1

00:00:00,300 --> 00:00:07,100

Hello everyone锛宼oday we will learn about the generation process of each power supply in the Apple A2337 circuit

2

00:00:07,633 --> 00:00:12,900

We have introduced the generation of 3.8V main standby power supply in the previous course

3

00:00:16,833 --> 00:00:23,666

The main standby power supply directly supplies power to the two power chips of U8100 and U7700

4

00:00:32,466 --> 00:00:39,266

Among them, U7700 is the auxiliary power chip, and U8100 is the main power chip

5

00:00:40,900 --> 00:00:46,000

Because after this machine is plugged in, it will turn on and power on automatically

6

00:00:47,500 --> 00:00:51,233

Therefore, we will not introduce the steps of pressing the switch

7

00:00:54,166 --> 00:00:58,733

When the main chip gets the main power supply, its crystal oscillator will start to work

8

00:01:04,833 --> 00:01:08,766

The position number of the crystal oscillator is Y8301,

9

00:01:12,166 --> 00:01:18,266

and the frequency is 32.768KHz, which is in this position in the real product

10

00:01:18,733 --> 00:01:22,533

The big one is the main power chip, and the small one is the secondary power chip

11

00:01:22,900 --> 00:01:29,333

There is a crystal oscillator next to the main power supply, which is a 32.768KHz crystal oscillator

12

00:01:29,933 --> 00:01:32,500

After the crystal oscillator starts to oscillate,

13

00:01:32,866 --> 00:01:37,333

the main power chip and the secondary power chip will communicate through the I2C bus

14

00:01:43,900 --> 00:01:47,166

The auxiliary power chip is managed by the main power chip

15

00:01:48,966 --> 00:01:52,900

The main power supply chip will control and generate various power supplies,

16

00:01:56,033 --> 00:02:01,933

including: hard disk power supply, various power supplies required by the M1 processor,

17

00:02:16,900 --> 00:02:26,366

such as 1.06V, 0.6V, 1.25V, 0.72V, PPVDD_GPU_AWAKE, etc.

18

00:02:30,833 --> 00:02:33,933

After each power supply is sent to the M1 processor,

19

00:02:34,266 --> 00:02:38,833

the 24MHz crystal oscillator of the M1 processor starts to vibrate

20

00:02:45,700 --> 00:02:50,833

At the same time, the M1 processor will also get the clock provided by the power chip

21

00:02:57,166 --> 00:03:02,000

This is the 32.768KHz clock sent by the power chip

22

00:03:06,100 --> 00:03:11,100

Then the power chip will continue to provide clock and reset signals to the M1 processor

23

00:03:11,466 --> 00:03:17,366

One is PMU_RESET_L, one is TPT_TST_CLKOUT

24

00:03:24,700 --> 00:03:28,666

After the M1 processor gets power supply, clock and reset signal,

25

00:03:28,933 --> 00:03:32,133

it starts to read the information in SOCROM

26

00:03:38,666 --> 00:03:44,633

If there is a problem with the information in the SOCROM, or M1 cannot read this program,

27

00:03:48,100 --> 00:03:50,766

it will cause the adapter not to boost the voltage

28

00:03:55,700 --> 00:03:58,200

After the M1 processor reads the program,

29

00:03:58,366 --> 00:04:02,666

it will communicate with the CD3217 through the I2C0 bus

30

00:04:04,966 --> 00:04:09,233

Before this, the Thunderbolt chip must first read the program information,

31

00:04:12,633 --> 00:04:16,400

and complete the communication with CD3217

32

00:04:20,666 --> 00:04:24,000

After receiving the information sent by the M1 processor,

33

00:04:25,200 --> 00:04:29,633

the CD3217 communicates with the adapter through the CC bus,

34

00:04:31,333 --> 00:04:36,233

requesting the adapter to provide a voltage and current that can satisfy the machine's work

35

00:04:47,466 --> 00:04:53,266

Then the adapter will output a boosted 20V according to the requirements of CD3217

36

00:05:02,000 --> 00:05:05,033

In this boost process, many chips are involved,

37

00:05:06,300 --> 00:05:13,733

such as Thunderbolt chips, logic chips, chip CD3217, charging chips, and various power chips

38

00:05:17,600 --> 00:05:21,500

While the M1 processor is communicating with the CD3217,

39

00:05:21,766 --> 00:05:24,800

it is also reading the information of its own logic chip

40

00:05:26,833 --> 00:05:28,800

There is a program in this logic chip,

41

00:05:29,066 --> 00:05:31,300

the program is bound to the Apple system,

42

00:05:37,200 --> 00:05:39,566

and this chip is bound to the M1 processor

43

00:05:43,566 --> 00:05:49,100

Therefore, when replacing the M1 processor, it must be replaced together with the chip

44

00:05:50,100 --> 00:05:55,500

Next, the M1 processor reads the system information in the hard disk through the PCIE bus,

45

00:06:04,033 --> 00:06:07,766

and reads some underlying data of the hard disk through the I2C bus

46

00:06:08,933 --> 00:06:14,666

But after our test, it does not need to read hard disk data before the adapter boosts the voltage

47

00:06:15,433 --> 00:06:19,633

It will be read after the adapter boosts and starts to enter the system

48

00:06:22,300 --> 00:06:26,566

The read system information needs to be compared with the information in the logic chip

49

00:06:26,566 --> 00:06:28,900

to verify the integrity of the system

50

00:06:30,466 --> 00:06:33,433

Ok, this is the generation process of each power supply
