1

00:00:00,166 --> 00:00:05,500

Hello everyone, today we will learn about the common problems of these models of Apple laptops

2

00:00:06,566 --> 00:00:12,533

The A1465, A1466 and A1502 models do not start up

3

00:00:12,533 --> 00:00:16,300

or sometimes can be turned on and sometimes cannot be turned on

4

00:00:21,166 --> 00:00:25,866

This kind of failure is mostly caused by the abnormal standby reset signal of the EC

5

00:00:25,933 --> 00:00:28,500

We can replace the U5110

6

00:00:33,100 --> 00:00:36,566

U5110 provides reset signal to EC

7

00:00:40,000 --> 00:00:44,700

The third pin VIN of this chip comes from the standby power supply of EC

8

00:00:46,033 --> 00:00:50,566

The first pin is specially used to check whether the EC standby power supply is normal,

9

00:00:51,133 --> 00:00:53,766

and the detection threshold is 3.0V

10

00:00:55,100 --> 00:00:58,633

As long as the voltage of this pin exceeds 3.0V,

11

00:00:58,833 --> 00:01:03,300

it will internally open-drain and output the EC standby reset signal,

12

00:01:03,966 --> 00:01:06,600

which is pulled up externally to a high level

13

00:01:10,233 --> 00:01:14,933

If the signal is abnormal, it is either because of the internal short circuit of the chip,

14

00:01:15,066 --> 00:01:17,433

or the damage of the pull-up resistor,

15

00:01:17,566 --> 00:01:20,300

or the EC short circuit pulls the signal down,

16

00:01:20,566 --> 00:01:23,400

and a small part is the leakage of the mainboard circuit

17

00:01:26,600 --> 00:01:32,566

Our solution is to replace the U5110, or directly connect this pull-up resistor,

18

00:01:32,733 --> 00:01:35,000

try to see if it can solve the problem

19

00:01:36,233 --> 00:01:39,633

If it can't be solved, we will try to replace the EC

20

00:01:40,300 --> 00:01:48,333

The second fault, the power-on current rises from 0.015A to 0.05A or 0.2A,

21

00:01:48,500 --> 00:01:51,233

and the power-off restarts repeatedly

22

00:01:53,366 --> 00:01:56,300

This is usually due to lack of power to the mainboard

23

00:01:56,866 --> 00:02:01,300

We focus on checking whether the main power supply of each channel is normally generated,

24

00:02:02,200 --> 00:02:04,366

which can be measured with an oscilloscope

25

00:02:04,933 --> 00:02:08,700

Check whether the back-end output voltage of each inductor is normal

26

00:02:11,566 --> 00:02:13,600

We can re-flash the BIOS

27

00:02:15,633 --> 00:02:19,200

This failure can also be caused by a problem with the BIOS program

28

00:02:20,966 --> 00:02:24,200

The CPU is soldered falsely or the CPU is damaged,

29

00:02:24,533 --> 00:02:27,733

which will also cause repeated power failure and restart

30

00:02:30,266 --> 00:02:33,633

We need to reball the CPU, or replace the CPU

31

00:02:36,400 --> 00:02:43,500

If the A1465, A1466, and A1370 models have 3 alarms when they are turned on,

32

00:02:46,900 --> 00:02:50,000

it is generally necessary to replace the memory chips first,

33

00:02:50,366 --> 00:02:53,166

because it is usually caused by memory damage

34

00:02:53,633 --> 00:02:56,466

If changing the memory still does not solve the problem,

35

00:02:57,233 --> 00:03:00,300

consider replacing the CPU or PCH

36

00:03:01,733 --> 00:03:05,466

If it is a machine with liquid or a machine that has been dropped,

37

00:03:07,266 --> 00:03:10,733

the possibility of disconnection of the board cannot be ruled out

38

00:03:10,966 --> 00:03:13,166

This is the most difficult to repair

39

00:03:15,033 --> 00:03:23,166

After the models like A1465 and A1466 have water ingress, the backlight circuit is also prone to problems

40

00:03:24,133 --> 00:03:28,833

The fault phenomenon is usually a dark screen when the power is turned on, and no display

41

00:03:29,666 --> 00:03:33,133

The solution is to focus on troubleshooting these fault points

42

00:03:33,800 --> 00:03:36,166

Check if the screen interface is corroded,

43

00:03:38,500 --> 00:03:41,500

and if the backlight boost control chip is damaged

44

00:03:44,600 --> 00:03:47,766

We remove the backlight driver chip, we can find that

45

00:03:47,766 --> 00:03:52,600

there are traces of mold on the bottom, and even some solder points have disappeared

46

00:03:55,300 --> 00:03:59,100

The FB feedback pin of the backlight chip is disconnected,

47

00:03:59,633 --> 00:04:03,633

and it is easy to cause the dark screen to not be displayed after booting

48

00:04:04,433 --> 00:04:08,866

Ok, these are the common problems of these models from Apple laptops
