1

00:00:00,200 --> 00:00:04,700

Hello everyone, today we will learn how to upgrade the memory of Apple laptops

2

00:00:07,700 --> 00:00:11,666

Ordinary Apple laptop memory upgrade is actually very simple

3

00:00:12,233 --> 00:00:14,266

For this kind of pluggable memory,

4

00:00:14,633 --> 00:00:17,933

we can directly replace a memory with a larger capacity

5

00:00:18,400 --> 00:00:22,866

In the process of replacement, some problems need to be paid attention to

6

00:00:23,433 --> 00:00:29,400

For example, the memory capacity cannot exceed the maximum memory limit supported by the chipset

7

00:00:34,433 --> 00:00:35,666

What does that mean?

8

00:00:35,900 --> 00:00:41,233

For example, Intel's sixth-generation CPU supports a maximum of 16GB

9

00:00:41,566 --> 00:00:45,100

After the upgrade, the memory cannot exceed this limit

10

00:00:47,633 --> 00:00:51,733

If it exceeds, it can only recognize up to 16GB

11

00:00:55,433 --> 00:01:01,266

DDR3 memory, DDR4 memory, and DDR5 memory, they cannot be mixed

12

00:01:01,800 --> 00:01:05,266

Try to make the memory frequency the same as the original memory

13

00:01:08,833 --> 00:01:12,300

Here's how to upgrade the memory of a regular Apple laptop

14

00:01:16,233 --> 00:01:19,533

Next, there is another type of onboard memory

15

00:01:20,000 --> 00:01:26,100

For models like A1465, A1466, and A1502,

16

00:01:26,500 --> 00:01:28,533

their memory is soldered to the mainboard

17

00:01:28,733 --> 00:01:31,933

This kind of memory upgrade is a little bit more difficult

18

00:01:32,566 --> 00:01:35,633

Because it does not support plugging and unplugging,

19

00:01:36,366 --> 00:01:37,500

when upgrading,

20

00:01:37,833 --> 00:01:43,066

you must buy 4 memory chips with a larger capacity than the original machine for replacement

21

00:01:49,633 --> 00:01:53,000

When replacing, we need to configure its memory parameters

22

00:01:53,000 --> 00:01:58,500

according to the table of CPU DRAM SPD Straps provided in the circuit diagram

23

00:02:02,366 --> 00:02:06,400

Let's take a look, the memory of the original machine is 4GB,

24

00:02:12,066 --> 00:02:14,166

if you want to upgrade to 8G,

25

00:02:15,866 --> 00:02:18,800

you can use Hynix memory or Samsung memory

26

00:02:22,666 --> 00:02:25,700

You can also use Elpida or Micron memory

27

00:02:27,866 --> 00:02:30,533

It can also be upgraded to 16GB

28

00:02:40,866 --> 00:02:43,700

If you upgrade from 4GB to 8GB,

29

00:02:44,166 --> 00:02:48,600

you need to modify the configuration according to this configuration table

30

00:02:51,066 --> 00:02:54,900

These original machines are "L", which means low level

31

00:02:58,066 --> 00:03:02,400

After the upgrade, they are still "L", so we don't care about them.

32

00:03:02,766 --> 00:03:08,466

Like this one, it used to be "L", but now it becomes "H", high level state,

33

00:03:09,000 --> 00:03:11,133

this one should be changed to high level

34

00:03:11,633 --> 00:03:16,800

We just need to search for this RAMCFG2 pin in the circuit diagram

35

00:03:19,033 --> 00:03:24,833

RAMCFG2 is in this place, there is a pull-up resistor and a pull-down resistor

36

00:03:29,666 --> 00:03:33,800

The original machine is 4GB, after changing to 8GB,

37

00:03:34,166 --> 00:03:38,600

the request in the form is changed to "L", we can install the pull-down resistor

38

00:03:39,700 --> 00:03:46,800

RAMCFG0 and RAMCFG1 must be low, and these two pull-down resistors must be installed

39

00:03:51,133 --> 00:03:56,466

For RAMCFG2 to become high level, this pull-down resistor must be removed,

40

00:03:57,400 --> 00:03:59,866

and this pull-up resistor must be installed, RAMCFG2

41

00:04:01,733 --> 00:04:04,633

The RAMCFG3 pin remains low

42

00:04:06,600 --> 00:04:11,500

The four original pins are all low, and they are all equipped with pull-down resistors

43

00:04:13,733 --> 00:04:20,866

After upgrading to 8GB memory, we only need to move the pull-down resistor to the position of the pull-up resistor

44

00:04:21,233 --> 00:04:26,033

Just move the RAMCFG2 pin and pull it up to 3.3V

45

00:04:29,300 --> 00:04:35,000

For models like A2159, its configuration table has undergone a little change

46

00:04:38,500 --> 00:04:43,200

This kind of memory only has two chips, just buy two chips and replace them.

47

00:04:43,900 --> 00:04:48,566

The combined capacity of these two chips is larger than that of the original machine,

48

00:04:48,833 --> 00:04:50,500

which is called an upgrade

49

00:04:51,666 --> 00:04:54,800

For example, the original machine is 8GB,

50

00:04:56,033 --> 00:04:59,966

if you want to upgrade to 16GB, it is still Hynix

51

00:05:02,500 --> 00:05:05,700

If we want to change, just follow this form to change

52

00:05:05,966 --> 00:05:08,066

The original 8GB is like this,

53

00:05:08,400 --> 00:05:11,000

RAMCFG4 is in low level,

54

00:05:11,366 --> 00:05:18,366

RAMCFG3 is also low, RAMCFG2, RAMCFG1 and RAMCFG0, which are all in low level

55

00:05:18,966 --> 00:05:21,166

There are a total of 5 resistors,

56

00:05:22,200 --> 00:05:26,500

if all these resistors are installed, they will all be in low level

57

00:05:27,066 --> 00:05:31,233

If it is not installed, it is pulled up to a high level by the chipset

58

00:05:33,800 --> 00:05:37,666

After removing the resistor, it defaults to high level

59

00:05:38,133 --> 00:05:42,633

If you want to upgrade to 16G, you only need to keep the four pins low,

60

00:05:43,833 --> 00:05:50,333

RAMCFG4, RAMCFG3, RAMCFG1, and RAMCFG0

61

00:05:51,166 --> 00:05:54,066

Only RAMCFG2 is not mentioned here, we will dismantle it,

62

00:05:54,266 --> 00:05:57,100

after dismantling, it will be high level

63

00:05:58,766 --> 00:06:03,666

What is not listed in this table means to remove it and keep it at a high level

64

00:06:06,066 --> 00:06:09,900

After the memory upgrade, some models need to refresh the BIOS

65

00:06:12,533 --> 00:06:16,133

Ok, here's how to upgrade the memory on an Apple laptop
