Hello everyone, today we will learn about the reset signal generation sequence

2

00:00:04,000 --> 00:00:08,866

in the standard timing of Intel's 10th to 12th generation low-power CPU chipsets

3

00:00:13,400 --> 00:00:18,866

This lesson includes reset signal generation sequence, and reset signal distribution block diagram

4

00:00:24,866 --> 00:00:28,900

The generation timing of the reset signal refers to this part of the timing diagram

5

00:00:32,033 --> 00:00:37,200

The first one is PLTRST#, which is the platform reset signal, 3.3V,

6

00:00:40,266 --> 00:00:43,966

sent by the CPU to each chip and each slot as a reset

7

00:00:47,266 --> 00:00:49,633

This is the over temperature protection signal

8

00:00:53,066 --> 00:01:00,366

After reset, the CPU will send an SVID signal to the CPU power supply chip to adjust the CPU power supply VCCIN

9

00:01:06,800 --> 00:01:11,100

SVID usually consists of a serial bus consisting of a data (VIDOUT) and a clock (VIDSCK),

10

00:01:11,400 --> 00:01:12,800

and an ALERT# signal

11

00:01:18,500 --> 00:01:21,333

The third is the memory reset, DRAM_RESET#

12

00:01:24,866 --> 00:01:29,466

After the various power supplies, clock, and reset signals of the CPU are normal,

13

00:01:29,666 --> 00:01:32,333

it will start to read the BIOS and start self-test

14

00:01:33,133 --> 00:01:34,833

In the self-test process,

15

00:01:35,100 --> 00:01:39,400

when the CPU completes the identification of the memory through the system management bus,

16

00:01:39,866 --> 00:01:44,500

it will send DRAM_RESET# to the memory to reset the memory and initialize the memory

17

00:01:47,000 --> 00:01:49,933

Ok, this is the sequence timing of the two reset signals

18

00:01:52,433 --> 00:01:56,600

Next, let's take a look at the distribution block diagram of the reset signal

19

00:01:56,900 --> 00:02:02,566

Platform reset is mainly for graphics cards, network cards, and M.2 interfaces,

20

00:02:04,033 --> 00:02:08,333

And for the LPC bus of EC, the DEBUG diagnostic interface

21

00:02:13,600 --> 00:02:16,366

There is also an independent memory reset signal here,

22

00:02:17,733 --> 00:02:22,466

which is usually pulled up by the main power supply of the memory to provide reset for the memory

23

00:02:25,500 --> 00:02:28,800

Ok, here is the distribution block diagram of the reset signals
