1

00:00:00,300 --> 00:00:05,700

Hello everyone, today we will learn how to expand and reduce the capacity of Apple laptop hard drives

2

00:00:07,266 --> 00:00:11,300

Ordinary Apple laptop hard drive expansion is actually simple

3

00:00:11,766 --> 00:00:16,566

For laptops using these two hard drives, if you want to expand or reduce capacity,

4

00:00:16,933 --> 00:00:21,033

you can directly replace the same type of large-capacity hard drive

5

00:00:23,133 --> 00:00:28,633

For example, for this mechanical hard drive, if 320GB is not enough,

6

00:00:28,866 --> 00:00:34,200

you can replace it with 1TB or 2TB,just replace it with the same type

7

00:00:39,400 --> 00:00:47,633

Laptops with solid-state drives, such as A1989 and A1990, are equipped with T2 chips

8

00:00:50,300 --> 00:00:54,300

And usually the standard configuration is 256GB.

9

00:00:58,133 --> 00:01:03,733

If you want to upgrade to 512GB, you need to have 4 hard drive chips as a group

10

00:01:04,433 --> 00:01:09,233

The combined capacity of 4 hard drive chips is equal to 512GB

11

00:01:09,633 --> 00:01:11,400

Just replace it in order

12

00:01:12,333 --> 00:01:16,866

For example, this A1989 has a total of 4 hard drives,

13

00:01:17,333 --> 00:01:19,966

two on the front and two on the back of the mainboard

14

00:01:21,566 --> 00:01:26,100

We need to find a set of hard drives with a larger capacity than the original hard drives

15

00:01:26,500 --> 00:01:33,600

The capacity of the four hard drives adds up to 512GB, so we will replace these four hard drives

16

00:01:34,233 --> 00:01:40,133

After the replacement, restore the T2 firmware, is is also called flashing T2

17

00:01:42,700 --> 00:01:46,033

There is no need to distinguish the manufacturers of hard drives,

18

00:01:46,500 --> 00:01:50,433

and hard drives from different manufacturers can also be substituted

19

00:01:50,733 --> 00:01:53,800

There is no need to change the configuration resistors,

20

00:01:55,333 --> 00:02:00,200

just find 4 hard drives with larger capacity than the original machine and replace them

21

00:02:00,866 --> 00:02:05,633

It should be noted that the hard drive above 1TB cannot be replaced directly

22

00:02:06,133 --> 00:02:11,733

Because they are all customized versions from 1TB to 4TB, their T2 chips are different

23

00:02:12,066 --> 00:02:16,133

Moreover, this customized version of the T2 chip is hard to find

24

00:02:16,233 --> 00:02:19,366

unless it is directly removed from the customized version

25

00:02:20,866 --> 00:02:25,400

If you want to drop from 512GB to 256GB

26

00:02:25,666 --> 00:02:31,166

also directly find 4 hard drives with a capacity of 256GB as a group,

27

00:02:31,500 --> 00:02:36,633

and replace them according to the order of the hard drive positions, and then flash T2

28

00:02:37,200 --> 00:02:41,366

For example, we have to remove the U8600 on one mainboard

29

00:02:41,700 --> 00:02:46,466

and install it in the same position as the U8600 on another mainboard

30

00:02:51,800 --> 00:02:59,366

Like this A2159, the version of low configuration is only 128GB, two hard drives,

31

00:03:00,000 --> 00:03:02,133

one on the front and one on the back,

32

00:03:03,266 --> 00:03:06,366

and there are two pads on this side that are idle

33

00:03:10,666 --> 00:03:17,433

If you want to expand to 256GB, you cannot directly install a hard drive on the idle pad

34

00:03:19,133 --> 00:03:22,600

Because there are many chips next to it that are not installed,

35

00:03:23,533 --> 00:03:27,666

such as the power supply chip of this hard drive, and these resistors

36

00:03:31,566 --> 00:03:33,600

If you want to install 4 hard drives,

37

00:03:33,900 --> 00:03:37,133

you must find a group of 4 hard drives to replace

38

00:03:38,000 --> 00:03:42,766

It can be disassembled on A1989 or other different models,

39

00:03:43,866 --> 00:03:47,400

because A1989 is a group of four hard drives

40

00:03:48,766 --> 00:03:50,800

If these four are disassembled,

41

00:03:52,866 --> 00:03:58,600

the hard drive power supply chip on the idle pad and the surrounding capacitors and resistors must be soldered

42

00:04:01,266 --> 00:04:02,600

How should we make it?

43

00:04:04,733 --> 00:04:07,766

Search for SSD:4L in the circuit diagram,

44

00:04:10,666 --> 00:04:16,033

as long as there are components with SSD:4L, all components must be added

45

00:04:16,366 --> 00:04:20,600

This operation is too troublesome, this method is not recommended

46

00:04:21,133 --> 00:04:27,533

How should we operate? Like this A2159, its capacity is 128GB,

47

00:04:29,400 --> 00:04:38,733

to expand to 256 or 512, we usually remove the hard drive from A1932 or A2179

48

00:04:39,533 --> 00:04:45,033

These models also have two hard drives, and the capacity is above 256GB

49

00:04:45,833 --> 00:04:51,300

After dismantling, there is no need to fill the pad, just solder it on the original position

50

00:04:51,700 --> 00:04:55,333

After the replacement, we need to flash the T2 firmware

51

00:04:55,666 --> 00:05:00,200

If the original machine has 4 hard drives, we want to change it to 2 hard drives

52

00:05:03,000 --> 00:05:06,066

Search for SSD:2L in the circuit diagram

53

00:05:07,366 --> 00:05:10,233

Add all the components with SSD:2L,

54

00:05:13,766 --> 00:05:16,700

remove all the components with SSD:4L

55

00:05:17,966 --> 00:05:22,533

Ok, this is how to expand and reduce the capacity of Apple laptop hard drives
