok, that's it for this lesson
