1

00:00:00,233 --> 00:00:03,000

Recognition and Measurement of Electronic Components

2

00:00:03,233 --> 00:00:07,100

This video mainly explains the method of judging the quality of inductors

3

00:00:07,766 --> 00:00:14,033

The first step is to observe whether there are obvious cracks or burnt traces on the appearance of the inductor

4

00:00:14,500 --> 00:00:18,133

As shown in the picture, the inductor is broken or burnt,

5

00:00:18,666 --> 00:00:21,133

which means that the inductor has been damaged

6

00:00:22,100 --> 00:00:25,900

In the second step, if the appearance is not obviously damaged,

7

00:00:26,166 --> 00:00:30,233

we use a multimeter diode or buzzer range to measure the two ends of the inductor

8

00:00:33,433 --> 00:00:37,000

If the value shows 0, it means that the inductor is normal

9

00:00:37,466 --> 00:00:41,633

If OL or 1 is displayed, it means the inductor is damaged

10

00:00:42,766 --> 00:00:45,733

The multimeter can only roughly judge the inductor

11

00:00:47,100 --> 00:00:50,600

To make an accurate judgment, we use the third step,

12

00:00:51,133 --> 00:00:53,766

using the inductor meter to measure the inductance

13

00:00:55,233 --> 00:00:58,500

When the measured value is consistent with the value marked in the drawing,

14

00:00:59,033 --> 00:01:01,500

it means that the inductor is completely normal

15

00:01:02,900 --> 00:01:06,500

In actual maintenance, generally only use a multimeter to judge

16

00:01:07,066 --> 00:01:10,833

If you suspect damage, you can directly replace it

17

00:01:11,233 --> 00:01:16,233

In actual maintenance, it is rare to remove the inductor to judge whether it is good or bad

18

00:01:16,633 --> 00:01:20,500

Generally, we use the diode range of a multimeter to measure the diode value

19

00:01:20,500 --> 00:01:22,733

to judge whether the inductor is good or bad

20

00:01:23,866 --> 00:01:29,833

For example, the third pin of the inductor L8051 is connected to the display seat,

21

00:01:30,100 --> 00:01:32,266

and the value is 450

22

00:01:32,533 --> 00:01:34,633

When we measure the other end of the inductor,

23

00:01:35,100 --> 00:01:39,733

if the value also shows 450, it means that the inductor is normal

24

00:01:40,500 --> 00:01:43,700

If the values at both ends of the inductor are not the same,

25

00:01:43,833 --> 00:01:45,833

it means that the inductor is damaged

26

00:01:46,366 --> 00:01:49,400

For example, when measuring inductor in some places,

27

00:01:49,666 --> 00:01:51,266

there is no connection point,

28

00:01:51,433 --> 00:01:55,733

we can view the connected components at both ends of the inductor through the bitmap

29

00:01:56,366 --> 00:02:00,500

If the values of the components connected at both ends are also the same,

30

00:02:01,033 --> 00:02:03,000

it means that the inductor is normal

31

00:02:04,066 --> 00:02:05,966

OK, that's all for this video
