1

00:00:00,400 --> 00:00:05,200

Hello everyone, today we will learn about the common problems of these models of Apple laptops

2

00:00:05,833 --> 00:00:10,200

A1989 and A1990 both have 4 Type-c ports,

3

00:00:15,100 --> 00:00:17,966

and A2159 has two Type-C ports

4

00:00:20,800 --> 00:00:25,333

These models with Type-C ports have a common fault: the adapter does not boost

5

00:00:29,533 --> 00:00:32,666

It is mostly because the Type-C controller is damaged

6

00:00:41,066 --> 00:00:43,700

It needs to be replaced with a chip of the same type

7

00:00:44,500 --> 00:00:49,100

If it is a mainboard with 4 Type-C interfaces, there are 4 Type-C control chips

8

00:00:52,933 --> 00:00:54,933

If any of the chips is damaged,

9

00:00:55,433 --> 00:00:58,166

all Type-C interface adapters will not boost

10

00:01:01,966 --> 00:01:07,333

For example, A2159 has two Type-C interfaces and two Type-C control chips,

11

00:01:13,033 --> 00:01:16,166

one chip is responsible for one Type-C interface

12

00:01:16,666 --> 00:01:22,033

Any CD3217 damage will cause all Type-C interface adapters to not boost

13

00:01:25,900 --> 00:01:31,100

After the A1989 is turned on, the external display can display normally,

14

00:01:31,366 --> 00:01:33,633

but the internal display has no display.

15

00:01:34,866 --> 00:01:38,366

Whether it is the water inlet machine or natural damage,

16

00:01:38,933 --> 00:01:43,633

it is basically a short circuit between pin 1 and pin 3 of the screen interface

17

00:01:44,366 --> 00:01:47,900

Pin 1 is the EDP_INT_AUX_N signal

18

00:01:49,233 --> 00:01:52,433

Pin 3 is the EDP_INT_AUX_P signal

19

00:01:55,700 --> 00:01:57,233

Pin 2 is the grounding

20

00:01:58,200 --> 00:02:01,400

These two signals are directly connected to the CPU

21

00:02:04,500 --> 00:02:09,700

If these two signals are short-circuited, first we need to eliminate the problem of the screen,

22

00:02:10,333 --> 00:02:15,933

eliminate the problem of the screen cable and the screen interface, and replace the screen to test

23

00:02:18,033 --> 00:02:21,066

If it still doesn't work, replace the CPU

24

00:02:23,266 --> 00:02:28,533

The PP3V3 inductor voltage of A2159 is easy to short circuit,

25

00:02:31,733 --> 00:02:34,166

all because the power management chip is damaged

26

00:02:36,033 --> 00:02:40,900

Replacement can be repaired, this is a common problem with A2159

27

00:02:41,766 --> 00:02:49,000

If the ground value of the hard disk power supply of A2159 and A1990 is pulled down to about 10 ohms,

28

00:02:49,866 --> 00:02:52,866

it is basically because the hard disk is short-circuited.

29

00:02:53,800 --> 00:02:56,833

The normal ground value is around 350

30

00:03:01,066 --> 00:03:07,566

If the ground value of the PP3V3_S5 power supply of A1990 is lowered to 100,

31

00:03:08,633 --> 00:03:11,866

it is generally caused by the damage of the T2 firmware,

32

00:03:12,333 --> 00:03:15,100

and you can directly flash the T2 firmware

33

00:03:16,033 --> 00:03:18,533

The ground value is normally about 300

34

00:03:19,800 --> 00:03:27,466

For Apple laptops after 2018, if the current stops at 0.06-0.08A after booting,

35

00:03:27,933 --> 00:03:31,266

it is basically because the internal firmware of the T2 is locked,

36

00:03:32,033 --> 00:03:34,466

and the T2 firmware needs to be refreshed

37

00:03:37,000 --> 00:03:40,866

The PMU chip of A2159 refers to this power chip,

38

00:03:41,200 --> 00:03:43,466

which is next to the T2 security chip

39

00:03:45,033 --> 00:03:48,033

This chip integrates multiple power supplies inside,

40

00:03:48,400 --> 00:03:51,633

and there are a bunch of power supply inductors output around it

41

00:03:52,266 --> 00:03:54,433

So it has a higher chance of damage

42

00:03:56,100 --> 00:03:59,066

Ok, here are some common problems of Apple laptops
