1

00:00:00,400 --> 00:00:05,466

Hello everyone, today we will learn about the generation process of the common point before the adapter boost

2

00:00:07,333 --> 00:00:10,000

First of all, after we plug in the adapter,

3

00:00:10,300 --> 00:00:15,500

the CC bus of the adapter will be pulled down by the internal resistance of CD3217

4

00:00:18,633 --> 00:00:21,433

Then, the adapter will output the 5V before boost

5

00:00:25,500 --> 00:00:30,700

If the CC bus communication is interrupted, the adapter will not output voltage

6

00:00:36,300 --> 00:00:42,300

The adapter outputs 5V before boost to supply power to the VBUS pin of CD3217

7

00:00:45,900 --> 00:00:52,400

CD3217 will generate LDO_3V3 to provide power for U2890

8

00:01:00,833 --> 00:01:06,566

Then, CD3217 reads the data in the U2890 chip through the SPI bus

9

00:01:20,100 --> 00:01:25,700

At the same time, CD3217 will also control the conduction of the internal MOS tube

10

00:01:26,200 --> 00:01:31,700

It converts the power supply of the adapter to an external PPDCIN_G3H power supply

11

00:01:34,566 --> 00:01:36,400

This is a 5V power supply

12

00:01:38,966 --> 00:01:44,300

This power supply provides power to the P_IN pin of the charging chip through the current-sensing resistor

13

00:01:50,566 --> 00:01:52,700

After the pin is powered by 5V,

14

00:01:53,133 --> 00:01:58,166

the charging chip will output a linear voltage of 5V from the VDDP pin,

15

00:01:59,466 --> 00:02:04,033

and provide power to the VDDA and CELL pins of the charging chip

16

00:02:11,433 --> 00:02:15,100

The charging chip will drive the four switch tubes to turn on in turn

17

00:02:15,100 --> 00:02:17,966

according to the charging voltage set by the CELL pin,

18

00:02:24,800 --> 00:02:30,100

and work in the boost mode to boost the power supply of the adapter from 5V to 12.2V

19

00:02:30,100 --> 00:02:32,300

to provide power to the common point

20

00:02:39,200 --> 00:02:42,000

At the same time, it can also charge the battery

21

00:03:02,366 --> 00:03:06,300

Here is the battery voltage, which can be sent to the common point

22

00:03:07,866 --> 00:03:11,566

After the voltage of the adapter rises from 5V to 12V,

23

00:03:11,733 --> 00:03:14,400

it can also provide power to the common point

24

00:03:16,400 --> 00:03:20,433

The battery and the adapter can supply power to the common point at the same time

25

00:03:24,033 --> 00:03:29,233

The common point voltage needs to be returned to provide power to the PBUS pin of the charging chip

26

00:03:29,300 --> 00:03:32,266

to detect whether the common point voltage is normal

27

00:03:37,500 --> 00:03:42,033

Ok, this is the generation process of the common point before the adapter boost
