1

00:00:00,766 --> 00:00:05,833

Hello everyone, today we will learn the standard timing of AMD Ryzen APU chipset

2

00:00:09,100 --> 00:00:11,433

In the AMD Ryzen APU standard timing,

3

00:00:11,600 --> 00:00:17,433

VDDBT_RTC_G is the power supply for the RTC circuit, 3.3V.3V

4

00:00:21,466 --> 00:00:30,900

X32K_X1 and X32K_X2, these two pins are the pins connected to the 32.768KHz crystal oscillator

5

00:00:35,266 --> 00:00:40,333

When the APU is powered by the RTC, it will provide power to the crystal oscillator pin,

6

00:00:40,700 --> 00:00:42,966

and the crystal oscillator will start to vibrate,

7

00:00:43,333 --> 00:00:48,533

providing the APU with a reference clock frequency of 32.768KHz

8

00:00:48,866 --> 00:00:51,700

RTC circuit does not participate in triggering

9

00:00:53,366 --> 00:00:58,300

When this power supply is pulled low, it will clear the CMOS settings

10

00:00:59,166 --> 00:01:04,833

However, if the RTC circuit is abnormal, it will cause other strange faults,

11

00:01:05,400 --> 00:01:09,800

such as no reset after booting, no running code (no self-test), etc.

12

00:01:11,066 --> 00:01:15,666

S5 POWER RAILS, this is the standby power supply in S5 state,

13

00:01:16,300 --> 00:01:22,566

including VDD_33_S5, VDD_18_S5, VDDP_S5

14

00:01:23,200 --> 00:01:30,900

They are 3.3V standby power supply, 1.8V standby power supply and 0.75V standby power supply

15

00:01:31,600 --> 00:01:34,466

After these three standby power supplies are normal,

16

00:01:35,133 --> 00:01:40,300

a standby power good signal RSMRST_L, 1.8V will be generated

17

00:01:42,300 --> 00:01:45,833

There is no deep sleep standby in AMD's timings

18

00:01:52,466 --> 00:01:57,500

PWR_BTN_L, this is the switch trigger signal for the APU

19

00:02:01,166 --> 00:02:07,400

When the signal is in standby, it is high level, it will be pulled low after pressing the switch,

20

00:02:08,566 --> 00:02:12,000

and it will return to high level after releasing the switch

21

00:02:14,166 --> 00:02:16,533

When the APU receives the switch trigger signal,

22

00:02:16,766 --> 00:02:23,166

it will set SLP_S5_L and SLP_S3_L high in turn to turn on the memory power supply

23

00:02:23,300 --> 00:02:26,233

and the power supply required by the S0 state

24

00:02:35,433 --> 00:02:43,533

In AMD's chipset, there are only SLP_S5_L and SLP_S3_L, and they came out at the same time

25

00:02:47,600 --> 00:02:51,633

When all the power supplies in the S0 and S3 states are normal,

26

00:02:52,600 --> 00:02:57,300

a power good signal PWR_GOOD will be generated and sent to the APU,

27

00:02:58,066 --> 00:03:01,266

indicating that the power supply on the mainboard is all normal

28

00:03:04,033 --> 00:03:11,066

At the same time, after each power supply is normal, the 48MHz crystal oscillator of the APU will start to vibrate,

29

00:03:11,233 --> 00:03:15,300

providing the reference clock frequency of the clock module inside the APU,

30

00:03:16,000 --> 00:03:21,333

and the APU outputs various clocks, including PCIE bus clock 100MHz,

31

00:03:21,466 --> 00:03:25,300

LPC bus clock 24MHz or 33MHz

32

00:03:27,666 --> 00:03:31,766

Then the APU sends a PWROK signal to the CPU power supply chip

33

00:03:33,166 --> 00:03:39,533

Then APU will send SVID signal to the CPU power supply chip to adjust the CPU core power supply

34

00:03:44,333 --> 00:03:49,266

The APU delays and sends out the PCIE reset signal PICE_RST_L,

35

00:03:49,433 --> 00:03:52,633

which is usually used to reset the independent graphics card

36

00:03:54,866 --> 00:04:00,200

APU sends out APU_RST# or RESET_L, which are platform resets,

37

00:04:01,866 --> 00:04:09,266

used to reset various devices on the platform, such as wireless network card, network card, EC, etc.

38

00:04:12,933 --> 00:04:16,766

Ok, here is the standard timing for the AMD Ryzen APU chipset
