1

00:00:00,466 --> 00:00:04,900

Hello everyone, today we will learn about the generation sequence of PG and clock signals

2

00:00:04,900 --> 00:00:09,666

in the standard timing of Intel's 10th to 12th generation low-power CPU chipsets

3

00:00:14,600 --> 00:00:18,800

PG, clock signal generation sequence refers to this part of the timing diagram

4

00:00:23,433 --> 00:00:30,300

The first one is VCCIN_VR_READY, which means that the VCCIN power supply of the CPU is normal,

5

00:00:33,466 --> 00:00:37,766

and it is usually sent to EC or communicated with other PGs.

6

00:00:42,800 --> 00:00:45,566

The second one, PCH_PWROK,

7

00:00:45,966 --> 00:00:51,333

this is the 3.3V high level sent to the CPU by the motherboard after the power supply is normal,

8

00:00:51,733 --> 00:00:54,600

indicating that the S0 state voltage is OK

9

00:00:55,200 --> 00:01:00,366

VCCIO, the actual circuit diagram searches for VCCIO_OUT,

10

00:01:00,733 --> 00:01:04,166

which is the 1.05V power supply output by the CPU

11

00:01:06,600 --> 00:01:12,733

After each power supply is normal, the 38.4M crystal oscillator of the CPU starts to vibrate,

12

00:01:13,000 --> 00:01:16,633

providing the reference frequency for the clock module inside the CPU

13

00:01:17,600 --> 00:01:21,466

But this crystal oscillator is not reflected in the standard timing diagram

14

00:01:25,300 --> 00:01:31,300

Next, PCH_CLK_OUTPUTS, this is the clock output by the CPU

15

00:01:32,500 --> 00:01:39,633

These include ESPI bus clock, PCIE bus clock, independent graphics card clock, etc.

16

00:01:44,033 --> 00:01:47,166

The last one, SYS_PWROK,

17

00:01:47,300 --> 00:01:49,900

means that the system power supply is normal,

18

00:01:50,300 --> 00:01:55,566

and it is also the key PG signal for reset, with a voltage of 3.3V

19

00:01:56,833 --> 00:02:00,266

Ok, this is the generation sequence of PG and clock signals
