Hello everyone, today we will learn about the working conditions of the T2 chip in the Apple A2159 circuit

2

00:00:08,766 --> 00:00:12,666

The working conditions of the T2 chip are all provided by the power chip

3

00:00:14,500 --> 00:00:19,366

First of all, this PP1V8_ refers to the 1.8V standby power supply

4

00:00:23,900 --> 00:00:27,600

The PP1V8_ below is also the 1.8V power supply

5

00:00:27,833 --> 00:00:31,533

There are PP1V1, PP0V82, etc.

6

00:00:39,633 --> 00:00:45,900

Including T2 core power supply, T2 upper cover memory power supply, and other modules power supply

7

00:00:50,066 --> 00:00:54,166

Each power supply is generated by PWM control inside the power chip

8

00:00:58,300 --> 00:01:02,966

For example PPVDDCPU_AWAKE, let's search in the circuit diagram

9

00:01:05,966 --> 00:01:12,100

This power supply comes from here, its voltage value is 0.625- 1.06V,

10

00:01:12,700 --> 00:01:16,233

and the maximum output current is 13.4A

11

00:01:21,433 --> 00:01:24,166

It is output by paralleling 4 inductors here

12

00:01:26,900 --> 00:01:32,033

These 4 inductors represent that there are 4 PWM circuits inside the power chip

13

00:01:33,466 --> 00:01:37,300

The bottom 0 ohm resistor is its feedback regulation

14

00:01:40,733 --> 00:01:44,466

When we drew this timing diagram, we only drew one inductor

15

00:01:46,033 --> 00:01:49,800

In fact, four inductors work together to generate the power supply

16

00:01:52,400 --> 00:01:54,600

The same is true for other power supplies,

17

00:01:54,733 --> 00:01:59,933

some of which are also provided by multiple inductors and multiple PWM circuits

18

00:02:02,533 --> 00:02:08,566

For example, this PP0V82_SLPDDR is a DDR memory power supply

19

00:02:09,400 --> 00:02:14,200

Its voltage value is 0.82V and the output current is 6A

20

00:02:16,566 --> 00:02:23,500

Two inductors are used here, which means that it needs two PWM circuits to provide 0.82V power supply

21

00:02:27,766 --> 00:02:32,333

There is a 0 ohm feedback resistor at the back end of each PWM inductor

22

00:02:33,433 --> 00:02:38,333

Each VDD_BUCK here provides the main power supply for each PWM circuit inside

23

00:02:46,200 --> 00:02:52,033

The various power supplies output by the power supply chip provide working conditions for this T2 chip

24

00:02:52,766 --> 00:02:54,800

After each power supply is normal,

25

00:02:56,966 --> 00:03:02,266

the 24M crystal oscillator of T2 starts to work to generate the clock frequency

26

00:03:05,966 --> 00:03:11,033

The power chip delays to send a reset signal to the COLD_RESET pin of the T2 chip

27

00:03:17,866 --> 00:03:21,233

After the T2 chip has power supply, clock, and reset,

28

00:03:21,433 --> 00:03:23,933

it needs to read the program in the SOCROM,

29

00:03:24,433 --> 00:03:26,900

configure its pins, and start running

30

00:03:31,066 --> 00:03:35,466

Then, the T2 chip will communicate with the CD3217 through the I2C bus,

31

00:03:36,300 --> 00:03:38,200

usually through the I2C0 bus

32

00:03:46,300 --> 00:03:50,633

Before the CD3217 communicates with the T2 chip, it has read the program

33

00:03:50,733 --> 00:03:53,600

and the Thunderbolt chip has also read the program

34

00:03:57,333 --> 00:04:01,300

Then CD3217 gets the instruction sent by the T2 chip

35

00:04:07,266 --> 00:04:13,400

After they communicate with each other, CD3217 communicates with the adapter through the CC bus,

36

00:04:13,833 --> 00:04:18,966

requesting the adapter to output a power supply that can satisfy the normal operation of the machine

37

00:04:22,600 --> 00:04:26,133

According to the request of CD3217 and T2 chip,

38

00:04:27,000 --> 00:04:32,866

the adapter will output a boosted 20V to supply power to the VBUS pin of CD3217

39

00:04:36,400 --> 00:04:39,966

CD3217 will convert the VBUS power supply

40

00:04:41,400 --> 00:04:45,933

At this time, PPDCIN_G3H gets 20V power supply

41

00:04:47,833 --> 00:04:52,333

For this charging chip, AUX_DET is an adapter voltage detection pin

42

00:04:56,333 --> 00:04:59,700

When it detects that the adapter voltage rises to 20V,

43

00:05:00,233 --> 00:05:02,200

it will work in the BUCK step-down mode,

44

00:05:04,566 --> 00:05:08,300

and after the 20V of the adapter is stepped down by PWM,

45

00:05:08,566 --> 00:05:11,800

a common point voltage of 12V is obtained

46

00:05:13,900 --> 00:05:16,666

The voltage of the common point is always constant,

47

00:05:16,900 --> 00:05:22,866

no matter the adapter voltage is 5V or 20V, the common point voltage is always 12V

48

00:05:25,800 --> 00:05:28,500

Ok, this is the working condition of the T2 chip
