1

00:00:00,400 --> 00:00:05,233

Hello everyone, today we will learn how to repair the power down failure of the Apple laptop

2

00:00:06,200 --> 00:00:08,633

Power down means that after pressing the switch,

3

00:00:09,000 --> 00:00:12,266

the mainboard enters the power-on state from the standby state,

4

00:00:12,766 --> 00:00:16,566

and the current rises accordingly, and then automatically shuts down,

5

00:00:17,033 --> 00:00:18,633

which is called power down

6

00:00:19,800 --> 00:00:23,100

Common power down faults are divided into the following types

7

00:00:24,566 --> 00:00:28,633

The first is that the standby condition of the chipset is not normal

8

00:00:29,333 --> 00:00:34,566

For example, the reset signal of RTC is normally 3.3V high level,

9

00:00:34,966 --> 00:00:37,600

and the minimum cannot be lower than 2V

10

00:00:38,333 --> 00:00:44,300

If it is exactly 2V, it is in a critical state and will cause power down at any time

11

00:00:44,733 --> 00:00:47,700

This is a fault that has been repaired more often.

12

00:00:49,400 --> 00:00:51,600

When encountering this kind of problem,

13

00:00:51,900 --> 00:00:57,400

measure each standby condition of the chipset one by one to see if they have normal voltage values

14

00:01:00,200 --> 00:01:04,333

Second, we need to measure the conduction condition of the isolation tube

15

00:01:04,333 --> 00:01:07,966

to eliminate the power-down fault caused by the false common point

16

00:01:08,266 --> 00:01:12,200

The second fault, the standby condition of the EC is not normal

17

00:01:12,700 --> 00:01:19,666

For example, PP3V3_S5_AVREF_SMC, if the power supply is not normal,

18

00:01:20,300 --> 00:01:22,466

it will also cause power down when booting

19

00:01:24,000 --> 00:01:30,800

Therefore, it is necessary to carefully measure whether the EC's standby power supply, clock, reset,

20

00:01:31,100 --> 00:01:34,166

and switch signals and LID signals are normal.

21

00:01:35,700 --> 00:01:40,100

The third fault is power failure caused by abnormal temperature control circuit

22

00:01:40,566 --> 00:01:45,733

This kind of fault can search for "THERMTRIP" signal in the circuit diagram

23

00:01:46,133 --> 00:01:47,900

and check whether it is normal

24

00:01:48,433 --> 00:01:54,233

Generally, this signal is connected to the temperature control circuit, normally it is high level,

25

00:01:55,733 --> 00:01:58,366

if it is low, it may cause power failure

26

00:02:01,266 --> 00:02:03,900

The voltage is insufficient after starting up,

27

00:02:04,266 --> 00:02:07,633

and some power supplies have not been successfully turned on

28

00:02:07,766 --> 00:02:13,033

For example, lack of CPU power supply after booting, or lack of bus power supply

29

00:02:13,400 --> 00:02:17,700

It will cause power down, which is a power down due to lack of voltage.

30

00:02:18,166 --> 00:02:22,866

You can use the dual channel of the oscilloscope to compare the waveforms of each power supply

31

00:02:22,900 --> 00:02:26,700

to see which power supply has not been generated before the power failure

32

00:02:27,733 --> 00:02:34,100

Compare the SLP_S3# signal to see which power supply drops earlier than the SLP_S3# signal,

33

00:02:34,633 --> 00:02:37,500

and the power supply that drops first is problematic

34

00:02:38,266 --> 00:02:43,566

If SLP_S3# falls first, then there is a problem with the bridge or chipset

35

00:02:45,133 --> 00:02:50,600

After receiving the switch signal, the chipset sends out SLP_S5#, SLP_S4#, SLP_S3#

36

00:02:50,600 --> 00:02:53,433

to turn on the power supply of the following channels

37

00:02:55,000 --> 00:02:59,533

Within the specified time, if some power supply is not successfully turned on,

38

00:03:00,700 --> 00:03:05,800

the chipset will automatically turn off the SLP_S*# signal to cause power failure

