163. Common terms in schematic diagram
In this video, we mainly look at the terms commonly used in the schematic diagrams.
Detail
Comments

1

00:00:00,433 --> 00:00:01,966

Terms explanation

2

00:00:02,600 --> 00:00:06,900

In this video, we mainly look at the terms commonly used in the schematic diagrams

3

00:00:06,900 --> 00:00:09,266

of iPhones and Android mobile phones

4

00:00:10,800 --> 00:00:12,900

Common terms meanings of iPhones

5

00:00:13,366 --> 00:00:16,166

There are many English logos in Apple's drawings,

6

00:00:17,566 --> 00:00:20,500

and these English logos represent different meanings

7

00:00:22,866 --> 00:00:28,033

Because the English abbreviation used in the circuit diagram is composed of several English words

8

00:00:30,233 --> 00:00:33,866

Only take the first letter in the words and splicing it together,

9

00:00:37,366 --> 00:00:39,733

We must remember these English terms

10

00:00:40,533 --> 00:00:44,133

Because in the circuit diagram, the lines are marked in English

11

00:00:47,366 --> 00:00:51,666

The meanings of the signals cannot be understood if we don't know the English terms

12

00:00:53,033 --> 00:00:55,333

There are about 200 common terms

13

00:00:55,733 --> 00:00:57,133

This is the first page

14

00:00:57,800 --> 00:00:59,200

This is the second page

15

00:01:00,000 --> 00:01:01,400

This is the third page

16

00:01:01,866 --> 00:01:03,466

This is the fourth page

17

00:01:03,766 --> 00:01:08,466

Like the touchpad, it will have three English words that all represent touchpad

18

00:01:08,833 --> 00:01:12,800

Further below are common English meanings in Android circuit diagrams

19

00:01:13,400 --> 00:01:17,500

It's slightly different from the Apple models, but mostly the same

20

00:01:19,366 --> 00:01:21,833

For example, ANT means antenna,

21

00:01:22,233 --> 00:01:26,200

many of the low frequency and intermediate frequency are the same

22

00:01:26,666 --> 00:01:30,333

But the gravity sensor and the compass English logo are different

23

00:01:30,966 --> 00:01:35,200

Next, let's go to the schematic diagram to check these English words

24

00:01:35,800 --> 00:01:39,566

For example, we open the schematic diagram of iPhone 11

25

00:01:40,033 --> 00:01:41,966

After opening the schematic diagram,

26

00:01:42,133 --> 00:01:45,000

we can see that there will be many English logos on it

27

00:01:45,466 --> 00:01:47,533

Based on the terms we learned earlier,

28

00:01:47,900 --> 00:01:50,366

we can simply understand the meaning of the drawing

29

00:01:50,933 --> 00:01:55,033

PCIe represents the bus, AP represents the CPU,

30

00:01:56,633 --> 00:01:59,400

and BI refers to bidirectional communication

31

00:01:59,566 --> 00:02:01,333

NAND stands for hard disk

32

00:02:01,966 --> 00:02:05,166

CLKREQ represents a clock request

33

00:02:05,666 --> 00:02:11,266

The meaning of this signal is the PCIe bus clock request signal from the hard disk to the CPU

34

00:02:14,133 --> 00:02:16,066

We can look at other signals

35

00:02:16,333 --> 00:02:20,466

For example, PCIe3 also represents the PCIe bus

36

00:02:20,866 --> 00:02:22,300

AP is CPU,

37

00:02:23,600 --> 00:02:25,766

WLAN refers to the WiFi,

38

00:02:26,100 --> 00:02:28,433

PERST refers to reset signal

39

00:02:28,866 --> 00:02:31,433

1V2 means 1.2V voltage

40

00:02:31,633 --> 00:02:36,633

Then this signal represents the reset signal of the PCIe bus from the CPU to Wifi,

41

00:02:38,233 --> 00:02:40,400

and the voltage is 1.2V

42

00:02:40,600 --> 00:02:43,200

Let's open the schematic diagram of Xiaomi 10

43

00:02:43,900 --> 00:02:47,900

After opening it, we can see that there are many English logos on it

44

00:02:48,733 --> 00:02:50,733

PCIe refers to the bus

45

00:02:52,200 --> 00:02:54,133

REF refers to the reference,

46

00:02:54,433 --> 00:02:56,733

CLK represents the clock signal,

47

00:02:57,133 --> 00:02:59,366

WLAN represents Wifi

48

00:02:59,533 --> 00:03:03,166

Then this represents the reference clock of the PCIe bus

49

00:03:04,066 --> 00:03:06,000

Then if we memorize the English terms,

50

00:03:07,366 --> 00:03:10,800

we can know the meanings of the signal line when we look at the drawings,

51

00:03:11,633 --> 00:03:13,666

which can help us understand better

52

00:03:14,900 --> 00:03:16,633

Ok, that's it for this lesson
