1

00:00:00,266 --> 00:00:05,400

Hello everyone, today we will learn about the common problems of these models of Apple laptops

2

00:00:06,166 --> 00:00:12,000

Apple's A1502, A1398, A1425 models

3

00:00:13,100 --> 00:00:17,133

You can hear a "boom" sound when you turn it on, but there is no display,

4

00:00:17,833 --> 00:00:21,133

the screen is dark, and the external display is normal

5

00:00:25,366 --> 00:00:28,600

In this case, generally check the screen cable first,

6

00:00:28,966 --> 00:00:31,833

it may be that the screen cable is not plugged in properly,

7

00:00:32,300 --> 00:00:35,833

or the contact is poor, you can re-plug the screen cable,

8

00:00:36,133 --> 00:00:38,433

or clean the screen cable interface

9

00:00:39,533 --> 00:00:43,466

It is also possible that the screen cable is damaged and needs to be replaced

10

00:00:44,966 --> 00:00:47,933

The screen lines of these three models are common

11

00:00:49,566 --> 00:00:52,400

The faults of screen line damage occur the most

12

00:00:53,366 --> 00:00:55,733

Generally, re-plug the screen cable,

13

00:00:55,900 --> 00:00:57,900

if not, replace the screen cable

14

00:00:59,466 --> 00:01:02,766

The A1398 model has two version numbers,

15

00:01:07,433 --> 00:01:09,633

and their drawings are exactly the same

16

00:01:12,533 --> 00:01:14,433

They have a common failure phenomenon,

17

00:01:17,100 --> 00:01:22,433

the power is turned off when the system is turned on, the power is not lost when the system is not turned on,

18

00:01:22,500 --> 00:01:25,100

and the machine cannot be turned on with the battery alone

19

00:01:25,733 --> 00:01:31,266

Like this kind of failure, generally repair the battery mode first, so that it can be turned on

20

00:01:34,166 --> 00:01:36,966

The model of the battery is A1618

21

00:01:37,133 --> 00:01:41,900

After entering the system, if there is an exclamation mark on the battery,

22

00:01:42,400 --> 00:01:44,833

it should be that the battery itself is damaged

23

00:01:46,100 --> 00:01:48,966

This machine will power off without a battery installed

24

00:01:51,566 --> 00:01:58,000

The video card power supply chip ISL62882C of this machine is also a common problem,

25

00:01:58,566 --> 00:02:01,700

which is easy to be damaged and will cause power failure

26

00:02:05,233 --> 00:02:09,100

A1502 freezes, fan spins wildly

27

00:02:09,700 --> 00:02:13,400

For this kind of problem, generally check the peripherals first.

28

00:02:13,966 --> 00:02:21,933

Such as small power boards, cameras, touchpads, keyboards, batteries, etc.

29

00:02:22,466 --> 00:02:27,000

Then check the device connected to the I2C bus, or replace the EC

30

00:02:27,666 --> 00:02:32,933

For laptops before 2017, after directly plugging in the adjustable power supply,

31

00:02:33,266 --> 00:02:37,666

if the standby current is around 200mA and there is no standby power supply

32

00:02:39,200 --> 00:02:41,966

This is usually a short circuit at the common point.

33

00:02:42,433 --> 00:02:44,900

We only need to find the short-circuited components,

34

00:02:45,200 --> 00:02:47,466

or find the fault point and fix it
