1

00:00:00,266 --> 00:00:06,866

Hello everyone, today we will learn about the hard boot process of Intel 100-300 series chipset mainboards

2

00:00:10,600 --> 00:00:13,266

After installing the 3V button battery,

3

00:00:13,866 --> 00:00:20,566

first it will generate VCCRTC power supply to provide power to the RTC circuit of the bridge

4

00:00:24,766 --> 00:00:31,100

The RTC circuit of the bridge includes the four conditions of VCCRTC, RTCRST#,

5

00:00:31,333 --> 00:00:36,200

SRTCRST# and 32.768KHz crystal oscillator

6

00:00:41,333 --> 00:00:43,766

When we plug in the battery or adapter,

7

00:00:44,500 --> 00:00:48,733

a common point will be generated through the protective isolation circuit

8

00:00:49,166 --> 00:00:52,333

Then the standby power supply of EC will be generated

9

00:00:52,700 --> 00:00:55,200

After the EC standby power supply is normal,

10

00:00:55,466 --> 00:01:00,466

the EC supplies power to the crystal oscillator pin to generate the EC standby clock

11

00:01:00,700 --> 00:01:03,233

But now many ECs have the built-in clock

12

00:01:05,033 --> 00:01:11,266

Then the EC's standby power supply is delayed by resistors and capacitors to generate an EC standby reset

13

00:01:12,200 --> 00:01:16,866

There are also some EC standby resets that are pulled up internally by the EC

14

00:01:17,533 --> 00:01:22,066

After the EC's power supply, clock, and reset are all satisfied,

15

00:01:22,233 --> 00:01:25,666

the EC will read the program and configure its own pins

16

00:01:26,266 --> 00:01:31,766

Some EC programs exist inside the EC, and some exist outside the EC.

17

00:01:32,600 --> 00:01:37,200

After reading the program, it mainly configures the GPIO pins of the EC

18

00:01:37,600 --> 00:01:43,166

Before the GPIO pins are not configured, many functions of the EC cannot work normally

19

00:01:46,800 --> 00:01:48,366

Next, let's take a look

20

00:01:51,100 --> 00:01:53,800

There are two ways to generate power for the bridge,

21

00:01:55,000 --> 00:01:58,900

one supports deep sleep, and the other does not support deep sleep

22

00:01:59,333 --> 00:02:04,100

Those who support deep sleep start from step 4 and step 5 in the block diagram

23

00:02:04,500 --> 00:02:10,166

Machines that do not support deep sleep start with steps 4, 5 outside the block diagram

24

00:02:10,733 --> 00:02:13,700

Let's take the example of not supporting deep sleep

25

00:02:15,666 --> 00:02:21,633

After the EC reads the program and configures the pins, if the EC detects the adapter

26

00:02:22,066 --> 00:02:27,833

EC will automatically turn on the bridge standby power supply VCCDSW_3P3 (deep sleep standby power supply),

27

00:02:28,533 --> 00:02:35,233

and its main standby power supply VCCPRIM_3P3 and VCC PRIM_1P0

28

00:02:41,733 --> 00:02:48,000

There is a VCCPRIM_1P8 here, which is the main standby power supply of 1.8V,

29

00:02:49,233 --> 00:02:52,033

only available in the 300 series chipset

30

00:02:52,566 --> 00:02:58,133

The 1.8V standby power supply is not available in the 100-200 series chipset

31

00:02:58,733 --> 00:03:02,933

Some machines need to press the switch to turn on the bridge standby power supply

32

00:03:03,600 --> 00:03:06,866

Then, the EC delays to send a good standby voltage signal

33

00:03:06,866 --> 00:03:14,766

to the DSW_PWROK and RSMRST# pins of the bridge to notify the bridge that the standby voltage is normal

34

00:03:18,666 --> 00:03:21,700

The bridge we are talking about here refers to the PCH

35

00:03:24,500 --> 00:03:29,000

Next, press the switch, after the EC receives the switch signal,

36

00:03:29,666 --> 00:03:36,133

the EC delays and sends a "high- low- high" jump pulse signal to the PWRBTN# pin of the bridge

37

00:03:45,233 --> 00:03:55,433

After the bridge receives this switch signal, it will send high-level SLP_S5#, SLP_S4#, SLP_S3#, etc.

38

00:04:03,000 --> 00:04:10,733

Among them, SLP_S5# or SLP_S4# will control the main power supply of the memory to 1.2V,

39

00:04:11,366 --> 00:04:15,733

the VPP power supply of the memory to 2.5V, etc.

