How to use the schematic diagram

2

00:00:04,800 --> 00:00:09,333

In this lesson, we mainly study the meanings of the symbols in the schematic diagram

3

00:00:10,566 --> 00:00:14,066

The first page of the schematic diagram is generally a catalog page,

4

00:00:15,100 --> 00:00:18,200

just like a book, there will be a catalog after opening

5

00:00:20,100 --> 00:00:24,500

This catalog page introduces the circuits covered by the different page numbers

6

00:00:25,500 --> 00:00:30,500

In the schematic diagram of Apple models, BS represents the screw column,

7

00:00:30,933 --> 00:00:35,933

and PP, TP, and FD in the schematic diagram refer to the test points

8

00:00:37,233 --> 00:00:40,466

For example, in the schematic diagram of Xiaomi,

9

00:00:40,800 --> 00:00:46,700

the test point marks TP1606, TP1607, etc.

10

00:00:47,266 --> 00:00:50,033

In the schematic diagram of Android machine,

11

00:00:50,266 --> 00:00:53,900

the power supply line and the signal line are the same thickness

12

00:00:54,533 --> 00:00:58,433

But in Apple's drawings, thick lines are generally for power supply,

13

00:01:00,233 --> 00:01:02,733

and thin lines are generally for signals

14

00:01:03,333 --> 00:01:05,533

But some lines have the same thickness

15

00:01:06,566 --> 00:01:12,133

At this time, we need to judge whether it is power supply or signal according to the power supply name

16

00:01:13,666 --> 00:01:17,266

In the schematic diagram, the box represents the chip,

17

00:01:18,200 --> 00:01:21,733

and the more chip pins, the more boxes there will be

18

00:01:22,100 --> 00:01:26,533

The position number inside the box is the same, it means the same chip

19

00:01:27,966 --> 00:01:32,366

Near or below the position number in the schematic diagram refers to the chip model

20

00:01:34,366 --> 00:01:40,900

For example, CG8889ATT is marked at the bottom of U6200,

21

00:01:41,200 --> 00:01:42,866

which is the model of this chip

22

00:01:44,833 --> 00:01:48,633

If the line marks NC or a cross in the schematic diagram,

23

00:01:49,366 --> 00:01:51,100

it means that the line is not used

24

00:01:53,366 --> 00:01:57,700

For example, in the drawing, there are several pins marked with NC,

25

00:01:57,833 --> 00:02:00,400

which means that the pins are empty and unused

26

00:02:02,866 --> 00:02:08,533

The English logo outside the box in the schematic diagram is the logo of the mobile phone manufacturer

27

00:02:09,300 --> 00:02:13,166

The internal English logos belong to the chip manufacturer's logos

28

00:02:13,700 --> 00:02:15,200

In the schematic diagram,

29

00:02:15,333 --> 00:02:20,700

the numbers and letters at the junction of lines and boxes represent the coordinates of the chip

30

00:02:21,733 --> 00:02:24,400

Because mobile phone chips are all BGA chips,

31

00:02:24,900 --> 00:02:28,966

when marking pins, numbers are generally used for horizontal rows,

32

00:02:29,300 --> 00:02:32,033

and letters are generally used for vertical rows

33

00:02:32,666 --> 00:02:35,833

Numbers and letters represent the pin coordinates of the chip

34

00:02:37,533 --> 00:02:42,266

The pin coordinates of the chip in the drawing correspond to the coordinates of the chip in the bitmap

35

00:02:44,733 --> 00:02:48,533

The arrow at the end of the line in the schematic diagram faces outward,

36

00:02:48,866 --> 00:02:52,400

or the one marked OUT means that the signal is an output

37

00:02:53,600 --> 00:02:56,800

For example PM_CLK_IN,

38

00:02:58,033 --> 00:03:01,733

the arrow pointing outward represents the signal output

39

00:03:02,133 --> 00:03:06,000

Arrows pointing inward or marked IN represent input,

40

00:03:06,400 --> 00:03:10,033

such as AUTO_ON, arrows pointing inward

41

00:03:10,500 --> 00:03:12,866

Then this signal represents the input

42

00:03:13,233 --> 00:03:15,700

There are arrows or logos on both sides,

43

00:03:16,600 --> 00:03:20,500

and the representative signal of BI can be input or output

44

00:03:21,466 --> 00:03:24,400

For example, PM_FAULT,

45

00:03:24,600 --> 00:03:27,166

there are arrows on both sides of this signal,

46

00:03:27,533 --> 00:03:30,566

which means that the signal can be input or output

47

00:03:31,466 --> 00:03:33,100

In the schematic diagram,

48

00:03:33,266 --> 00:03:37,866

the number at the end of the line means that the signal will reach the page number of the drawing

49

00:03:39,933 --> 00:03:43,200

The more numbers, the more pages the signal reaches

50

00:03:43,533 --> 00:03:46,766

Generally, Apple and Vivo models are mostly

51

00:03:47,600 --> 00:03:49,766

Like in the drawing of this Xiaomi model,

52

00:03:50,300 --> 00:03:52,166

it has no identification number

53

00:03:52,400 --> 00:03:56,666

A dot will be marked on the cross-connected lines in the schematic diagram,

54

00:03:57,300 --> 00:04:00,600

and no dot will be marked on the lines that are not connected

55

00:04:00,866 --> 00:04:04,433

For example, if there is no dot after the line crosses,

56

00:04:04,533 --> 00:04:06,900

it means that the two lines are not connected

57

00:04:07,200 --> 00:04:10,566

If there is a dot, it means that the lines are connected

58

00:04:11,100 --> 00:04:14,366

Some components in the actual products may not be installed

59

00:04:17,400 --> 00:04:21,800

It is not to save material, it has a variety of design versions,

60

00:04:22,266 --> 00:04:26,833

such as high configuration, medium configuration, low configuration

61

00:04:27,100 --> 00:04:31,200

There are maybe many components that are not installed in the low-end version

62

00:04:31,600 --> 00:04:34,166

Different manufacturers have different logos

63

00:04:34,600 --> 00:04:36,866

Apple uses NOSTUFF to identify,

64

00:04:37,266 --> 00:04:39,600

Huawei uses DNI to identify,

65

00:04:40,233 --> 00:04:42,666

and Xiaomi uses NM to identify

66

00:04:42,900 --> 00:04:45,400

If NM is marked next to the component,

67

00:04:45,600 --> 00:04:47,800

it means that the component is not installed

68

00:04:48,966 --> 00:04:52,366

OPPO, Meizu and Samsung use NC to identify

69

00:04:52,633 --> 00:04:54,466

If the component is marked NC,

70

00:04:54,566 --> 00:04:56,700

it means that the component is not installed

71

00:04:57,166 --> 00:05:01,900

In the schematic diagram, the English name marks are completely consistent,

72

00:05:02,200 --> 00:05:05,233

and in the real object it means that they are connected

73

00:05:09,200 --> 00:05:11,066

Ok, that's it for this lesson
