1

00:00:00,266 --> 00:00:05,033

Hello everyone, today we will learn how to repair the failure of Apple laptop not charging

2

00:00:05,833 --> 00:00:08,933

No charging fault means that after plugging in the adapter,

3

00:00:09,400 --> 00:00:14,200

the battery cannot be charged normally, and the battery power will become lower and lower

4

00:00:16,733 --> 00:00:18,666

Usually there are three phenomena

5

00:00:20,000 --> 00:00:24,933

The first one is that the battery is not detected in the system and cannot be charged

6

00:00:28,966 --> 00:00:33,333

The second type is that the battery power information can be recognized in the system,

7

00:00:33,966 --> 00:00:35,700

but the battery cannot be charged

8

00:00:41,000 --> 00:00:45,666

The third is that the system shows that it is charging, but it cannot be charged,

9

00:00:46,100 --> 00:00:48,700

and the battery power is getting lower and lower.

10

00:00:52,800 --> 00:00:55,966

These 3 are the more common faults of no charging

11

00:00:57,533 --> 00:01:00,966

Among them, there are reasons for the battery itself,

12

00:01:01,333 --> 00:01:04,633

and there are also problems with the circuit of the mainboard

13

00:01:07,966 --> 00:01:12,833

Our maintenance ideas have different processing methods for the three types of failures

14

00:01:13,800 --> 00:01:16,333

First of all, the first kind of failure,

15

00:01:16,866 --> 00:01:19,200

the battery cannot be recognized in the system,

16

00:01:19,466 --> 00:01:21,533

usually caused by the battery damage

17

00:01:26,933 --> 00:01:32,033

If the battery itself is normal and can be used normally when installed on other identical machines,

18

00:01:32,600 --> 00:01:34,833

then the cause of the battery is ruled out

19

00:01:35,300 --> 00:01:39,733

You can check whether the battery insertion identification signal on the mainboard is normal

20

00:01:42,300 --> 00:01:47,166

For the second type of failure, the battery power can be identified in the system,

21

00:01:47,700 --> 00:01:49,233

but it cannot be charged,

22

00:01:55,000 --> 00:01:58,833

usually because the wrong adapter is used or the adapter is damaged,

23

00:01:59,633 --> 00:02:05,766

or it may be that the EC cannot recognize the power information of the adapter, resulting in no charging

24

00:02:06,400 --> 00:02:09,800

For example, there is an indicator light on the power head

25

00:02:12,500 --> 00:02:17,466

Under normal circumstances, the EC can complete the communication with the adapter,

26

00:02:17,833 --> 00:02:19,500

and this light will be on

27

00:02:20,333 --> 00:02:24,566

When the green light is on, it means that the charging has been fully charged,

28

00:02:25,266 --> 00:02:28,600

and the communication between the EC and the adapter is normal

29

00:02:29,133 --> 00:02:34,566

If the light is off, it means the communication between EC and adapter is interrupted

30

00:02:35,700 --> 00:02:38,500

If the light is orange, it means it is charging

31

00:02:41,900 --> 00:02:46,933

Of course, there are also reasons for the battery itself that cannot be charged normally

32

00:02:47,933 --> 00:02:53,633

For the third type of failure, it shows that it is charging, but it has not been fully charged,

33

00:02:53,866 --> 00:02:58,200

which is usually caused by a failure of the charging circuit or an EC problem

34

00:02:59,600 --> 00:03:01,800

This problem is more complicated,

35

00:03:02,200 --> 00:03:04,933

first we have to rule out the cause of the battery

36

00:03:06,566 --> 00:03:09,366

Some batteries have been left useless for a long time,

37

00:03:09,566 --> 00:03:12,800

resulting in loss of capacity and failure to charge

38

00:03:13,533 --> 00:03:15,833

We need to replace the battery for testing

39

00:03:16,566 --> 00:03:19,100

Some batteries have not been used for a long time,

40

00:03:19,766 --> 00:03:22,700

and it will be displayed as charging after being installed

41

00:03:23,633 --> 00:03:30,233

After charging for many hours, it will gradually charge in slowly, which is also an activation process

42

00:03:30,800 --> 00:03:31,833

This is rare

43

00:03:38,566 --> 00:03:43,533

Generally, the battery is useless after a long time, and the capacity is invalid

44

00:03:43,766 --> 00:03:46,466

It is recommended that you replace the battery

45

00:03:47,100 --> 00:03:51,333

We can replace the charging chip, the upper and lower tubes of the charging circuit

46

00:03:53,033 --> 00:03:57,400

Focus on checking whether the charging current detection circuit is disconnected

47

00:03:58,433 --> 00:04:01,033

Let's take a look at this charging block diagram

48

00:04:01,866 --> 00:04:04,133

The charging chip is controlled by the EC

49

00:04:05,666 --> 00:04:08,300

This is the upper tube, this is the lower tube

50

00:04:10,633 --> 00:04:13,933

After the charging chip receives the charging command from the EC,

51

00:04:14,433 --> 00:04:18,000

it will output pulses to drive the upper and lower tubes to conduct,

52

00:04:18,466 --> 00:04:20,966

generate charging voltage and charging current,

53

00:04:21,533 --> 00:04:25,833

and charge the battery after passing through the charging current-sensing resistor

54

00:04:32,500 --> 00:04:38,100

The charging chip will detect the charging current in real time and feed back the charging current to the EC

55

00:04:41,966 --> 00:04:47,233

EC will adjust the charging current in real time according to the charging current and battery power

56

00:04:50,833 --> 00:04:55,666

If the current detection circuit is disconnected, or the resistance of the circuit changes,

57

00:04:56,333 --> 00:04:59,700

it will cause the display to be charging but not fully charged

58

00:05:04,533 --> 00:05:09,966

The charging chip is damaged, the communication between the EC and the charging chip is abnormal,

59

00:05:10,800 --> 00:05:14,233

or the communication between the EC and the battery is abnormal,

60

00:05:14,633 --> 00:05:18,000

and the battery power information cannot be obtained correctly,

61

00:05:18,233 --> 00:05:20,133

which will cause this failure

62

00:05:20,866 --> 00:05:26,133

For this kind of failure, you can replace the EC, or re-flash the EC program

63

00:05:26,400 --> 00:05:30,933

For Apple's EC, we generally have no way to flash the EC program,

64

00:05:31,433 --> 00:05:33,566

we can replace the EC directly

65

00:05:35,400 --> 00:05:38,900

Ok, this is the repair of the Apple laptop no charging fault