40

00:04:16,100 --> 00:04:22,066

SLP_S3# will control the generation of secondary voltages of 3.3V and 5V,

41

00:04:22,866 --> 00:04:26,966

as well as secondary voltages of 1.0V and 1.2V

42

00:04:29,700 --> 00:04:34,100

Like this VCCPLL_OC power supply 1.2V,

43

00:04:34,266 --> 00:04:38,233

it is also converted from the main memory power supply of 1.2V

44

00:04:38,633 --> 00:04:44,666

Including VCCST, VCCPLL and other 1.0V power supplies,

45

00:04:46,366 --> 00:04:52,866

most of them are converted from the 1.0V standby power supply, which is also a secondary voltage.

46

00:04:53,400 --> 00:04:55,466

After each power supply is normal,

47

00:04:55,733 --> 00:05:00,866

a VCCST_PWRGD signal will be generated and sent to the CPU

48

00:05:03,933 --> 00:05:12,233

The CPU will send a DDR_VTT_CNTL signal to control and generate the 0.6V VTT power supply of the memory

49

00:05:14,566 --> 00:05:19,566

After each power supply is normal, an open signal to the CPU power supply is generated

50

00:05:20,333 --> 00:05:27,666

It controls the generation of CPU power supply VCCSA, and CPU core power supply VBOOT voltage

51

00:05:28,666 --> 00:05:32,500

This VBOOT voltage is also called the startup voltage

52

00:05:32,733 --> 00:05:37,700

The VBOOT voltage value can be set through the pins of the CPU power supply chip,

53

00:05:38,200 --> 00:05:41,466

some are set to 1V, and some are set to 0V

54

00:05:41,766 --> 00:05:43,666

After each power supply is normal,

55

00:05:43,900 --> 00:05:48,066

the 24MHz crystal oscillator of the bridge will start to vibrate

56

00:05:49,600 --> 00:05:57,133

Then PG summarizes, successively generates PCH_PWROK and SYS_PWROK to the bridge

57

00:05:57,566 --> 00:06:03,633

After the bridge receives PCH_PWROK, it will read the ME firmware in the BIOS

58

00:06:07,700 --> 00:06:11,400

After reading the ME, the bridge will send out clocks

59

00:06:13,000 --> 00:06:19,933

Then the bridge sends PROCPWRGD to the CPU to notify the CPU that the core power supply is normal

60

00:06:25,366 --> 00:06:29,566

Then the bridge delays and sends a platform reset PLTRST#,

61

00:06:30,133 --> 00:06:36,700

which is usually sent to the LPC bus, to Wifi, some slots and independent graphics card, etc.

62

00:06:45,433 --> 00:06:50,966

The bridge then delays to send the CPU reset signal to the RESET# pin of the CPU

63

00:06:51,400 --> 00:06:58,166

Common names of reset signals are PLTRST_PROC# or PLTRST_CPU#

64

00:07:00,400 --> 00:07:04,600

The CPU sends out SVID waveform to the CPU power supply chip,

65

00:07:05,166 --> 00:07:08,800

which is used to adjust or turn on the CPU core power supply

66

00:07:10,200 --> 00:07:15,766

If the CPU core power supply is already at a high level when VBOOT voltage is generated,

67

00:07:16,000 --> 00:07:20,400

then it will adjust the CPU core power supply through SVID at this time

68

00:07:21,800 --> 00:07:25,100

If the VBOOT voltage of the CPU is 0V,

69

00:07:25,266 --> 00:07:29,300

it will turn on the CPU core power supply through SVID at this time

70

00:07:35,400 --> 00:07:40,533

After the CPU power supply is normal and has received signals such as reset and clock

71

00:07:40,833 --> 00:07:43,900

The CPU will go to the bridge through the DMI bus,

72

00:07:44,466 --> 00:07:50,566

and then read the BIOS through the SPR bus of the bridge, and start self-testing the entire mainboard

73

00:07:51,100 --> 00:07:52,500

When the memory is checked,

74

00:07:53,266 --> 00:07:58,500

the bridge will read the SPD information of the memory through the system management bus

75

00:08:02,766 --> 00:08:07,533

Then the bridge sends out a memory reset signal, DRAM_RESET#

76

00:08:08,766 --> 00:08:14,733

After checking the memory, the CPU will send the SVID waveform again to the CPU power supply chip,

77

00:08:15,100 --> 00:08:20,900

which is used to control the generation of integrated display power supply VCCGT

78

00:08:21,366 --> 00:08:27,000

But for most models, the integrated display power supply will be turned off in an instant

79

00:08:27,366 --> 00:08:30,700

Other power supplies can be shared inside the CPU

80

00:08:31,066 --> 00:08:34,166

When the program consumes a lot of graphics card,

81

00:08:34,466 --> 00:08:37,900

the integrated display power supply will be awakened again

82

00:08:38,566 --> 00:08:43,566

Ok, this is the hard boot process of Intel 100~300 series chipset mainboards
