iPhone Wi-Fi circuit repairing

2

00:00:02,700 --> 00:00:08,566

This video mainly explains how to find the iPhone 12 Pro Max Wi-Fi 2.4G or 5G antenna line

3

00:00:11,433 --> 00:00:15,566

Step 1, find the Wi-Fi location number in the component map

4

00:00:17,300 --> 00:00:21,833

Step 2, search for the Wi-Fi location number in the schematic diagram

5

00:00:22,933 --> 00:00:27,366

Step 3, find the corresponding antenna pin in the schematic diagram

6

00:00:30,133 --> 00:00:34,600

Step 4, search for the pin identification in the schematic diagram,

7

00:00:35,300 --> 00:00:39,866

find the connected components, and finally find the antenna screw post

8

00:00:40,600 --> 00:00:45,000

We can also jump to the bitmap according to the name to view the connected components

9

00:00:47,800 --> 00:00:53,966

When checking the picture, we first open the 12 Pro Max component map, circuit diagram, point map

10

00:00:55,666 --> 00:00:58,300

Find the Wi-Fi location number in the component map

11

00:00:59,266 --> 00:01:02,700

Then search for the Wi-Fi location number in the schematic diagram

12

00:01:05,733 --> 00:01:09,366

After finding the Wi-Fi chip, find the corresponding signals

13

00:01:10,466 --> 00:01:16,266

In the functional block diagram, 2G_C0_ANT represents the 2.4G upper antenna

14

00:01:16,900 --> 00:01:20,966

2G_C1_ANT represents 2.4G lower antenna

15

00:01:21,433 --> 00:01:24,666

5G_C0_ANT represents the 5G upper antenna

16

00:01:25,366 --> 00:01:28,700

5G_C1_ANT represents the 5G lower antenna

17

00:01:29,500 --> 00:01:31,766

When the mobile phone is searching for a signal,

18

00:01:31,966 --> 00:01:35,200

it mainly relies on the upper antenna to search for the signal,

19

00:01:35,466 --> 00:01:38,366

and the lower antenna is only an auxiliary function

20

00:01:38,866 --> 00:01:40,933

When we check the weak Wi-Fi signal,

21

00:01:41,233 --> 00:01:46,400

we only need to find the signal of the upper antenna, and there is no need to search for the lower antenna

22

00:01:46,766 --> 00:01:48,900

Let's find the 5G upper antenna line

23

00:01:50,133 --> 00:01:53,300

Pin 28 of the Wi-Fi chip is the 5G upper antenna line

24

00:01:54,500 --> 00:01:57,733

It is connected to the resistor R237_W

25

00:01:59,466 --> 00:02:02,500

and connected to FL_ISG_U_W

26

00:02:03,333 --> 00:02:05,266

This component is a filter

27

00:02:05,600 --> 00:02:11,000

After passing through the filter, the line is connected to the resistor R201_W

28

00:02:11,433 --> 00:02:13,400

After passing through the resistor,

29

00:02:13,533 --> 00:02:16,533

we search for the signal name at the back end of the resistor

30

00:02:17,566 --> 00:02:23,966

In the schematic diagram, the box that does not identify the coordinates of the pin is the signal conversion box,

31

00:02:24,133 --> 00:02:25,733

we do not need to check

32

00:02:27,133 --> 00:02:28,933

Continue to search down

33

00:02:30,633 --> 00:02:34,466

The signal is connected to the resistor R363_W

34

00:02:35,266 --> 00:02:40,066

It is connected to pin 20 of U_5G_U_W after passing through the resistor

35

00:02:40,966 --> 00:02:42,933

The chip is an antenna filter

36

00:02:43,400 --> 00:02:45,466

The upper pin is the power supply pin,

37

00:02:45,733 --> 00:02:48,666

The lower left part is detection and control signals

38

00:02:49,166 --> 00:02:53,800

When looking for the line, we need to continue to look down from the ANT pin of the chip

39

00:02:54,400 --> 00:02:57,533

Pin 26 of the chip is the antenna pin, ANT

40

00:02:58,000 --> 00:03:03,933

After the 26 pin comes out, it is connected to the resistor R365_W,

41

00:03:04,266 --> 00:03:06,466

and after passing through the resistor,

42

00:03:06,700 --> 00:03:10,500

it is connected to the filter DPLXR_U_W

43

00:03:10,800 --> 00:03:16,500

After passing through the filter, the signal is connected to the resistor R301_W

44

00:03:17,033 --> 00:03:21,900

After passing through the resistor, we search for the signal at the back end of the resistor

45

00:03:22,533 --> 00:03:27,066

After searching, it is connected to pin 11 of JUAT1

46

00:03:27,433 --> 00:03:29,500

Jump to the bitmap according to the name,

47

00:03:30,433 --> 00:03:34,533

after determining the position of JUAT1, we look at the component map

48

00:03:34,966 --> 00:03:39,366

In the component map, JUAT1 represents the upper antenna connector

49

00:03:40,300 --> 00:03:45,166

In this way, all the components connected to the 5G upper antenna line are searched

50

00:03:46,500 --> 00:03:49,300

When troubleshooting the weak 5G Wi-Fi signal,

51

00:03:49,566 --> 00:03:53,200

we can fly a wire from the Wi-Fi antenna pin to the screw post

52

00:03:54,300 --> 00:03:57,333

If the Wi-Fi signal is still poor after flying the wire,

53

00:03:57,500 --> 00:03:59,766

it means that the Wi-Fi chip is damaged

54

00:04:00,033 --> 00:04:01,933

Ok, that's all for this video
