Recognition and Measurement of Electronic Components

2

00:00:04,100 --> 00:00:09,866

This video mainly explains common inductor types and inductor parameter identification in mobile phones

3

00:00:13,666 --> 00:00:17,366

In real objects, large inductor will be marked with dot

4

00:00:19,366 --> 00:00:22,400

Like these inductors, they all have parameters

5

00:00:23,533 --> 00:00:26,700

For example, inductor L3401,

6

00:00:26,800 --> 00:00:32,000

the position of the circle marked with the first corner of the inductor represents the direction of the inductor

7

00:00:32,600 --> 00:00:35,300

It corresponds to the mark in the real object

8

00:00:38,866 --> 00:00:41,433

Parameters are marked below the position number

9

00:00:42,866 --> 00:00:48,200

0.22 uH means the inductance is 0.22 microhenries,

10

00:00:48,700 --> 00:00:51,366

20% means the error of the inductance

11

00:00:52,633 --> 00:00:58,366

5.8A means that the maximum passing current of the inductor is 5.8A,

12

00:00:58,900 --> 00:01:03,566

and 0.04OHM means the resistance value of the inductor

13

00:01:06,166 --> 00:01:08,166

Common inductors in mobile phones

14

00:01:09,000 --> 00:01:13,666

One is a large chip inductor, the color of the inductor is mostly gray,

15

00:01:14,966 --> 00:01:16,500

and there will be a dot mark

16

00:01:17,966 --> 00:01:20,200

The second type is the fuse inductor,

17

00:01:20,766 --> 00:01:23,033

the fuse inductor is relatively small,

18

00:01:23,400 --> 00:01:25,900

generally located near the connection seat

19

00:01:26,700 --> 00:01:29,266

Let's understand the inductor through the physical map,

20

00:01:29,466 --> 00:01:31,433

bitmap and schematic diagram

21

00:01:33,866 --> 00:01:37,933

In the physical picture, the large inductor is easier to distinguish

22

00:01:38,766 --> 00:01:42,700

Large inductors generally have a gray surface and are marked with dots

23

00:01:46,400 --> 00:01:49,433

The fuse inductor is generally near the connection seat,

24

00:01:49,600 --> 00:01:51,400

because it is relatively small,

25

00:01:51,533 --> 00:01:54,233

it cannot be distinguished by physical inspection

26

00:01:55,100 --> 00:01:57,100

We can view it through the bitmap

27

00:02:01,100 --> 00:02:07,266

The mark FL means it is a fuse inductor, such as FL10500

28

00:02:11,100 --> 00:02:15,333

After we can find the inductor in the bitmap, switch to the schematic diagram,

29

00:02:16,833 --> 00:02:19,133

we can see the parameters of the inductor

30

00:02:24,266 --> 00:02:27,300

The small circle represents the direction of the inductor,

31

00:02:27,733 --> 00:02:33,633

2.2 uH represents the inductance, and 20% represents the inductance error

32

00:02:35,733 --> 00:02:39,900

3.7A represents the maximum passing current of the inductor,

33

00:02:40,566 --> 00:02:45,433

and 0.071OHM represents the resistance of the inductor

34

00:02:45,966 --> 00:02:51,533

FL10500 is a fuse inductor with a resistance of 33 ohms,

35

00:02:53,633 --> 00:02:59,133

an error of 25%, and a maximum current of 1.5 amps

36

00:03:00,033 --> 00:03:05,933

In the main board, there are some double inductors connected together, such as L3301

37

00:03:08,833 --> 00:03:13,766

In the schematic diagram, we can see that pins 1 and 3 of the inductor are an inductor,

38

00:03:14,633 --> 00:03:16,800

and pins 2 and 4 are an inductor

39

00:03:19,500 --> 00:03:23,166

This is an inductor in which two inductors are packaged together

40

00:03:28,600 --> 00:03:31,766

When we replace this kind of inductor after it is damaged,

41

00:03:32,000 --> 00:03:34,933

we need to find the same type of inductor to replace it,

42

00:03:35,066 --> 00:03:37,900

and we cannot use a single inductor to replace it

43

00:03:38,433 --> 00:03:40,233

Ok, that's it for this lesson
