Recognition and Measurement of Electronic Components

2

00:00:03,533 --> 00:00:07,466

In this lesson we're going to learn about the principle of inductor substitution

3

00:00:07,633 --> 00:00:12,933

After the chip inductor is damaged, it needs to be replaced with the same parameters and the same size

4

00:00:13,533 --> 00:00:16,466

For example, iPhone 11 backlight inductor,

5

00:00:17,066 --> 00:00:20,300

if it is damaged, you need to find the inductor parameters

6

00:00:21,500 --> 00:00:24,233

First find the inductor position number in the bitmap,

7

00:00:25,133 --> 00:00:27,200

and then jump to the schematic diagram

8

00:00:28,666 --> 00:00:32,066

The parameters of the inductor can be seen in the schematic diagram

9

00:00:32,466 --> 00:00:36,933

The inductance is 15 uH, the error value is 20%,

10

00:00:37,400 --> 00:00:40,066

the maximum current is 0.8A,

11

00:00:40,400 --> 00:00:44,600

the resistance value of the inductor is 0.585 ohms,

12

00:00:44,700 --> 00:00:48,300

and the specification of the inductor is 32251

13

00:00:48,733 --> 00:00:52,966

When replacing, find an inductor with the same parameters to replace

14

00:00:53,166 --> 00:00:58,000

If the parameters are different, the machine may not be able to start after replacement

15

00:00:58,766 --> 00:01:00,800

After the fuse inductor is damaged,

16

00:01:01,100 --> 00:01:04,333

you can find a fuse inductor as the same size to replace

17

00:01:04,766 --> 00:01:07,100

or you can use a wire to connect directly

18

00:01:07,566 --> 00:01:09,966

Precautions for replacing the inductors

19

00:01:10,666 --> 00:01:14,133

Chip large inductors cannot be directly connected with wires,

20

00:01:14,500 --> 00:01:17,933

only fuse inductors can be directly connected with wires

21

00:01:18,266 --> 00:01:23,466

In the actual maintenance, the inductor is easy to be damaged when disassembling and assembling

22

00:01:24,033 --> 00:01:27,666

You can buy a fortune small inductor on Taobao to replace it

23

00:01:28,800 --> 00:01:34,000

The size and parameters of the fortune small inductor are similar to the inductor around the CPU,

24

00:01:34,366 --> 00:01:36,333

and it can be directly replaced

25

00:01:36,966 --> 00:01:40,333

Like some special inductors, such as charging inductors,

26

00:01:40,633 --> 00:01:43,233

you cannot use small inductors to replace them,

27

00:01:43,500 --> 00:01:46,666

you need to buy inductors with the same parameters to replace them

28

00:01:47,566 --> 00:01:49,366

Ok, that's all for this video
