1

00:00:00,666 --> 00:00:02,633

How to use the schematic diagram

2

00:00:03,666 --> 00:00:07,866

This lesson mainly demonstrates how to use the toolbar in the schematic diagram

3

00:00:10,800 --> 00:00:14,200

Let's take the iPhone 12 Pro Max model as an example

4

00:00:15,900 --> 00:00:20,433

After opening the schematic diagram, we click the left and right rotation icon,

5

00:00:20,500 --> 00:00:23,433

and the schematic diagram will change its direction

6

00:00:25,700 --> 00:00:30,300

The page number 1 in the toolbar means that it is currently on the first page,

7

00:00:30,600 --> 00:00:36,900

and 177 means that there are 177 pages of the drawing for this model

8

00:00:37,633 --> 00:00:41,466

After shrinking the schematic, a box represents a page

9

00:00:46,066 --> 00:00:49,733

The left and right arrows represent the page turning function,

10

00:00:50,733 --> 00:00:53,633

you can click it to jump to the next or previous page

11

00:00:54,766 --> 00:00:57,000

Conforms to width continuous mode

12

00:00:57,466 --> 00:01:01,100

When we click this icon, the schematic will be full screen

13

00:01:01,466 --> 00:01:03,133

Conforms to single page

14

00:01:03,500 --> 00:01:08,666

When we click on this icon, only the current page will be displayed in the schematic

15

00:01:09,700 --> 00:01:12,933

When we use it normally, this function is not needed,

16

00:01:13,400 --> 00:01:15,466

we need to use the continuous mode

17

00:01:16,166 --> 00:01:21,900

The minus sign and plus sign in the toolbar represent the reduction and enlargement of the schematic diagram

18

00:01:22,366 --> 00:01:26,133

When we click the minus sign, the schematic diagram shrinks,

19

00:01:26,600 --> 00:01:30,466

and when we click the plus sign, the schematic diagram zooms in

20

00:01:30,933 --> 00:01:35,000

In the search box, we can enter the position number or signal name

21

00:01:36,700 --> 00:01:41,933

After entering, click the triangle symbol behind, you can search down or up

22

00:01:54,533 --> 00:01:55,800

Case matching button

23

00:01:56,333 --> 00:02:02,566

When we open the icon, change the letters to lowercase and then search, we can't find it

24

00:02:06,533 --> 00:02:10,400

When we use it normally, we don't need to turn on case matching

25

00:02:10,933 --> 00:02:12,500

Advanced search button

26

00:02:13,200 --> 00:02:17,733

When we enter the location number or signal name, click Advanced Search

27

00:02:18,433 --> 00:02:21,700

The search results will be displayed in the list on the left

28

00:02:34,633 --> 00:02:38,200

Demonstration of shortcut functions in the schematic toolbar

29

00:02:39,000 --> 00:02:42,633

When we want to zoom in on the drawing, we slide the mouse wheel

30

00:02:43,500 --> 00:02:46,400

Slide the mouse wheel up, the drawing will be enlarged

31

00:02:47,500 --> 00:02:50,466

Slide the mouse wheel down, the drawing will zoom out

32

00:02:51,200 --> 00:02:54,333

When searching for a signal or component position number,

33

00:02:55,300 --> 00:02:59,300

we only need to double-click the name of the signal or position number,

34

00:03:02,566 --> 00:03:04,433

After copying the search box,

35

00:03:04,700 --> 00:03:08,466

we can click the Find Down button, or open the advanced search

36

00:03:09,833 --> 00:03:11,600

If we want to search for a signal,

37

00:03:12,200 --> 00:03:15,933

we only need to double-click the signal name to open the advanced search,

38

00:03:16,766 --> 00:03:20,333

and the page number of the signal connected to the drawing will be displayed

39

00:03:21,200 --> 00:03:24,866

When we look at the signals, when the names are exactly the same,

40

00:03:25,533 --> 00:03:27,300

it means that they are connected

41

00:03:29,333 --> 00:03:32,166

For example, if there is CON after the name,

42

00:03:32,633 --> 00:03:35,633

it means that the signal is converted by a component

43

00:03:36,666 --> 00:03:42,366

After learning the basics of electronics, we know that 0 ohm represents a fuse resistor,

44

00:03:42,366 --> 00:03:44,233

and its two sides are connected

45

00:03:44,733 --> 00:03:48,066

Although the names are inconsistent in the schematic diagram,

46

00:03:48,366 --> 00:03:53,000

the two sides are also the same signal, because the 0 ohm resistor is a wire

47

00:03:53,800 --> 00:03:55,733

Ok, that's it for this lesson
