iPhone display circuit repairing

2

00:00:03,433 --> 00:00:06,933

This video mainly explains how to find the display power supply signals

3

00:00:06,933 --> 00:00:09,833

and measurement points of the iPhone 12 and 12 Pro

4

00:00:11,800 --> 00:00:17,433

Search method Step 1, find the display power supply in the iPhone 12 Promax component map

5

00:00:18,700 --> 00:00:23,633

Step 2, find the display power supply in the bitmap and confirm the position number

6

00:00:24,300 --> 00:00:28,866

Step 3, search for the position number of the display power supply in the circuit diagram,

7

00:00:29,500 --> 00:00:31,433

and find the corresponding signal

8

00:00:34,300 --> 00:00:37,766

Step 4, jump to the bitmap according to the position number,

9

00:00:37,833 --> 00:00:40,000

and find the connected components

10

00:00:41,233 --> 00:00:44,733

The yellow points in the bitmap can measure the voltage and diode value

11

00:00:47,800 --> 00:00:54,700

When checking the diagrams, first open the component map, circuit diagram, and bitmap of iPhone 12 and 12 Pro

12

00:00:55,966 --> 00:00:58,866

Find the display power supply in the component map,

13

00:01:00,200 --> 00:01:03,566

confirm the display power supply position number in the bitmap,

14

00:01:04,766 --> 00:01:07,600

search for the position number in the schematic diagram

15

00:01:09,100 --> 00:01:14,466

After finding the display power supply, find the corresponding signals according to the circuit diagram

16

00:01:16,133 --> 00:01:20,200

First look for the power supply and the boost inductor of the display power supply

17

00:01:20,566 --> 00:01:25,500

In the schematic diagram, the C7 pin of the display power supply is the power supply pin,

18

00:01:26,133 --> 00:01:29,766

which is connected to the main power supply PP_VDD_MAIN

19

00:01:31,100 --> 00:01:37,266

Inductor L9100 and inductor L9110 are power supply boost inductors

20

00:01:39,533 --> 00:01:43,400

L9100 is used to convert VOUT3,

21

00:01:44,766 --> 00:01:48,833

and L9110 is used to convert VOUT1

22

00:01:51,300 --> 00:01:55,300

Let's find the I2C bus that the CPU detects the display power supply

23

00:01:55,733 --> 00:01:59,666

The D4 pin of the display power is the I2C bus clock

24

00:02:00,800 --> 00:02:02,633

Jump to the bitmap according to the name,

25

00:02:03,533 --> 00:02:07,833

the signal is directly connected to the CPU and connected to the display connector

26

00:02:08,633 --> 00:02:13,300

It means that the I2C of the display screen and the I2C of the display power supply are the same

27

00:02:16,800 --> 00:02:23,533

D5 pin is the I2C bus data, connected to the CPU after passing through the resistor XR9122,

28

00:02:24,200 --> 00:02:26,566

and also connected to the display connector

29

00:02:28,566 --> 00:02:31,566

Let's find the reset signal of the display power supply

30

00:02:32,533 --> 00:02:35,766

The D7 pin of the display power supply is a reset signal

31

00:02:36,433 --> 00:02:38,366

Jump to the bitmap according to the name,

32

00:02:39,333 --> 00:02:42,733

the reset signal is directly connected to the main power supply

33

00:02:43,566 --> 00:02:47,666

The reset signals of the display power supply and display screen are the same

34

00:02:48,266 --> 00:02:52,100

Let's find the turn-on signal sent by the display to the display power supply,

35

00:02:52,233 --> 00:02:56,100

VOUT1 2_EN and VOUT3_EN

36

00:02:57,166 --> 00:03:01,266

The D6 pin of the display power supply is VOUT1 2_EN

37

00:03:02,466 --> 00:03:08,000

Jump to the bitmap according to the name, the turn-on signal is directly connected to the display

38

00:03:08,700 --> 00:03:14,366

VOUT1 2_EN is used to control the output of VOUT1 and VOUT2

39

00:03:14,833 --> 00:03:21,100

VOUT1 is 4.6V power supply, VOUT2 is -7V power supply

40

00:03:24,866 --> 00:03:29,066

The C5 pin of the display power supply is VOUT3_EN

41

00:03:29,900 --> 00:03:32,033

Jump to the bitmap according to the name,

42

00:03:32,900 --> 00:03:35,066

the signal is sent by the display screen and

43

00:03:35,066 --> 00:03:38,666

reaches the display power supply and the main power supply at the same time

44

00:03:39,366 --> 00:03:44,133

VOUT3_EN is mainly used to control the output of VOUT3,

45

00:03:44,600 --> 00:03:47,666

and VOUT3 is 7.3V power supply

46

00:03:49,000 --> 00:03:51,700

Let's find the inductors that convert the power supply

47

00:03:52,233 --> 00:03:55,433

Among them, we have already found the boost inductors,

48

00:03:56,133 --> 00:03:59,400

let's look for the inductors that convert the negative voltage

49

00:03:59,833 --> 00:04:06,433

The negative step-down inductors of the display power supply are L9130 and L9120

50

00:04:06,933 --> 00:04:11,300

These two inductors are specially used to convert -7V power supply

51

00:04:12,333 --> 00:04:16,400

If the inductor is removed, there will be no -7V power supply

52

00:04:18,066 --> 00:04:20,033

Ok, that's all for this video