39

00:03:06,533 --> 00:03:08,033

This is a power failure

40

00:03:08,966 --> 00:03:12,333

There is also a power failure during the soft startup process,

41

00:03:12,866 --> 00:03:15,133

which has nothing to do with the hard start

42

00:03:16,033 --> 00:03:19,866

There is no problem with the power supply, clock, and reset signals

43

00:03:20,333 --> 00:03:23,566

The CPU has been working, and the BIOS has been read,

44

00:03:23,733 --> 00:03:26,500

and the self-test of the entire mainboard is performed

45

00:03:26,833 --> 00:03:30,566

During the self-test, if a problem is detected with a device,

46

00:03:30,700 --> 00:03:32,300

it will cause a power down

47

00:03:33,233 --> 00:03:37,966

Of course, there are also power failures caused by the BIOS itself

48

00:03:38,500 --> 00:03:41,866

For example, there is a problem with the BIOS itself,

49

00:03:42,633 --> 00:03:48,300

which causes failures during the self-test of each device, causing the self-test to fail

50

00:03:50,433 --> 00:03:54,566

During the self-test process, when each device is self-tested,

51

00:03:54,900 --> 00:03:59,000

if a certain device fails the self-test, it will cause power failure

52

00:03:59,300 --> 00:04:02,500

In this case, we can try to flash the BIOS first,

53

00:04:03,366 --> 00:04:08,266

eliminate the cause of the peripherals, and finally try to replace the chipset or EC

54

00:04:08,500 --> 00:04:11,666

The last type of fault is that after entering the system,

55

00:04:12,100 --> 00:04:15,100

the power is cut off from time to time during normal use

56

00:04:16,466 --> 00:04:21,766

In this case, we need to rule out the cause of the external device or the temperature control circuit

57

00:04:22,066 --> 00:04:25,566

You can also try to replace the memory, replace the BIOS,

58

00:04:25,900 --> 00:04:27,600

or reinstall the system

59

00:04:29,166 --> 00:04:32,466

Change the hard disk, reinstall the system and test,

60

00:04:33,400 --> 00:04:38,900

eliminate the cause of the system and software, and then consider to reball the chipset or EC

61

00:04:41,933 --> 00:04:43,933

Next, let's look at a case

62

00:04:44,233 --> 00:04:49,700

For example, Apple A1465, power down at about 0.7A

63

00:04:49,966 --> 00:04:53,766

When the power is turned on to 0.7A, the power is cut off,

64

00:04:54,000 --> 00:04:57,066

and it can be triggered repeatedly after the power is off

65

00:04:57,433 --> 00:05:01,933

In this case, it is generally necessary to consider Apple's common problem,

66

00:05:02,033 --> 00:05:07,400

which is the power supply of EC's PP3V3_S5_AVREF_SMC

67

00:05:07,933 --> 00:05:13,200

If the power supply is not normal, it will cause the power down at about 0.7A

68

00:05:13,433 --> 00:05:17,166

After measuring we found that there is no voltage of this power supply

69

00:05:17,633 --> 00:05:23,833

After measuring the impedance, I found that its resistance value is only 0.0053,

70

00:05:23,966 --> 00:05:27,366

which is quite low, and it is obviously short circuited

71

00:05:28,066 --> 00:05:31,933

In this case, either the chip that outputs the power supply is short-circuited,

72

00:05:32,300 --> 00:05:35,300

or there is a problem with the capacitor at the output end,

73

00:05:35,766 --> 00:05:38,233

or there is a problem with the EC itself

74

00:05:39,233 --> 00:05:44,633

Let's start with the easy and then the difficult, first eliminate the filter capacitor

75

00:05:45,033 --> 00:05:48,700

After replacing the filter capacitor, the problem was fixed

76

00:05:48,933 --> 00:05:50,766

This capacitor has been replaced

77

00:05:51,100 --> 00:05:56,133

After the replacement, it can be turned on and it can enter the system normally

78

00:05:56,533 --> 00:05:58,933

OK, this is a repair for a power down
