Hello everyone, today we will learn about the four major conditions of the RTC circuit

2

00:00:04,866 --> 00:00:10,000

in the standard timing of Intel's 10th to 12th generation low-power CPU chipsets

3

00:00:11,633 --> 00:00:13,500

This lesson includes two parts

4

00:00:13,766 --> 00:00:19,366

An introduction to the RTC circuit and an introduction to the four major working conditions of the RTC circuit

5

00:00:21,433 --> 00:00:29,166

First of all, low-power CPU refers to the integration of PCH and CPU, we collectively refer to it as CPU

6

00:00:34,166 --> 00:00:36,800

The RTC circuit is inside the PCH module

7

00:00:40,300 --> 00:00:45,533

The RTC circuit includes the RTC module inside the PCH, the RTC register,

8

00:00:46,033 --> 00:00:52,033

the external 32.768KHz crystal oscillator, and the reset of the RTC circuit

9

00:01:00,000 --> 00:01:06,100

RTC circuit is mainly used to store CMOS settings, save time, date and ESCD files

10

00:01:08,666 --> 00:01:13,366

If the RTC circuit is abnormal, the time and date information will be lost,

11

00:01:13,566 --> 00:01:16,566

and the CMOS setting information cannot be saved

12

00:01:16,966 --> 00:01:20,500

Abnormal RTC circuit will also cause failure to boot

13

00:01:25,166 --> 00:01:28,766

Let's take a look at the four working conditions of the RTC circuit

14

00:01:29,166 --> 00:01:31,533

The first one is VCCRTC

15

00:01:31,933 --> 00:01:35,666

This is a main power supply for the RTC module inside the CPU,

16

00:01:36,300 --> 00:01:38,866

the voltage value is 3.3V

17

00:01:39,366 --> 00:01:44,933

It is mainly used to save SMOS parameters and guarantee the normal operation of the time

18

00:01:47,133 --> 00:01:54,333

The second, RTCRST# and SRTCRST#, both are 3.3V high level

19

00:01:55,600 --> 00:02:00,900

These two are the reset of the RTC circuit, both of which are high at 3.3V

20

00:02:03,233 --> 00:02:07,033

The third is a 32.768KHz crystal oscillator

21

00:02:07,833 --> 00:02:11,300

This crystal oscillator is not shown in the standard timing diagram,

22

00:02:14,900 --> 00:02:18,933

but in the RTC circuit, it is an essential condition

23

00:02:25,100 --> 00:02:31,100

After the VCCRTC power supply is normal, the CPU will provide power to the crystal oscillator pin

24

00:02:34,066 --> 00:02:40,066

Then the crystal oscillator starts to vibrate, providing the reference clock for the RTC module inside the CPU

25

00:02:42,900 --> 00:02:47,166

Ok, this is an introduction to the four major conditions of the RTC circuit
