177. Intel 10th~12th Power supplies generation sequence
We will learn about the power supply generation sequence in the standard timing of Intel's 10th to 12th generation low-power CPU chipsets.
Detail
Comments

1

00:00:00,266 --> 00:00:03,733

In this lesson, we will learn about the power supply generation sequence

2

00:00:03,733 --> 00:00:08,833

in the standard timing of Intel's 10th to 12th generation low-power CPU chipsets

3

00:00:12,400 --> 00:00:16,800

This lesson includes two parts, the explanation of each power supply and signal,

4

00:00:16,933 --> 00:00:19,766

and the timing of each power supply and signal generation

5

00:00:21,200 --> 00:00:25,500

First of all, let's take a look at the explanation of each power supply and signal

6

00:00:26,166 --> 00:00:29,100

power supply in this timing diagram refers to this part

7

00:00:31,266 --> 00:00:38,333

The first one is VCCST power supply and VCCSTG power supply, which is the maintain voltage of the CPU,

8

00:00:38,800 --> 00:00:41,566

usually controlled by CPU_C10_GATE#

9

00:00:48,600 --> 00:00:55,633

The second one, VPP, VDD2 and VDDQ, these refer to the power supply required by the memory,

10

00:00:55,966 --> 00:00:58,366

generally controlled by SLP_S4#

11

00:01:07,233 --> 00:01:12,633

VCC refers to the secondary voltage 3.3V, the secondary voltage 5V,

12

00:01:12,933 --> 00:01:15,933

and the secondary voltage 1.8V, etc.

13

00:01:16,633 --> 00:01:19,166

After the VCCST power supply is normal,

14

00:01:19,933 --> 00:01:25,566

it will generate a VCCST_PWRGD signal to the CPU, 1.05V,

15

00:01:26,566 --> 00:01:29,600

indicating that the VCCST power supply is normal

16

00:01:37,433 --> 00:01:44,800

The CPU will then issue DDR_VTT_CTL to generate the memory VTT power supply, 0.6V

17

00:01:54,066 --> 00:01:58,466

Then, after circuit conversion, a VR_ON signal is generated,

18

00:02:01,933 --> 00:02:04,500

which is a signal to turn on the CPU power supply,

19

00:02:04,600 --> 00:02:08,300

and is used to turn on VCCIN to supply power to the CPU

20

00:02:11,366 --> 00:02:15,666

VCCIN is equivalent to supplying power to the common point inside the CPU

21

00:02:18,733 --> 00:02:25,966

The CPU integrates integrated display power supply, VCCSA power supply, VCCPLL power supply, etc.

22

00:02:28,266 --> 00:02:32,466

VCCIN is what we call the common point power supply inside the CPU,

23

00:02:33,800 --> 00:02:36,200

using FIVR power supply mode

24

00:02:38,400 --> 00:02:42,666

Next, let's take a look at the timing of each power supply and signal generation

25

00:02:45,000 --> 00:02:47,300

After the CPU receives the switch signal,

26

00:02:47,500 --> 00:02:51,600

it will directly or indirectly turn on the various power supplies behind

27

00:02:51,600 --> 00:02:58,100

through the ESPI bus or SLP_S4#, SLP_S5#, SLP_S3#, etc.

28

00:03:05,033 --> 00:03:10,800

Among them, SLP_S4# will be used to turn on the memory VPP power supply 2.5V

29

00:03:10,833 --> 00:03:13,433

and memory main power supply 1.2V

30

00:03:14,800 --> 00:03:23,033

SLP_S3# will be used to turn on the secondary voltage 3.3V, secondary voltage 5V, 1.8V, etc.

31

00:03:23,633 --> 00:03:29,866

After each power supply is normal, VCCST_PWRGD will be generated and sent to the CPU

32

00:03:31,133 --> 00:03:37,933

The CPU will issue DDR_VTT_CTL to control the VTT power supply of the memory, 0.6V

33

00:03:39,233 --> 00:03:46,800

At the same time, the CPU will issue a CPU_C10_GATE# to turn on the VCCSTG power supply of the CPU

34

00:03:51,500 --> 00:03:54,933

Ok, this is the generation sequence of each power supply and signal
