1

00:00:00,733 --> 00:00:02,266

Terms explanation

2

00:00:02,900 --> 00:00:08,100

This video mainly explains the meaning and identification of common terms in the schematic diagram

3

00:00:10,800 --> 00:00:12,566

In the working conditions of the chip,

4

00:00:13,166 --> 00:00:16,600

except for the power supply and grounding, all belong to the signal

5

00:00:17,500 --> 00:00:18,866

But when the chip is working,

6

00:00:19,100 --> 00:00:23,133

it will divide the signal into different signals to realize different commands

7

00:00:25,266 --> 00:00:28,333

The signal includes clock signal, reset signal,

8

00:00:28,333 --> 00:00:32,233

enable signal, interrupt signal, and wake-up signal

9

00:00:33,000 --> 00:00:36,900

These signals will execute different commands when the chip is working,

10

00:00:37,633 --> 00:00:40,233

so their working meanings are also different

11

00:00:42,100 --> 00:00:46,333

The clock signal is identified by English CLK in the schematic diagram

12

00:00:47,233 --> 00:00:51,800

The clock signal is designed to provide a reference operating frequency for the chip

13

00:00:52,733 --> 00:00:56,433

A chip or device lacks a clock signal and cannot function

14

00:00:58,533 --> 00:01:00,966

The basic unit of the clock is Hertz

15

00:01:02,066 --> 00:01:07,600

For example, CLK_PMU_TO_TOUCH_32K_1V8,

16

00:01:08,366 --> 00:01:14,833

this signal belongs to the clock signal, which is the 32KHz clock signal from power supply to touch

17

00:01:16,566 --> 00:01:20,300

The reset signal is identified by the English letter RST,

18

00:01:21,800 --> 00:01:24,266

and reset means to restart operation

19

00:01:25,200 --> 00:01:29,966

For example, when we're playing games or watching movies on a desktop computer,

20

00:01:30,666 --> 00:01:34,733

suddenly it freezes, you may need to press the restart button

21

00:01:34,866 --> 00:01:38,200

After pressing restart, the computer will restart

22

00:01:38,566 --> 00:01:40,200

When the mobile phone is turned on,

23

00:01:40,466 --> 00:01:42,566

the chip also needs a reset signal

24

00:01:43,666 --> 00:01:47,333

Without a reset signal, the chip cannot function properly

25

00:01:48,333 --> 00:01:51,700

The reset signal is active at an instant low level,

26

00:01:52,566 --> 00:01:57,433

which generally means that the reset pin has no voltage at the moment of power-on,

27

00:01:57,933 --> 00:02:01,166

and the pin will have voltage after this time point

28

00:02:02,700 --> 00:02:05,200

Measure the reset signal during maintenance,

29

00:02:05,633 --> 00:02:07,966

the voltage is mostly 1.8V

30

00:02:09,033 --> 00:02:13,066

For example, in the picture, AOP_TO_CODEC_RESET

31

00:02:13,833 --> 00:02:17,966

This signal refers to the reset signal from the CPU to the large audio,

32

00:02:18,266 --> 00:02:20,933

which is specially used to reset the audio chip

33

00:02:21,400 --> 00:02:25,400

The enable signal is generally identified by the English letter EN

34

00:02:26,400 --> 00:02:31,766

In the schematic diagram, some will use PWDN, SHUTDOWN to identify

35

00:02:32,500 --> 00:02:35,066

Enable signal means that when the chip is working,

36

00:02:35,433 --> 00:02:37,066

there needs to be a command

37

00:02:38,833 --> 00:02:41,533

After this command, the chip can work normally

38

00:02:43,166 --> 00:02:47,400

For example, TOUCH_TO_VDDH_EN in the picture,

39

00:02:49,000 --> 00:02:53,166

then the signal refers to the enable signal from the touchpad to the power supply

40

00:02:53,566 --> 00:02:54,866

Interrupt signal

41

00:02:55,166 --> 00:02:58,233

The interrupt signal is identified by English INT

42

00:02:59,733 --> 00:03:03,033

Interruption means that when we are playing games on the mobile phone,

43

00:03:03,366 --> 00:03:05,066

a call comes in suddenly,

44

00:03:05,566 --> 00:03:07,966

and the game will be interrupted at this time,

45

00:03:08,366 --> 00:03:10,766

and then it will display the answering call

46

00:03:11,033 --> 00:03:14,200

After answering the call, return to the game to run,

47

00:03:14,800 --> 00:03:17,400

then this process refers to the interruption

48

00:03:18,766 --> 00:03:20,766

For example, in the picture,

49

00:03:20,900 --> 00:03:25,833

AP_FROM_CODEC_INT refers to the CPU interrupt signal from the audio

50

00:03:28,200 --> 00:03:32,066

The wake-up signal uses the English WAKE logo

51

00:03:33,400 --> 00:03:36,400

Wake up means that when the mobile phone is not in use,

52

00:03:36,866 --> 00:03:41,033

the mobile phone will automatically turn off the screen and enter sleep mode

53

00:03:41,300 --> 00:03:44,066

When using the mobile phone, press the HOME button,

54

00:03:44,400 --> 00:03:47,200

the circuit will automatically send a wake-up signal,

55

00:03:47,766 --> 00:03:49,233

and the screen will light up

56

00:03:51,566 --> 00:03:53,700

For example, in the schematic diagram,

57

00:03:53,900 --> 00:03:59,600

PMU_FROM_CODEC_WAKE represents the wake-up signal from the audio to power supply

58

00:04:00,400 --> 00:04:04,366

The signals mentioned just now belong to the working conditions of the chip

59

00:04:05,066 --> 00:04:09,800

When the mobile phone fails, it is necessary to check these working conditions,

60

00:04:10,533 --> 00:04:13,566

so these signals are not required by every chip

61

00:04:14,100 --> 00:04:17,400

When we search, as long as the signal can be found,

62

00:04:17,600 --> 00:04:19,166

it means that the chip needs

63

00:04:20,266 --> 00:04:23,700

If you can't find it, it means that the chip does not need

64

00:04:24,266 --> 00:04:26,133

Ok, that's it for this video
