1

00:00:00,800 --> 00:00:02,633

How to use the schematic diagram

2

00:00:02,866 --> 00:00:07,766

This video mainly demonstrates how to view the meanings of the marking in the schematic diagram

3

00:00:09,000 --> 00:00:12,433

Let me take the iPhone schematic diagram as an example to demonstrate

4

00:00:14,633 --> 00:00:18,600

After opening in the drawing, the first page is the catalog page

5

00:00:19,233 --> 00:00:24,200

The catalog page is dedicated to introducing the page numbers of different chips in the mainboard

6

00:00:24,733 --> 00:00:26,800

After the schematic diagram is opened,

7

00:00:27,100 --> 00:00:30,066

if we see a circle marked SB or BS,

8

00:00:31,633 --> 00:00:34,800

it represents the screw column in the real object

9

00:00:35,166 --> 00:00:41,133

All those starting with FD, TP, or PP in the schematic diagram represent test points

10

00:00:42,600 --> 00:00:46,666

In the actual object, the small yellow dots represent test points

11

00:00:48,366 --> 00:00:51,266

A box in the schematic diagram represents a chip

12

00:00:53,466 --> 00:00:56,133

If the position numbers in the boxes are same,

13

00:00:56,266 --> 00:00:59,033

it means that all the introductions are the same chip

14

00:00:59,266 --> 00:01:03,966

For example, the location number of the iPhone 12 CPU is U1000

15

00:01:04,166 --> 00:01:08,500

After searching, we can find that there are many identifiers U1000

16

00:01:08,733 --> 00:01:13,766

As long as U1000 is marked, it means that the whole introduction is CPU

17

00:01:14,266 --> 00:01:21,333

In the Apple drawing, we can also identify it according to the SYM2OF21 below the position number

18

00:01:23,500 --> 00:01:25,933

2 represents the second box of the CPU,

19

00:01:26,233 --> 00:01:30,166

and 21 represents a total of 21 boxes for the CPU

20

00:01:32,066 --> 00:01:36,966

Each line in the schematic diagram represents each solder point in the physical diagram

21

00:01:39,233 --> 00:01:44,000

The English identification in the schematic diagram is the manufacturer's English logo

22

00:01:44,500 --> 00:01:47,866

The English logo of the internal is the chip manufacturer logo

23

00:01:48,833 --> 00:01:52,433

When we search for a signal, we search for the external English name

24

00:01:53,033 --> 00:01:57,666

The letters and numbers at the junction of the line and the box represent the coordinates

25

00:01:59,900 --> 00:02:03,600

Because BGA chips have solder points horizontally and vertically,

26

00:02:04,333 --> 00:02:06,933

they cannot be directly identified by numbers

27

00:02:08,600 --> 00:02:12,333

Generally, the vertical row will be identified by letters,

28

00:02:12,666 --> 00:02:15,733

and the horizontal row will be identified by numbers

29

00:02:16,533 --> 00:02:19,233

the coordinate point represents the foot position

30

00:02:20,666 --> 00:02:23,200

For example, point F5 in the bitmap,

31

00:02:23,833 --> 00:02:26,900

it will have a corresponding point in the schematic diagram

32

00:02:29,733 --> 00:02:32,700

In the schematic diagram, the line is marked IN,

33

00:02:34,100 --> 00:02:37,500

and the arrow facing inward represents that the signal is input

34

00:02:38,333 --> 00:02:42,633

If the arrow marks OUT outward, it means that the signal is output

35

00:02:44,900 --> 00:02:48,333

If there are arrows on both sides of the line identification BI,

36

00:02:48,733 --> 00:02:51,600

it means that the signal can be output or input

37

00:02:54,366 --> 00:02:57,433

In Apple's drawings, the line marked NC,

38

00:02:59,100 --> 00:03:03,733

like the unused signal in the schematic diagram of iPhone 11, will be marked NC

39

00:03:04,066 --> 00:03:08,600

And the line will be crossed, then both cases belong to the signal is not used

40

00:03:11,233 --> 00:03:13,800

The inside of the box is divided into areas,

41

00:03:14,066 --> 00:03:15,966

which belong to the subdivision module

42

00:03:16,300 --> 00:03:18,533

Because the CPU is an integrated body,

43

00:03:18,700 --> 00:03:21,900

its different solder points handle different functions

44

00:03:22,466 --> 00:03:27,233

In the schematic diagram, the solder points with the same functions will be marked together

45

00:03:27,700 --> 00:03:31,433

The number below the position number generally represents the model of the chip

46

00:03:31,966 --> 00:03:38,000

For example, CBTL1614A1 is marked under U9300,

47

00:03:38,266 --> 00:03:40,366

which means it is the model of this chip

48

00:03:43,033 --> 00:03:46,933

In general, we are based on the model marked on the physical chip,

49

00:03:49,166 --> 00:03:52,633

and the model marked in the schematic diagram is only for reference

50

00:03:52,900 --> 00:03:57,100

In Apple's schematic diagram, the thick line is usually the power supply,

51

00:03:58,900 --> 00:04:00,800

and the thin line is usually the signal

52

00:04:01,400 --> 00:04:03,366

But there are also special cases

53

00:04:03,566 --> 00:04:04,966

In the Apple model,

54

00:04:05,133 --> 00:04:08,300

if we see the NOSTUFF mark on the top of the component,

55

00:04:08,800 --> 00:04:11,033

it means that the component is not installed

56

00:04:11,633 --> 00:04:13,233

When we look at the physical picture,

57

00:04:13,766 --> 00:04:16,666

we can see that there are many components that are not installed

58

00:04:17,500 --> 00:04:19,966

We can't make up for this kind of component,

59

00:04:23,500 --> 00:04:26,000

There are dots crossed in the schematic diagram,

60

00:04:26,833 --> 00:04:29,966

which means that the line is connected in actual measurement

61

00:04:31,433 --> 00:04:35,666

If the intersection has no dot, it means that the lines are not connected

62

00:04:36,433 --> 00:04:38,400

Ok, that's it for this lesson
