1

00:00:00,566 --> 00:00:02,533

How to use the schematic diagram

2

00:00:02,933 --> 00:00:08,666

In this lesson, we mainly study the common numbers in the schematic diagram and the meanings of the toolbar

3

00:00:10,966 --> 00:00:16,800

The schematic diagram reflects the physical connection relationship between the components on the circuit board

4

00:00:17,400 --> 00:00:22,466

The schematic diagram will contain informations such as models of the electronic components,

5

00:00:22,800 --> 00:00:25,233

the pins and some parameters of the pins

6

00:00:27,166 --> 00:00:30,600

The schematic will draw each component as a separate block

7

00:00:33,500 --> 00:00:36,500

The schematic diagram has many page numbers,

8

00:00:36,633 --> 00:00:40,200

for example, there are 80 pages, 90 pages

9

00:00:40,600 --> 00:00:42,933

Each page introduces a single chip

10

00:00:43,600 --> 00:00:47,666

The component number in the schematic diagram is the same as the component number

11

00:00:47,666 --> 00:00:49,700

in the position diagram and the bitmap

12

00:00:50,466 --> 00:00:53,633

The chip starts with U, the interface starts with J,

13

00:00:54,166 --> 00:00:58,300

the transistor starts with Q, and the diode starts with D

14

00:00:58,933 --> 00:01:02,266

The crystal oscillator is represented by X or Y,

15

00:01:03,066 --> 00:01:07,433

the resistor is represented by R, the capacitor is represented by C,

16

00:01:07,533 --> 00:01:09,733

and the inductor is represented by L

17

00:01:10,600 --> 00:01:12,500

After opening the schematic diagram,

18

00:01:12,533 --> 00:01:16,166

we can see that there will be a toolbar above the schematic diagram

19

00:01:16,666 --> 00:01:19,433

There are some shortcut icons in the toolbar

20

00:01:22,666 --> 00:01:28,300

For example, the two icons identified by the letter A represent the rotation direction

21

00:01:29,000 --> 00:01:31,333

left rotation and right rotation

22

00:01:33,800 --> 00:01:37,600

The icon identified by the letter B is the page number of the drawing

23

00:01:38,933 --> 00:01:42,100

1 means that it is currently on the first page of the drawing,

24

00:01:42,566 --> 00:01:48,300

and 177 means that the drawing has a total of 177 pages

25

00:01:48,700 --> 00:01:52,433

The left and right arrows identified by the C letter in the toolbar

26

00:01:52,433 --> 00:01:55,666

represent the previous page and the next page of the drawing

27

00:01:56,033 --> 00:01:59,366

The two icons identified by the letter D in the toolbar,

28

00:01:59,966 --> 00:02:02,900

the one on the left represents continuous mode,

29

00:02:03,633 --> 00:02:06,766

and the one on the right represents single-page display

30

00:02:07,133 --> 00:02:12,266

The plus and minus signs identified by the E icon represent the zoom in and out of the drawing

31

00:02:14,466 --> 00:02:16,933

The F icon represents the search box,

32

00:02:18,700 --> 00:02:23,766

we can search the position number of the chip or search the signal in the schematic diagram

33

00:02:28,066 --> 00:02:35,666

G icon, the left and right triangle symbols represent the previous search result and the next search result

34

00:02:41,000 --> 00:02:44,200

The H icon in the toolbar stands for case matching

35

00:02:45,466 --> 00:02:50,566

After opening, when searching, it will only be displayed if the case matches

36

00:02:55,066 --> 00:02:57,500

We don't need to open it in normal use

37

00:02:58,566 --> 00:03:01,800

The I icon in the toolbar stands for Advanced Search

38

00:03:02,200 --> 00:03:04,766

If we enter the signal and click Advanced Search,

39

00:03:05,500 --> 00:03:08,900

the search results will be displayed in the list on the left,

40

00:03:13,633 --> 00:03:17,866

so that we can check which pages of the drawing the signal is connected to

41

00:03:18,266 --> 00:03:22,100

In use, hold down the left or right button of the mouse,

42

00:03:22,266 --> 00:03:24,200

and move the mouse to drag the drawing

43

00:03:25,800 --> 00:03:31,033

When double-clicking the signal name, the name will be automatically pasted into the search box,

44

00:03:31,266 --> 00:03:33,700

which is convenient for us to find the signal

45

00:03:34,266 --> 00:03:36,366

Ok, that's all for this video
