1

00:00:01,100 --> 00:00:05,233

Hello everyone, today we will learn about the generation process of the standby power supply

2

00:00:05,233 --> 00:00:10,600

PP3V3_G3H_RTC in the Apple A2159 circuit

3

00:00:13,266 --> 00:00:19,500

PP3V3_G3H_RTC is generated by TPS62180 control

4

00:00:22,100 --> 00:00:23,766

Let's search in the circuit

5

00:00:31,733 --> 00:00:36,400

This is a tiny PWM controller, which integrates two upper and lower tubes

6

00:00:40,533 --> 00:00:44,566

Among them, VIN1 provides power supply to the D-level of the first tube,

7

00:00:47,733 --> 00:00:50,666

and the phase pin of the first road is SW1

8

00:00:52,166 --> 00:00:55,200

The D-stage of the second tube is powered by VIN2,

9

00:00:56,866 --> 00:00:59,866

and the phase pin of the second road is SW2

10

00:01:06,166 --> 00:01:08,500

This power supply comes from the common point

11

00:01:11,133 --> 00:01:15,033

We trace the name of its external power supply and find its source,

12

00:01:20,566 --> 00:01:26,466

we found that it was renamed after the common point voltage passed through a current-sensing resistor

13

00:01:26,466 --> 00:01:30,133

to provide the main power supply for this U6903

14

00:01:42,033 --> 00:01:47,366

In addition to the power supply, this chip also needs to receive an open signal, EN

15

00:01:52,700 --> 00:01:57,866

This open signal comes from the CHGR_EN_MVR sent by the charging chip

16

00:01:58,633 --> 00:02:03,566

We searched for this EN and found that it comes from ISL9240,

17

00:02:12,233 --> 00:02:17,900

the internal name is EN_MVR, and the external name is CHG_EN_MVR

18

00:02:24,900 --> 00:02:29,300

With this open signal, it will control the work of the two upper and lower tubes,

19

00:02:29,400 --> 00:02:31,600

and generate two power supply outputs

20

00:02:39,666 --> 00:02:42,266

The back end of the inductor is connected together, and the PP3V3_G3H_RTC is generated by two PWMs

21

00:02:43,666 --> 00:02:48,766

and the PP3V3_G3H_RTC is generated by two PWMs

22

00:02:50,633 --> 00:02:54,633

This is a power supply with a maximum output current of 6A,

23

00:02:55,200 --> 00:02:58,600

and the operating frequency is 1.25MHz

24

00:03:02,166 --> 00:03:08,766

The external name is changed to PP3V3_G3H_RTC after the current-sensing resistor

25

00:03:10,400 --> 00:03:15,333

This is the first generation process of PP3V3_G3H_RTC

26

00:03:17,366 --> 00:03:18,833

let's review again

27

00:03:21,366 --> 00:03:26,133

The main power supply of PPBUS_G3H is what we talked about in the last lesson,

28

00:03:29,600 --> 00:03:34,433

it is generated by the control of the common point circuit PPBUS_G3H

29

00:03:35,266 --> 00:03:40,833

This common point should be returned to provide power to the PBUS_PWR pin of the charging chip

30

00:03:41,433 --> 00:03:46,933

The charging chip will send an EN signal to turn on the PP3V3_G3H_RTC

31

00:03:49,000 --> 00:03:50,933

After the power supply is generated,

32

00:03:51,366 --> 00:03:57,333

it mainly provides the main power supply for the U6940 and U7800 power chips

33

00:04:00,766 --> 00:04:05,933

Ok, this is the generation process of PP3V3_G3H_RTC power supply
