1

00:00:00,266 --> 00:00:05,833

Hello everyone, today we will learn about the boosted circuit of the Apple A2337 adapter

2

00:00:09,933 --> 00:00:14,133

After the CD3217 and the adapter complete the communication,

3

00:00:14,366 --> 00:00:17,400

the adapter outputs a boosted 20V power supply

4

00:00:20,166 --> 00:00:24,866

After the 20V power supply is internally transferred through the CD3217 chip,

5

00:00:25,333 --> 00:00:29,733

it is directly supplied to the generating circuit of the common point through fuse

6

00:00:41,966 --> 00:00:45,566

After the 20V voltage is divided by resistors in series,

7

00:00:46,366 --> 00:00:52,866

the CHGR_AUX_DET signal is generated, which is the adapter voltage detection signal

8

00:00:55,433 --> 00:00:58,700

When the charging chip detects that the adapter voltage is boosted,

9

00:00:59,300 --> 00:01:01,133

it will work in the step-down mode,

10

00:01:03,200 --> 00:01:09,300

and step down the 20V voltage to 12V through PWM to provide power to the common point

11

00:01:15,333 --> 00:01:19,033

Before the adapter is not boosted, the voltage is 5V

12

00:01:22,966 --> 00:01:27,100

The charging chip works in boost mode, boosting 5V to 12V

13

00:01:32,433 --> 00:01:38,800

When the adapter is boosted, the charging chip will step down the 20V voltage to 12V through PWM

14

00:01:41,000 --> 00:01:45,300

Therefore, the voltage of the common point is always kept at 12V

15

00:01:47,366 --> 00:01:52,700

This common point power supply can not only charge the battery, but also provide power to the system

16

00:01:55,166 --> 00:01:57,966

The common point voltage is equal to the battery voltage

17

00:02:04,733 --> 00:02:08,766

The adapter and battery can provide power to the common point at the same time

18

00:02:10,200 --> 00:02:13,066

This is the workflow after the adapter is boosted
