Hello everyone, today we're going to learn about the data preservation maintenance of the Apple laptop

2

00:00:07,766 --> 00:00:12,233

Hard drive data preservation means that there are important data stored in the hard drive,

3

00:00:12,866 --> 00:00:14,533

but the computer is damaged,

4

00:00:15,533 --> 00:00:20,666

and it is necessary to read out and save the important data in the hard drive through special means,

5

00:00:21,333 --> 00:00:23,633

which is called data preservation maintenance.

6

00:00:25,833 --> 00:00:28,966

If the laptop using these two hard drives is damaged,

7

00:00:34,000 --> 00:00:35,500

if you want to keep the data,

8

00:00:35,966 --> 00:00:40,533

first of all, we must make sure that the hard drive itself has no problems

9

00:00:42,400 --> 00:00:46,633

If the hard drive itself is not damaged, the data in the hard drive can be saved

10

00:00:49,133 --> 00:00:54,400

If the hard drive itself is damaged, the data stored in the hard drive will basically not be preserved

11

00:00:56,000 --> 00:00:59,600

The hard drive itself is not broken, but the mainboard is damaged,

12

00:00:59,800 --> 00:01:04,066

we can try to repair the mainboard, and then read the data in the hard drive

13

00:01:05,733 --> 00:01:09,333

If the mainboard cannot be repaired, we can remove the hard drive,

14

00:01:10,333 --> 00:01:16,100

install it in another laptop of the same type, and read the data on the hard drive when it is turned on

15

00:01:18,400 --> 00:01:23,500

For example, this A1466, this hard drive can be taken out,

16

00:01:28,433 --> 00:01:33,233

inserted into another laptop, turned on and then read the data inside

17

00:01:33,600 --> 00:01:37,033

If the hard drive is damaged, the machine cannot be turned on,

18

00:01:37,666 --> 00:01:41,366

the system cannot be entered, and the data cannot be recovered.

19

00:01:42,633 --> 00:01:47,533

It is more difficult to save data on the hard drive of Apple laptops with T2 chips

20

00:01:51,033 --> 00:01:54,166

This is a T2 chip, and this is a solid state drive

21

00:01:56,766 --> 00:02:00,333

Its hard drive master control is integrated inside the T2 chip

22

00:02:00,766 --> 00:02:06,166

Laptops that use the above hard drives, if they are damaged and we want to retain the data,

23

00:02:07,533 --> 00:02:11,300

first of all, make sure that the hard drives have no problems

24

00:02:12,066 --> 00:02:15,866

If the hard drive is damaged, the data in the hard drive cannot be saved

25

00:02:16,866 --> 00:02:19,966

If the hard drive is not damaged, but the mainboard is damaged,

26

00:02:20,300 --> 00:02:23,100

we can try to repair the mainboard and read the data

27

00:02:24,700 --> 00:02:28,000

If the mainboard cannot be repaired, we need to move the board,

28

00:02:29,300 --> 00:02:34,200

that is, move the hard drive kit to another good mainboard to read the hard drive data,

29

00:02:35,766 --> 00:02:37,733

this operation is more troublesome

30

00:02:38,600 --> 00:02:41,366

Next, let's take a look at the hard drive kit

31

00:02:41,900 --> 00:02:44,500

For laptops with T2 security chips,

32

00:02:45,066 --> 00:02:49,900

the precondition for data protection is that the four-piece set must function normally

33

00:02:53,300 --> 00:02:58,566

The four-piece set refers to the T2 chip, hard drive, logic chip and SOCROM

34

00:03:03,633 --> 00:03:09,966

The 4-piece set is indispensable, and the function of the 4-piece set must be normal and cannot be damaged

35

00:03:17,066 --> 00:03:22,366

After moving the four-piece set, first turn it on to see if it can enter the system normally

36

00:03:22,666 --> 00:03:26,466

If it can enter the system normally, you can read the data directly

37

00:03:27,266 --> 00:03:31,466

If it cannot enter the system, we can repair the T2 firmware first

38

00:03:31,766 --> 00:03:34,200

T2 firmware refers to this Bridge OS

39

00:03:36,000 --> 00:03:39,866

If we still cannot enter the system after repairing the T2 firmware,

40

00:03:40,100 --> 00:03:42,366

we can only restore the T2 firmware

41

00:03:45,466 --> 00:03:50,233

If it really comes to the step of restoring the T2 firmware, it is meaningless

42

00:03:50,966 --> 00:03:53,933

Because in the process of restoring the T2 firmware,

43

00:03:54,633 --> 00:03:59,300

its hard drive data will be completely erased, which is a failure to save data

44

00:04:01,100 --> 00:04:05,533

If the T2 firmware is damaged, or the bottom layer of the hard drive is damaged,

45

00:04:06,133 --> 00:04:08,300

or the chip data of the T2 is damaged,

46

00:04:10,833 --> 00:04:14,433

it will be in recovery mode or DFU mode when it is turned on

47

00:04:16,600 --> 00:04:19,900

In this case, you can try to repair the device

48

00:04:22,600 --> 00:04:25,600

If the repair can pass, the data can be saved,

49

00:04:28,966 --> 00:04:32,533

if the repair is not successful, the data will not be saved

50

00:04:32,833 --> 00:04:37,266

The hard drive should be disassembled in sequence and replaced in the same position

51

00:04:38,100 --> 00:04:41,166

For example, if we want to move the four-piece set,

52

00:04:42,666 --> 00:04:48,233

U8600 must be soldered back to the U8600 position of the good mainboard,

53

00:04:49,166 --> 00:04:54,800

and U8700 must also be soldered to the U8700 position of the good mainboard

54

00:04:55,966 --> 00:05:01,133

One-to-one, the same position must be moved over, the order must not be wrong,

55

00:05:01,800 --> 00:05:05,066

and the machine cannot be turned on if it is installed incorrectly
