Hello everyone, today we will learn about the power-on circuit in the Apple A2159 circuit

2

00:00:07,433 --> 00:00:12,166

Apple A2159 uses Intel's eighth-generation processor

3

00:00:14,633 --> 00:00:17,466

Therefore, when we analyze the boot circuit,

4

00:00:17,900 --> 00:00:22,800

we need to analyze it according to the timing of Intel's eighth-generation CPU chipset

5

00:00:24,600 --> 00:00:29,033

We have introduced the standby conditions of the T2 chip and CPU in the previous course,

6

00:00:33,233 --> 00:00:35,366

today we will look at the power-on circuit

7

00:00:36,266 --> 00:00:41,366

First, the switch key is connected to the connector J6600 of the mainboard

8

00:00:44,600 --> 00:00:49,500

When we press the switch, a "high --> low --> high" pulse signal is generated to the power chip

9

00:00:52,466 --> 00:00:56,500

The name of this switch signal is called PMU_ONOFF_L

10

00:00:58,300 --> 00:01:00,800

After the power supply chip receives the switch signal,

11

00:01:02,266 --> 00:01:08,733

it sends a "high --> low --> high" pulse jump from the SYS_BTN pin to the PWRBTN# pin of the CPU

12

00:01:17,733 --> 00:01:21,933

The name of this switch signal is PCH_PWRBTN_L

13

00:01:29,766 --> 00:01:33,700

After the CPU meets the standby condition and receives the switch signal,

14

00:01:35,166 --> 00:01:42,366

it will send out various signals such as SLP_S5#, SLP_S4#, SLP_S3#, etc.

15

00:01:45,600 --> 00:01:49,633

But in this machine, the SLP_S*# signal is not used

16

00:01:50,666 --> 00:01:53,066

After the CPU receives the switch signal,

17

00:01:55,400 --> 00:01:58,833

it will communicate with the T2 chip through the eSPI bus

18

00:02:03,400 --> 00:02:09,033

At the same time, the CPU will send a CPU_C10_GATE* open signal to the power chip

19

00:02:16,100 --> 00:02:20,866

After the T2 chip receives the power-on command transmitted by the eSPI bus,

20

00:02:21,466 --> 00:02:24,533

it will communicate with the power chip through the I2C bus

21

00:02:32,566 --> 00:02:37,900

The power chip will send out various EN signals to turn on the subsequent power supplies

22

00:02:39,966 --> 00:02:43,600

Ok, this is the power-on circuit for the A2159
